Product description The ZE-ONE Zoom Extraction System from For.A lets you frame and extract specified HD scenes at any size from 4K sources using an intuitive touch-screen interface. To simulate zooming, dynamic zooming effects at key points and in various sizes can be specified in slow-motion instant replays from the FT-ONE high-speed 4K camera. This system allows you to enjoy replays of live sports coverage and other applications. Note: Control software for Windows 7 or Windows 8 computers is provided to enable touch and mouse operation. - Extract HD (1080i or 720p) output from QFHD (1080p × 4) input
- Isolate and enlarge the action in scenes
- Easy touchscreen-based framing and extraction
- Compatible with FT-ONE high-speed 4K cameras
- Simulate camerawork in replays frame slow-motion scenes at desired sizes and from specific in/out and intermediate points
- Ideal for capturing the excitement by zooming in to the action in slow-motion replays
- Includes an 16-channel embedded audio delay processor
In the Box For.A ZE-ONE Zoom Extraction System for FT-ONE 4K Cameras Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the For.A ZE-ONE Zoom Extraction System for FT-ONE 4K Cameras in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersFor.A ZE-ONE Specs | Video Formats | 1080/60p, 1080/59.94p, 1080/50p (input, auto-detection capability)
1080/60i, 1080/59.94i, 1080/50i (output)
720/60p, 720/59.94p, 720//50p (output) | | Video Inputs | 4 x 3G/HD-SDI: 3 Gb/s, 75 Ω, via BNC Connectors | | Genlock Input | 1 x BB: NTSC 0.429 Vp-p / PAL 0.45 Vp-p or Tri-level Sync: ±0.3 V, 75 Ω, via BNC Connector | | Video Outputs | 2 x HD-SDI: 1.5 Gb/s, 75 Ω, via BNC Connectors | | Quantization | Y: 10-bit, C: 10-bit | | Sampling Frequencies | Y: 148.5 MHz or 148.5/1.001 MHz, Y: 74.25 MHz or 74.25/1.001 MHz | | Video Delay | 3 frames | | Audio Output | Embedded audio 16 channels | | Audio Sampling Frequency | 48 kHz | | Interface | 1 x Ethernet (10/100Base-TX) via RJ-45 Port | | Temperature / Humidity | 32 to 104°F (0 to 40°C), 30 to 90% (no condensation) | | Power Requirement | 100 to 240 VAC | | Dimensions (W x H x D) | 16.92 x 1.73 x 18.7" (430 x 44 x 475 mm), EIA 1 RU |
