User Manual for Formatt Hitech 5 x 5" CC15C Cyan Color Compensating Filter

Click to enlarge the picture
Formatt Hitech 5 x 5" CC15C Cyan Color Compensating Filter Contents of the user manual for the Formatt Hitech 5 x 5" CC15C
  • Product category: Color Compensating Formatt Hitech
  • Brand: Formatt Hitech
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Formatt Hitech Color Compensating

User manual for the Formatt Hitech 5 x 5" CC15C contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Formatt Hitech product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Formatt Hitech user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Formatt Hitech product will considerably shorten its lifespan!



Product description

Formatt 5 x 5" CC15C Cyan Color Compensating Filters or CC's act as sponges, absorbing excessive amounts of particular colors. Some photographic situations require specific color corrections. For example, when shooting daylight film under fluorescent lighting, some magenta correction is needed in order to remove the greenish tint that would otherwise appear. Formatt CC filters offer color control of primary (red, green, blue) and secondary (yellow, magenta, and cyan) levels. Densities range from 0.025 to 0.50; by combining different densities, it gives the flexibility to knock out specific colors as well as offering extremely fine adjustments in color temperature. Note: The amount of color correction required is most accurately measured via a color temperature meter
  • Color Correction filters are specifically designed to affect the color sensitivity of film emulsions
  • A typical designation for one of these filters is CC30M; The "CC" stands for Color Compensating; The "30" stands for a density of 0.30 and the "M" is for magenta
  • Formatt manufactures three types of Color Correction Filters - Color Temperature Conversion, Light Balancing and Color Compensating
  • Optically consistent from filter to filter
  • Formatt filters use the finest materials together with state of the art production techniques; This has resulted in a standard of optical perfection unmatched anywhere else
  • All Formatt filters are manufactured using Water White Schott optical glass that is precision polished and ground to ensure absolute optical flatness and optimum performance

Absorbing Cell Technology

  • The secret to Formatt's consistency in filter design lies in its unique "Absorbing Cell Technology" (A.C.T.); This unique process allows color correct dyes to be applied to optically pure, wafer thin absorbing cells and offers a controllability that ensures the smoothest grad lines and consistent color across the whole filter surface.
  • This process is revolutionary compared with conventional filter dying techniques by eliminating the need to directly coat the glass surface itself; The repeatable performance gained through A.C.T. ensures that at any time you have to swap like filters for like filters mid shoot you can do so with confidence with no discernable differences in color or density.
  • Each filter is guaranteed flatness to a maximum 2-wave value and comes with an individual reading from a laser interferometer; Every filter is carefully verified with a densitometer and spectrophotometer to ensure consistent and accurate transmission, before leaving the factory - the result is an absolute purity of image that eliminates any unwanted colorcast caused by conventional greenish soda-lime glass.

Color Compensation Filter Factors

  • CC05B: in Daylight = 1.2: in Tungsten = 1.2
  • CC10B: in Daylight = 1.3: in Tungsten = 1.3
  • CC20B: in Daylight = 1.6: in Tungsten = 1.7
  • CC40B: in Daylight = 2.1: in Tungsten = 2.4
  • CC05Y: in Daylight = 1.1: in Tungsten = 1.1
  • CC10Y: in Daylight = 1.1: in Tungsten = 1.1
  • CC20Y: in Daylight = 1.2: in Tungsten = 1.2
  • CC40Y: in Daylight = 1.4: in Tungsten = 1.3
  • CC05C: in Daylight = 1.1: in Tungsten = 1.1
  • CC10C: in Daylight = 1.1: in Tungsten = 1.2
  • CC20C: in Daylight = 1.3: in Tungsten = 1.4
  • CC40C: in Daylight = 1.4: in Tungsten = 1.5
  • CC05R: in Daylight = 1.2: in Tungsten = 1.1
  • CC10R: in Daylight = 1.3: in Tungsten = 1.2
  • CC20R: in Daylight = 1.5: in Tungsten = 1.4
  • CC40R: in Daylight = 2.1: in Tungsten = 1.9
  • CC05G: in Daylight = 1.1: in Tungsten = 1.1
  • CC10G: in Daylight = 1.2: in Tungsten = 1.2
  • CC20G: in Daylight = 1.3: in Tungsten = 1.3
  • CC40G: in Daylight = 1.5: in Tungsten = 1.5
  • CC05M: in Daylight = 1.2: in Tungsten = 1.1
  • CC10M: in Daylight = 1.3: in Tungsten = 1.2
  • CC20M: in Daylight = 1.5: in Tungsten = 1.3
  • CC40M: in Daylight = 1.9: in Tungsten = 1.5
In the Box Formatt Hitech 5 x 5" CC15C Cyan Color Compensating Filter
  • One-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Formatt Hitech 5 x 5" CC15C Cyan Color Compensating Filter in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Formatt Hitech BF 5X5CC15CYA4 Specs

    Type Color Compensating
    Size 5 x 5" (125 x 125mm, 4mm thick)
    Grade 15 Cyan
    Filter Factor in Daylight = 1.2: in Tungsten = 1.3 (approx)
    Multi-Coated Not Applicable
    Rotating Not Applicable
    Effect Helps with color balance when shooting with any lighting source
    Application Architectural, portrait, product photography
    Color Temperature Not Specified by Manufacturer
    Construction Schott-Desag B270 Crown Optical Glass
    Front Filter Thread Size Not Applicable
    Front Lens Cap Size Not Applicable
    Package Weight 0.5 lb
    Box Dimensions (LxWxH) 2.0 x 2.0 x 2.0"
