Product description The 4K 12G-SDI MSX2-O Microsplit Reclocking DA with Standard Freakshow Power Connector from Freakshow HD is an ultra-compact reclocking distribution amplifier with a single 12G-SDI input and matching dual SDI outputs. Using Belden 1694A cables, the Microsplit is capable of extending a DCI 4K signal up to 246' via the dual outputs over 12G-SDI. Extensions over 6G-SDI run up to 328', 3G-SDI up to 722', HD-SDI up to 870', and SD-SDI up to 1740'. An included AC adapter features a U.S. wall plug on one end and standard Freakshow power connector on the other. - Key Features
-
- Robust, ultra-compact 12G-SDI reclocking DA
- Auto-selectable input, dual outputs
- DCI 4K extension up to 246' using Belden 1694A cables
- 722' 3G-SDI / 1740' SD-SDI extension
In the Box Freakshow HD 4K 12G-SDI MSX2-O Microsplit Reclocking DA with Standard Freakshow Power Connector AC Adapter Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Freakshow HD 4K 12G-SDI MSX2-O Microsplit Reclocking DA with Standard Freakshow Power Connector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersFreakshow HD Microsplit Specs | Input | 12G/6G/3G/HD/SD-SDI (Auto-Selectable):
1 x BNC (SMPTE-424, SMPTE-292, SMPTE-259) | | Outputs | 12G/6G/3G/HD/SD-SDI (With Equalization and Reclocking):
2 x BNC (SMPTE-424, SMPTE-292, SMPTE-259) | | Cable Distances | Using Belden 1694A Cable (Belden 1505 Allows Half the Distance):
246' / 75 m via 12G-SDI
328' / 100 m via 6G-SDI
722' / 220 m via 3G-SDI
870' / 265 m via HD-SDI
1740' / 530 m via SD-SDI | | Input Return Loss | -8 dB at 12G, -9 dB at 6G, -13 dB at 3G, -18 dB at HD/SD | | Power Connector | 1 x Standard Freakshow Power Connector | | Output Return Loss | -6 dB at 12G, -8.5 dB at 6G, -15 dB at 3G, -23 dB at HD/SD | | Operating Voltage | 5-36 VDC | | Dimensions | 2.6 x 1.8 x 0.8" / 6.7 x 4.5 x 2.1 cm | | Weight | 2.2 oz / 62 g | | | | Package Weight | 0.9 lb | | Box Dimensions (LxWxH) | 8.3 x 6.8 x 2.4" |
