Product description The FL-1500-2DBLK Floor Box with Divided Bracket (Black) from FSR is a floor box designed for use on wooden stages and in computer floors. It provides a practical method of providing power, audio, and video cable termination. The box is virtually concealed from view when not in use via an integrated cover piece. But even with cabling connected to the unit, it remains unobtrusive thanks to its dual-door design, which includes a smaller cable door within the main door.
The unit ships with a divided bracket designed for use with (2) duplex receptacles and a removable flat plate. It can easily be installed or removed via (3) screws, facilitating the unit's management and maintenance.
The box includes (8) knockouts in total on its lower section for cable runs, (4) on the rear and (4) on the bottom panel. This unit is constructed as a single piece with a welded design, ensuring it will withstand rough working conditions and provide years of reliable use. Note: Please note that (2) of the (8) knockouts on this unit cannot be used with the bracket included with this model. - Floor Box
- Use this convenient floor box to provide an unobtrusive single point of access for video, audio, and power connections.
- Aesthetics
- The box mounts flush with your floor surface and a door-within-a-door design makes for a clean look in and out of use.
- Rugged
- This unit features a single-piece welded design that ensures years of reliable use.
- Inserts
- It includes a divided bracket designed for use with (2) duplex receptacles and a removable flat plate.
In the Box FSR FL-1500-2DBLK Floor Box with Divided Bracket (Black) Floor Box Three-Year Warranty Against Defects in Material & Workmanship Table of Contents
|
Upload User Manual
Have you got an user manual for the FSR FL-1500-2DBLK Floor Box with Divided Bracket in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersFSR FL-1500-2DBLK Specs | Construction | Metal | | Finish | Black | | Dimensions (HxWxD) | 13-1/2 x 9-1/2 x 3/16" (top door section)
11-7/8 x 8 x 6" (box)
1 or 1-1/4" (rear knockouts)
1 or 1-1/4" (bottom knockouts) | | Weight | Not specified by manufacturer | | | | Package Weight | 12.5 lb | | Box Dimensions (LxWxH) | 14.5 x 12.8 x 5.0" |
