User Manual for FSR PWB-290 Display Wall Box Click to enlarge the picture
Contents of the user manual for the FSR PWB-290 Display Wall Box
- Product category: Wall Plates & Installation Boxes FSR
- Brand: FSR
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for FSR Wall Plates & Installation Boxes
|
User manual for the FSR PWB-290 Display Wall Box contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any FSR product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official FSR user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a FSR product will considerably shorten its lifespan!
|
Product description The black PWB-290 Display Wall Box from FSR is designed to be used with an AMX AVB-RX-DXLINK-HDMI Receiver, an AVB-TX-MULTI-DXLINK Multi-Format Transmitter, a DXLF-HDMIRX Fiber Receiver, or a DXLF-MFTX Fiber Transmitter, and a power supply, behind a wall mounted display or a projector. The component and power supply are mounted to a removable bracket which is in turn mounted to the PWB-290 back box.
The back box is installed flush with the wall’s surface, between either wood or steel studs. It includes mounting hardware and a duplex box that can be mounted at either the top or bottom duplex knockout areas on the back box. There are two 1” and 1.25” concentric knockouts on the top and bottom for cable/conduit entry and cable tie slots for cable management (cable ties included). The cover provides convection cooling for the internal components. A slot in the cover facilitates passing cables through for external devices such as displays and is designed to provide strain relief for the cables as they exit. - Rugged 16-gauge steel back box
- Mounting hardware is included
- Connections and cables are hidden behind cover for a neat install
- Removable pass-through enclosure for isolating cables that need to go through the back box via the single-gang knockout
- Multiple knockouts in a variety of sizes
- Compatible with all IPS inserts from FSR
- UL-listed AC back boxes included
In the Box FSR PWB-290 Display Wall Box (Black) Mounting Hardware Duplex Box Cable Ties Limited 1-Year Warranty Table of Contents
|
