User Manual for Furman SM3-PRO 15A BlueBOLT Compact Power Conditioner Click to enlarge the picture
Contents of the user manual for the Furman SM3-PRO 15A BlueBOLT Compact Power
- Product category: Power Distributors & Conditioners Furman
- Brand: Furman
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Furman Power Distributors & Conditioners
 |
User manual for the Furman SM3-PRO 15A BlueBOLT Compact Power contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Furman product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Furman user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Furman product will considerably shorten its lifespan!
|
Product description The SM3-PRO 15A BlueBOLT Compact Power Conditioner from Furman is designed to protect your connected equipment from power surges and dangerous voltage conditions. It is compatible with entertainment systems, digital signage, network equipment hubs, and similar setups. The conditioner filters your AC power for maximum electronic performance and reduces equipment issues with remote hard reboots. The SM3-PRO also provides remote power, energy, network management from any web-enabled device, and visibility on energy usage with cloud-based monitoring and tracking. The conditioner will automatically reboot your network equipment when connectivity is lost and reduce excess energy consumption with scheduled on/off commands. - 3 outlets (2 banks) with front-panel bank-override button and indicator lights
- Two accessory ports for external sensors and triggers
- AVM and Protect-or-Disconnect protection
UPC: 050616010108 In the Box Furman SM3-PRO 15A BlueBOLT Compact Power Conditioner Mounting Kit Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Furman SM3-PRO 15A BlueBOLT Compact Power Conditioner in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersFurman SM3-PRO Specs | Voltage Protection Rating | 330 V L-N, 400 V L-G, 400 V N-G | | Under-Voltage Shutoff | 95 VAC ± 2 VAC | | Over-Voltage Shutoff | 134 VAC ± 2 VAC | | Discharge Current | Nominal: 3000 A | | Maximum Current Rating | 15 A | | Line Voltage | 120 VAC, 60 Hz | | Initial Clamping Level | 200 V | | Energy Dissipation | 1,800 Joules (8/20 µs) | | Networking | BlueBOLT enabled
2-Port ethernet switch
2 x RJ-45
10/100 Base-T | | Filtration | -15.9 dB @ 10 kHz
EMI / RFI Noise Filtration: -43.5 dB @ 100 kHz
-49.3 dB @ 1 MHz | | Dimensions | 7.0 x 10.0 x 1.6" / 17.8 x 25.4 x 4.1 cm (with mounting bracket) | | Weight | 4.8 lb / 2.2 kg | | | | Box Dimensions (LxWxH) | 9.2 x 5.65 x 5.1" |
