User Manual for Garner PD-5 Multiple Hard Drive Destroyer Package with HD-3WXL Hard Drive Degausser and Workstation Click to enlarge the picture
Contents of the user manual for the Garner PD-5 Multiple Hard Drive Destroyer
- Product category: Degaussers & Erasers Garner
- Brand: Garner
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Garner Degaussers & Erasers
|
User manual for the Garner PD-5 Multiple Hard Drive Destroyer contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Garner product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Garner user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Garner product will considerably shorten its lifespan!
|
Product description The PD-5 Multiple Hard Drive Destroyer Package with HD-3WXL Hard Drive Degausser and Workstation from Garner provides a secure way to ensure sensitive data is properly handled according to NSA standards. The package includes the PD-5 Multiple Hard Drive Destroyer with the SSD-1 Solid State/Flash Destroyer Accessory, the HD-3WXL Hard Drive Degausser, the SW-1 Secure Workstation, two color-coded bins, and a recycling container.
The PD-5 Multiple Hard Drive Destroyer has an LCD display, a 9 second cycle for two standard hard drives and the included SSD-1 adds an SSD/Flash Media destruction insert. The PD-5's chassis, motor, and all main components are aluminum and completely recyclable. It has a very unique operation with its automatic High-Torque Sensor that allows the crushing wedge to move at high speed to the media and then optimize speed for maximum crushing power. The PD-5 automatically destroys all formats and sizes of hard drives including Network SCSI and IDE Drives up to 1.66" in height. Since the PD-5 doesn't rely on software, all working and non-working hard drives put in the chamber will be destroyed in just 9 seconds. A simple push of a button will ensure complete hard drive destruction. The included SSD-1 Solid State Destroyer sanitizes solid state media such as SSD, Flash, Compact Flash, USB drives, and controller boards for hybrid HDD's. Over 90 pins pierce the solid state media from top and bottom causing both perforation and waffling, which destroys the individual memory chips.
The included HD-3WXL Hard Drive Degausser erases hard drives and high coercivity tape media including all formats of LTO (1, 2, and 3), SuperDLT I & II, DLT, 9940, 3592, AIT, 8mm, and more, all without any adapters. With a continuous duty rating (no cooling necessary) and 10 second cycle time, even large quantities of media can be erased in a short period of time. An additional benefit of degaussing is that there will be no need to purchase additional blanks tapes. Erased tapes can be used as many times as they can be re-serviced. And, inasmuch as the tapes are now blank, the integrity of the new, overwritten programs will not be compromised. Note: Hard Drives and Flash chips are not reusable after having been destroyed. - PD-5 with SSD-1:
-
- The PD-5 can crush up to one full height 1.66" hard drive, two standard 1" hard drives, or eight laptop drives at a time
- The SSD-1 can destroy up to one standard SSD, one HDD controller board, or as many flash, compact flash, USB thumb drives, and flash chips that fit into the destruction chamber at a time
- Fast crushing time at 9 seconds
- SSD-1 Option enables you to destroy SSD's, Flash, and USB thumb drives
- 32 Character LCD display with counter
- Lightweight at 72 lb
- Crushes multiple drives at a time
- Quiet, office friendly design
- No hydraulics
- All aluminum chassis and main components
- HD-3WXL Hard Drive Degausser:
-
- Fast, safe, and complete erasure
- Simple one button operation
- Conveniently operates from a 120 VAC outlet
- Compact and quiet design easily operates in any office environment
- User-friendly, simply slide your media into the slot on the left side of the HD-3WXL and push the "Erase" button, within ten seconds your media will be completely erased and will automatically slide out of the right side
- Takes up just over one square foot of space
- Produces an erasing field several times stronger than the erasing fields produced by the read/write heads in hard drives and tape drives which makes for a deeper and more efficient erasure than that provided by software based wiping programs
- Kit Meets Government Mandates:
- Government mandates require complete elimination of sensitive information stored on magnetic media prior to disposal
- NSA/CSS SDDM 9-12
- PCI DSS (Payment Card Industry) Data Security Standard
- NIST (National Institute of Standards and Technology) Guidelines for Media Sanitization
- NIST SP 800-36
- NIST SP 800-88
- HIPAA (Health Information Portability and Accountability Act)
- PIPEDA (Personal Information Protection and Electronic Documents Act)
- GLBA (Gramm-Leach-Bliley Act)
- California Senate Bill 1386
In the Box Garner PD-5 Multiple Hard Drive Destroyer Package with HD-3WXL Hard Drive Degausser and Workstation PD-5 Physical Hard Drive Destroyer SSD-1 Solid-State Destroyer Accessory for PD-5 Destroyer xtrxbaxzuwbsfd HD-3WXL Hard Drive and Tape Degausser Kit with SCAN-1 Report Generator SW-1 Secure Workstation 2 x Color-Coded Bins Blue Recycle Container Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Garner PD-5 Multiple Hard Drive Destroyer Package with HD-3WXL Hard Drive Degausser and Workstation in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersGarner DDR-35SSD Specs | | | Power Supply | 100-240 V ±5%, 50 or 60 Hz | | Power Consumption | 1.5 A Operating, 7 A Max @ 120 VAC | | Operating Time | Crushing: 9 seconds | | Operating Temperature | 41 to 104 °F (5 to 40 °C) | | Operating Humidity | 10 to 80% (non-condensing) | | Dimensions | 18.0 x 7.0 x 14.5" (45.0 x 17.8 x 36.8 cm) | | Weight | 72 lb (32.7 kg) | | | | Dimensions | Destruction Chamber: 0.5 x 3.0 x 5.0" (1.3 x 7.6 x 12.7 cm)
Overall Dimensions: 2.75 x 5.00 x 6.35" (6.99 x 12.70 x 16.13 cm) | | Weight | 8.5 lb (3.9 kg) | | | | System | Capacitive discharge | | Erasure | Time: 10 seconds per hard drive | | Magnetic Field Strength | 9,000 Oe | | Media Type | Full height hard drives, standard 1" high hard drives, laptop drives, 2.5 type HDD, 3.5 type HDD, DLT, LTO, 3490 form factors, and more | | Duty Cycle | Continuous | | Power Requirements | 120 VAC ±5%, 50/60 Hz | | Power Consumption | Standby: 0.2 A
Charging: 8.0 A
Erasing: 0.5 A | | Operating Temperature | 41 to 104°F (5 to 40°C) | | Operating Humidity | 10 to 40% (without condensation) | | Dimensions | Without Slide: 12.25 x 13.13 x 18.75" (31.12 x 33.34 x 47.63 cm)
With Slide: 12.25 x 22.63 x 18.75" (31.12 x 57.47 x 47.63 cm)
Erasing Area: 6.75 x 4.50 x 1.80" (17.15 x 11.43 x 4.57 cm) | | Weight | 75 lb (25 kg) |
