User Manual for Gefen UHD 4K 600 MHz 1x2 HDMI Splitter with HDR Support Click to enlarge the picture
Contents of the user manual for the Gefen UHD 4K 600 MHz 1x2
- Product category: Distribution Amplifiers (DA's) Gefen
- Brand: Gefen
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Gefen Distribution Amplifiers (DA's)
|
User manual for the Gefen UHD 4K 600 MHz 1x2 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Gefen product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Gefen user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Gefen product will considerably shorten its lifespan!
|
Product description Provided by third party: Designing systems capable of distributing 4K Ultra High Definition media requires support for the content of today, and headroom for the content of tomorrow. Gefen's EXT-UHD600 Series of splitters take HDMI 2.0 to its highest specification of 4K 60 Hz at 4:4:4 chroma subsampling, along with HDR (High Dynamic Range) support. They go beyond the requirements of typical 4K systems, delivering stunning Ultra HD and DCI/Cinema picture up to 4096 x 2160 pixels at 60 frames per second without subsampling color. This ensures that the scene shown on the display is every bit as brilliant as the picture that the camera captured. HDR lets every subtle nuanced gradation of each pixel play out across the screen in immersive clarity. Gefen's EXT-UHD600 product line creates a seamless bridge between the digital media of yesterday, today, and tomorrow. Supporting the digital rights management standard for Ultra High Definition content, HDCP 2.2, as well as the legacy HDCP 1.4, Gefen's EXT-UHD600 products can handle the signal routing needs for both existing and new components in commercial and residential AV systems. Highest performance multichannel digital audio including 7.1 channels of LPCM and HBR (High Bit Rate) digital audio formats such as Dolby Atmos®, Dolby® TrueHD, DTS:X™, and DTS-HD Master Audio™ are also supported. These splitters have been specifically designed to support multiple layers of cascading** for flawless performance in large video distribution and signage applications, supporting up to hundreds of displays. Gefen's exclusive Long Reach Power (LRP) feature provides 5V at 500 mA (as opposed to HDMI standard 55 mA) on pin 18 of HDMI outputs 1 and 2. This enhanced current capability enables select extender devices to be powered through their HDMI input port without the need for an external power supply. Gefen's EXT-UHD600 product line was designed to work with Gefen's Syner-G™ software suite. EDID and HDCP management, status monitoring, and firmware updates can be done in minutes using the Gefen Syner-G™ software. The Gefen EXT-UHD600-12 splitter features a low profile, compact, and surface-mountable enclosure that can fit in tight places. It also accommodates Gefen locking HDMI cables for secure connections. UPC: 888814272352 In the Box Gefen UHD 4K 600 MHz 1x2 HDMI Splitter with HDR Support (4K, 60 Hz, 4:4:4) Ultra HD 600 MHz 1:2 Splitter for HDMI w/ HDR 1 x 6 ft locking HDMI cable 1 x 5V Power Supply w US/EU/UK/AU plugs 2 x Surface Mounting L-Brackets 4 x M3 6 mm Machine screws for Mounting the L-Brackets to unit 2 x 6-32 5 mm Machine screws for mounting the unit to Gefen EXT-RACK-1U-GRY (available separately) 4 x Self-Adhesive Rubber Feet 1 x Quick-Start Guide 2 Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Gefen UHD 4K 600 MHz 1x2 HDMI Splitter with HDR Support in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersGefen EXT-UHD600-12 Specs | | | Maximum Frequency | 600 MHz | | | | Maximum Video Resolution | 4096 x 2160 | | | | HDMI In | Yes | | HDMI Out | Yes | | USB | Yes | | Number of HDMI Inputs | 1 | | Number of HDMI Outputs | 2 | | | | Height | 1" | | Width | 8.4" | | Depth | 3.7" | | Weight (Approximate) | 12 oz | | | | Package Weight | 2.2 lb | | Box Dimensions (LxWxH) | 12.047 x 6.063 x 4.095" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 96 owners. Add your rating and experience with the product.
