Product description

Smart Fan 5
• Smart Fan 5 allows you to interchange your fan headers to reflect different thermal sensors at different locations on the motherboard.

Hybrid Fan Pin Headers
• Hybrid Fan Headers detect whether the cooling device uses PWM or Voltage mode and automatically switches settings accordingly. It supports up to two amps with built-in overcurrent protection.

Smart Fan 5 Software
• Choose from quiet to full speed modes to match your system usage scenario. For each fan or pump, you can use the intuitive fan curve to define trigger thresholds and corresponding fan speeds.

Interoperable Sensors and Fans
• Each fan can be customized to operate at different speeds according to any defined temperature source input (except the CPU fan).

Fan Curve
• You can customize fan curves based on specific temperatures with the intuitive graphical UI.

BIOS Interface
• The enhanced BIOS interface can set triggers based on different temperature sensors on the board, fan curve definition, and the temperature interval setting, which can prevent fan rotation noise caused by sudden temperature change.

Immersive VR Gaming Experience
• The recommended configuration for VR gaming PC is by using a NVIDIA GTX 1050/AMD R9 290 or greater graphics card that has a compatible HDMI 1.3 video output, an Intel i5-7600K equivalent or greater CPU, a Gigabyte X99/Z270/Z170/H170/B150 motherboard, a memory of 8GB RAM or greater, three USB 3.0 ports and one USB 2.0 port or greater, and a Windows 7 SPI 64-bit or newer operating system.

Realtek GbE LAN with cFosSpeed Internet Accelerator Software
• Realtek Gigabit LAN features cFosSpeed, a network traffic management application which helps improve network latency and maintain low ping times to deliver responsiveness in crowded LAN environments.

NVMe PCIe Gen3 x4 2280 M.2 Connector
• The M.2 solution offers fast storage performance and support for both PCIe and SATA interface for M.2 SSD devices.

Two-Way CrossFire Multi-Graphics
• Multi-graphics configuration offers graphics performance with high frame rates for gaming enthusiasts without compromising on resolution. Graphics cards are sold separately.

Supports DDR4 XMP Up to 3866MHz
• XMP profiles (sold separately) automatically modify the timings of the supported memory modules to work with your CPU to achieve increased performance. This platform ensures proper compatibility with profiles up to 3866MHz. To attain this performance boost you should ensure that your memory module is XMP capable and that the XMP function is activated and enabled on your motherboard. XMP Profile support may vary depending on memory module. Please visit www.gigabyte.com to see the complete validated memory support list.

Patented Double Locking Bracket
• The first lock is inserted from the top for better retention and the second lock is soldered for a strong bond.

Anti-Sulfur Resistor Design
• The resistors are equipped with an anti-sulfur design which prevents chemical change from causing them to open or short.

High-Quality Onboard Audio Design
• This motherboard delivers high-quality sound resolution and sound expansion to create realistic sound effects for professional gamers. It features audio noise guard with LED trace path lighting and high-end audio components.

Refreshed BIOS Easy, Smart, and Friendly
• The BIOS has a new GUI and easy-to-use functionalities which are essential for users during initial setup to allow for optimal settings.

APP Center
• The APP center allows you to launch all Gigabyte apps installed on your system, check related updates online, and download apps, drivers, and BIOS.

EasyTune
• EasyTune is an easy-to-use interface that allows you to fine-tune your system settings or adjust system and memory clocks and voltages in a Windows environment. Smart Quick Boost will automatically overclock your system and give you an added performance boost.

Overclocking
• Overclocking features boost your frame rates.

System Information Viewer
• System Information Viewer is a central location that gives you access to your current system status. You can monitor components such as the clocks and processor, set your preferred fan speed profile, create alerts when temperatures get too high, and record your system's behavior.

@BIOS
• The @BIOS app allows you to update your system's BIOS from within Windows using a graphical user interface. @BIOS can automatically download the latest version from the GIGABYTE servers or you can update your BIOS from a file on your computer. @BIOS also allows you to save your current BIOS to a file, recover your previous BIOS from an image, and backup your BIOS to an image.

3D OSD
• 3D OSD automatically detects and displays your system information during games which allows you to get a hold of your system information without switching between screens.

Patented DualBIOS (UEFI) Design
• This Ultra Durable motherboard has DualBIOS which protects you from BIOS failure due to virus, hardware malfunction, improper OC settings, or power failure during the update process by featuring a main BIOS and a backup BIOS.

G-Connector Design
• The G-connector allows you to connect all the FP cables at once.

4K Ultra HD Support
• This motherboard provides native 4K support with integrated Intel HD graphics via HDMI. 4K resolution utilizes approximately 4,000 pixels on the horizontal axis. The 4K display support is dependent on your CPU.

HDMI Next Generation Multimedia Interface
• HDMI is a high-definition multimedia interface which provides up to 5Gb/s video transmitting bandwidth and 8-channel high quality audio through a single cable. It can transmit superior, uncompressed digital video and audio. HDMI ensures rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. In addition, HDMI is compatible with HDCP (High-bandwidth Digital Content Protection), allowing the playback of Blu-ray/HD DVD and other protected media content.

XSplit Gamecaster & Broadcaster
• Fully optimized social media integration is ready for real-time chats which keeps you notified yet focused in the game. With one click you can stream your gameplay to Twitch. A 14-day XSplit Gamecaster + Broadcaster premium license is included.

TriDef SmartCam Custom Stream Modding
• TriDef SmartCam software allows you to remove backgrounds without using a green screen. Through the SmartCam application you can apply live filters and fully control your background, not only while streaming, but also through other video applications such as Skype. A one month TriDef SmartCam license is included.
