Product description - From the Engineers | The Goal Zero Sherpa 100AC Power Bank
- Goal Zero | Sherpa 100AC
Portable power for laptops, phones, tablets, cameras, and much more—the Goal Zero Sherpa 100AC Power Bank makes it possible to charge and run your devices on the plane, in the field, and off the grid. This two-pound, 7.5 x 5.7 x 1" power bank comes with the outputs you need to charge even power-hungry devices quickly. The Sherpa 100AC stores and delivers enough power to charge two laptops, three tablets, 10 smartphones or 18 POV cameras, using a standard 100-watt AC outlet, USB-C Power Delivery ports, a 5V, 2.4A USB-A port, and a wireless phone charging pad. The power bank itself can be recharged from AC power, USB-C, or a compatible solar panel. -
- Two 60-watt USB-C Power Delivery ports for speedy charging of laptops, phones, and more
- 100-watt AC inverter with three-prong plug for wall-style charging of computers, camera batteries, etc.
- Qi Wireless Charging for your smartphone
- Fast 5V, 2.4A USB-A port
- Lightning, Micro USB, USB-C, and USB-C to USB-C cables
- Recharges via USB-C PD (2.5 hours), AC wall charger (3 hours) (requires #98051 Sherpa Power Supply, sold separately), USB-A 2.4A (9 hours), Boulder 50 solar panel (4-8 hours), Nomad 28 solar panel (6-14 hours), Nomad 14 solar panel (12-28 hours)
- 94.7Wh Li-ion NMC battery (14.8V, 6400mAh)
- Compact at 7.5 x 5.7 x 1", lightweight at 2 pounds
UPC: 847974006054 In the Box GOAL ZERO Sherpa 100AC Power Bank USB-C to USB-C Cable Lightning Cable Micro-USB Cable 30" USB-C Cable Limited 6-Month Warranty (Battery) Limited 1-Year Warranty (Power Bank) Table of Contents
|
Upload User Manual
Have you got an user manual for the GOAL ZERO Sherpa 100AC Power Bank in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersGOAL ZERO 22050 Specs | Battery | Li-Ion NMC | | Capacity | 94.7 Wh (14.8 VDC, 6400 mAh) | | Input Power / Charge Time | USB-C PD (60 W): 2.5 Hours
AC (45 W): 3 Hours
USB-A (2.4 VDC): 9 Hours
Boulder 50 Solar Panel: 4-8 Hours
Nomad 28 Solar Panel: 6-14 Hours
Nomad 14 Solar Panel: 12-28 Hours
12 VDC: 3 Hours
110 VAC: 3 Hours
GOAL ZERO Nomad 27: 4-8 Hours
GOAL ZERO Nomad 13: 8-16 Hours | | Output Ports | Wireless Qi (Output): 5 W
USB-A: 5 VDC, up to 2.4 A (12 W max), Regulated
USB-C PD ports (Input/Output): 5 VDC, 9 VDC, 12 VDC, 15 VDC, 20 VDC up to 3 A (60 W Max), Regulated
AC Inverter (Output): 110 VAC, up to 0.9 A (100 W Max), 60 Hz, Modified Sine Wave
Charging Port (Input, 8 mm): 14-22 VDC (50 W Max) | | Operating temperature | 32-104°F / 0-40°C | | Dimensions | 7.5 x 5.7 x 1" / 19 x 2.54 x 14.4 cm | | Weight | 2 lb / 0.9 kg | | | | Package Weight | 3.12 lb | | Box Dimensions (LxWxH) | 10.4 x 7.7 x 2.0" |
Rating70% users recommend this product to others. And what about you?
This product has already been rated by 58 owners. Add your rating and experience with the product.
Discussion
Ask our technicians if you have a problem with your settings,
or if anything is unclear in the user manual you have downloaded.
You can make use of our moderated discussion.
The discussion is public and helps other users of our website who may be encountering similar problems.
Post new comment to GOAL ZERO Sherpa 100AC Power Bank
| Subject: My sherpa100AC stoped working. While charging my iPad. | | Date: 14.12.2021 05:51:44 | Name: Andrew Schultz | | While charging my iPad using the inverter like I have many of times. It just stoped working. It will no longer accept a charge. And when I get it to turn on. As soon as I press the ac button to turn the inverter on it shuts off. And won’t turn back on for a minute or two. Please help as this is my absolute favorite battery pack I own. | | Post reply |
