User Manual for Gra-Vue SD-SDI Delay, SD-SDI Maximum Delay 90S Click to enlarge the picture
Contents of the user manual for the Gra-Vue SD-SDI Delay, SD-SDI Maximum Delay
- Product category: Video & Audio Delays Gra-Vue
- Brand: Gra-Vue
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Gra-Vue Video & Audio Delays
 |
User manual for the Gra-Vue SD-SDI Delay, SD-SDI Maximum Delay contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Gra-Vue product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Gra-Vue user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Gra-Vue product will considerably shorten its lifespan!
|
Product description The Gra-Vue SD-SDI Delay, SD-SDI Maximum Delay 90S is suitable for high resolution SDI signal delay. It can delay 1 digital serial signal (supports SDI with embedded audio) with the requisite technology that allows delay time to be adjusted frame by frame. The maximum delay time is up to 10 minutes for SD-SDI. There are convenient function buttons and an LCD display on the front panel. - Maximum delay time is up to 10 minutes for SD-SDI
- Advanced FPGA + DSP processing technology
- Accurately adjusts delay time, frame by frame
- Supports H / V phase adjustment
- Supports monitoring the signal before delay
- AUX video input or audio mute to avoid abnormal video signal output
- Provides a quick switch between bypass and delay signal
- 4x AES Input and output (sold separately)
- Program loop-out when power off
- 1U chassis structure, redundant power supplies
- Supports SNMP (Simple Network Management Protocol)
In the Box Gra-Vue SD-SDI Delay, SD-SDI Maximum Delay 90S Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Gra-Vue SD-SDI Delay, SD-SDI Maximum Delay 90S in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersGra-Vue VIO DELAY-SD600S Specs | Signal Input | PGM: 1x SD-SDI, BNC, 75 Ω
AUX: 1x SD-SDI, BNC, 75 Ω
Standard SMPTE 259M 270 Mb/s | | Input | BB Reference Input: 1x CVBS, BNC, 75 Ω | | Signal Output | Interface: 3x SD-SDI, BNC, 75 Ω (2 after-delay outputs 1 of 2 for loop-out without power, 1 before-delay output)
Standard: SMPTE 259M 270 Mb/s | | Control Interface | RS-232: 26-pin female D
Network: Port RJ45, 1000MBase T Ethernet | | Power | 2x 120 W, 100 to 256 VAC, 50 to 60 Hz | | Dimensions | 17.32 x 19.01 x 1.77" (440.00 × 483.00 × 45.00 mm) | | | | Package Weight | 16.53 lb | | Box Dimensions (LxWxH) | 24.0 x 24.0 x 8.0" |
