User Manual for Gra-Vue XIO 9030HDEMB-2AES-FS-X Embedder Click to enlarge the picture
Contents of the user manual for the Gra-Vue XIO 9030HDEMB-2AES-FS-X Embedder
- Product category: Embedders & De-Embedders Gra-Vue
- Brand: Gra-Vue
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Gra-Vue Embedders & De-Embedders
 |
User manual for the Gra-Vue XIO 9030HDEMB-2AES-FS-X Embedder contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Gra-Vue product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Gra-Vue user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Gra-Vue product will considerably shorten its lifespan!
|
Product description The Gra-Vue XIO 9030HDEMB-2AES-FS-X Embedder embeds 2-channel AES balanced audio signals into a single HD/SD-SDI signal, and outputs 2 identical serial digital signals with embedded audio and frame sync processing. The embedded audio group can be selected though the DIP switch. Not only that, the embedded mode of audio channels is also selectable, such as total embedding left or right channel, following input channels and so on.The embedder supports 625i 50, 525i 60, 720p, 1080i, 1080p, 1080psf, and automatic detection of input format. It provides automatic signal equalization for up to 100m (Belden 1694A), which can improve the signal quality and reduce the signal loss caused by long distance transmission of input source. The green LED lights on the module indicate the status of input signal and power supply. This embedder supports SNMP and it can be managed and monitored real-time by XIO NET (the Network Management Module) via Ethernet. - Supports 625i 50, 525i 60, 720p, 1080i, 1080p, 1080psf, and automatic detection of input format
- Provides automatic signal equalization for up to 100m (Belden 1694A)
- Provides 3 kinds of sync modes: INT, single EXT, and Global EXT
- Green LED lights to indicate the status of signals and power supply
- Supports SNMP and can be real-time managed and monitored by XIO NET via Ethernet
- Used in broadcasting system, studios, and other professional fields
- Provides an individual Ref interface and frame sync processing
In the Box Gra-Vue XIO 9030HDEMB-2AES-FS-X Embedder Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Gra-Vue XIO 9030HDEMB-2AES-FS-X Embedder in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersGra-Vue XIO 9030HDEMB-2AES-FS Specs | | | Interface | 1 x HD/SD-SDI, BNC | | Impedance | 75 Ω | | Resolution | SD: 625i50, 525i60HD: 1080i50/60, 720p50/60, 1080p24/25/30, 1080psf24, SMPTE 259M-C: 270 Mb/s, SMPTE 292M: 1.485 Gb/s | | Maximum Length | < 328.08' (100 m) (Belden 1694 A) | | | | Interface | 4 x 3 pin, balance | | Maximum Level | 0 dBFs (+24 dBu) | | | | Interface | 2 x HD/SD-SDI, BNC | | Format | SMPTE 259M-C: 270 Mb/sSMPTE 292M: 1.485 Gb/s | | Level | 800 mV ± 5% | | Jitter | < 0.2 UI (100 KHz) | | Status Indicator | Signal status indicator, power indicator | | Reference Input | Analog composite video | | Interface | 1 x Ref, BNC | | Standard | PAL / NTSC | | | | Package Weight | 1.6 lb | | Box Dimensions (LxWxH) | 18.0 x 9.0 x 4.0" |
