Product description The NVISION CR6400 Digital Audio Router from Grass Valley fits 64 inputs and 64 outputs in a slim 2 RU frame and is suitable for small facilities, trucks, stadiums or any location that is space-constrained such as editing suites, post-production, and playout facilities. The robust matrix supports its 64-squared matrix, thanks to the introduction of DIN connectors rather than the typical BNC connectors. This durable router contains a hot swappable module for easy serviceability and is tested for performance from 32 to 113°F.The space-saving nature of the router provides the power and flexibility of a larger, enterprise-class router, along with the flexibility to fit into most complex workflows, integrating easily with multiviewers, signal processing platforms, and master control switchers. -
- High-density 64 x 64 matrix in 2 RU
- Optional, redundant power supply available
- Broadcast quality components for high quality signal performance
- Rugged design to smoothly handle both movement and extreme temperature
- Local control panel option mounts to the front of the router or can be used for remote access using an RP32
- Operates with or without external control system
- Field serviceable modules are hot swappable
- Crosspoint and control card
Input and output cards
Fan module
In the Box Grass Valley NVISION CR6400 Digital Audio Router Limited 15-Month Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Grass Valley NVISION CR6400 Digital Audio Router in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersGrass Valley CR6464-AES Specs | | | Signal Type | AES3id (2 mono channels per input) | | Sample Rate | 32 to 192 kHz | | Input Level | 1 V p-p nominal into 75 Ohms | | Input Range | 200 mV p-p to 3 V p-p into 75 Ohms | | Input Return Loss | < -25 dB, from 100 kHz to 6 MHz | | Input Connectors | DIN, 75 Ohms | | | | Signal Type | AES3id (2 mono channels per input) | | Sample Rate | Async, 32 to 192 kHz
Sync, 48 kHz | | Output Level | 1 V p-p ±10% into 75 Ohms | | Offset | 0.0 VDC ±50 mVDC, AC coupled | | Rise / Fall time | 4 to 8 ns | | Output Jitter | < 1 ns, in synchronous mode | | Output Return Loss | < -25 dB, from 100 kHz to 6 MHz | | Isolation | Output-to-Output: > 40 dB, from 100 kHz to 6 MHz | | Output Connectors | DIN 1.0/2.3 | | | | Power | 2 Connectors, DIN 4 | | Ethernet | 1 Connector, 10/100BaseT, RJ45 jack | | RS-422 | 1 Connector, 9-pin D type, usage determined by software, SMPTE 207M | | Reference Video | 2 Connectors, BNC, 75 Ohms | | Control Panel | Two 2 x 60 connectors | | Removable | 4 x I/O card slots at rear
1 x Crosspoint card slot at rear
1 x Control card slot at rear
1 x Fan module removable at the front | | Grounding Terminal | Copper, accepts 14-6 AWG | | Power Supply | 2 VDC ± 10%, 5 A | | Power Consumption | 55 W maximum | | Dimensions | Height: 3.5" (88 mm), fits EIA 2 RU 3.5" (89 mm)
Width: 19" (48 cm)
Depth: 10 ±0.01" (26 ±0.25 cm), enclosure < 11" (27 cm) from front of rack to extended ground screw | | Weight | 11.8 lb (5.35 kg) without I/O cards, without control panel
15.3 lb (6.94 kg) with 4 x I/O card, without control panel |
