User Manual for Hanwha Techwin SNB-9000 4K UHD 12MP Network Camera Click to enlarge the picture
Contents of the user manual for the Hanwha Techwin SNB-9000 4K UHD 12MP
- Product category: Wired IP Cameras Hanwha Techwin
- Brand: Hanwha Techwin
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Hanwha Techwin Wired IP Cameras
 |
User manual for the Hanwha Techwin SNB-9000 4K UHD 12MP contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Hanwha Techwin product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Hanwha Techwin user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Hanwha Techwin product will considerably shorten its lifespan!
|
Product description The SNB-9000 4K UHD 12MP Network Camera from Samsung features a 1/2.3" progressive scan CMOS sensor that captures images up to a resolution of 4000 x 3000. Thanks to the automatic IR cut filter, the camera can capture color images with sufficient lighting and B&W images in the dark. The camera comes with a host of features, such as simple focus and intelligent video analytics. - Multi-Streaming
- This network camera can display videos in different resolutions and qualities simultaneously using different codecs
- Web Browser-Based Monitoring
- Use a web browser to display images in a local network environment
- Alarm
- When an event occurs, video is either sent to the email address registered by the user, sent to the FTP server, saved in a microSD card or NAS, or a signal is sent to the alert output terminal. 1
Please Note: microD card and NAS available separately close - Tampering Detection
- Detects tampering attempts on video monitoring
- Motion Detection
- Detects motion from the camera's video input
- Intelligent Video Analysis
- Analyzes video to detect logical events of specified conditions from the camera's video input
- Face Detection
- Detects faces from the camera's video input
- Audio Detection
- Detects sound louder than a certain level specified by user
- Smart Codec
- Adaptively applies codecs for a portion of the camera's field of view to improve the quality of such area specified by user
- Auto Detection of Disconnected Network
- Detects network disconnection before triggering an event
- ONVIF Compliance
- This product supports ONVIF Profile S
In the Box Hanwha Techwin SNB-9000 4K UHD 12MP Network Camera (No Lens) Software CD Table of Contents
|
Upload User Manual
Have you got an user manual for the Hanwha Techwin SNB-9000 4K UHD 12MP Network Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHanwha Techwin SNB-9000 Specs | | | Imaging Device | 1/2.3" CMOS | | Total Pixels | 12 MP (4168 x 3062) | | Effective Pixels (H x V) | 4072 x 3046 | | Scanning System | Progressive | | Minimum Illumination | Color: 0.28 lux (1/30 sec, f/1.2), 0.01 lux (1 sec, f/1.2)
B/W: 0.03 lux (1/30 sec, f/1.2), 0.001 lux (1 sec, f/1.2) | | S / N Ratio | 50 dB | | Video Output | CVBS : 1.0 V p-p / 75 Ohms composite, 720 x 480(N), 720 x 576(P), for installation
BNC type | | | | Focus Control | Simple focus / manual
Remote control via network, button control (manual, simple focus, day & night) | | Lens Type | Manual / DC auto iris | | Mount Type | C / CS | | | | Camera Title | Off / On (Display up to 20 characters) | | Day & Night | Auto (ICR) / color / B&W / external / schedule | | Backlight Compensation | Off / BLC / HLC | | Contrast Enhancement | SSDR (Samsung super dynamic range) (off / on) | | Digital Noise Reduction | SSNRIII (2D + 3D noise filter) (off / on) | | Motion Detection | Off / on (4ea 4 points polygonal zones) | | Privacy Masking | Off / On (32 zones of rectangular) | | Gain Control | Off / low / middle / high | | White Balance | ATW / AWC / manual / indoor / outdoor / mercury | | Electronic Shutter Speed | Minimum / maximum / anti-flicker (1 to 1/12,000 sec) | | Digital PTZ | 8x (Preset, group) | | Flip / Mirror | Off / on | | Intelligent Video Analytics | Tampering, virtual line, enter / exit, (Dis)appear, audio detection, face detection with metadata (to NVR / SSM recording server) | | Alarm I/O | Input x 2 / output x 1 | | Remote Control Interface | RS-485 | | RS-485 Protocol | Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch | | Alarm Triggers | Motion detection, tampering, audio detection, face detection, video analytics, alarm input, network disconnection | | Alarm Events | File upload via FTP and email, notification via email, TCP and HTTP
Local storage (SD/SDHC/SDXC) recording at network disconnect & event (Alarm triggers) or NAS recording at event (Alarm triggers), external output | | | | Ethernet | RJ45 (10/100/1000BASE-T) | | Video Compression Format | H.264 (MPEG-4 part 10/AVC), MJPEG | | Resolution | 4000 x 3000, 4096 x 2160, 3840 x 2160, 2592 x 1944, 2048 x 1536, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 720 x 576, 720 x 480, 704 x 576, 640 x 480, 640 x 360, 320 x 240 | | Maximum Frame Rate | H.264
3840 x 2160 to 320 x 240 @ 30 fps
4096 x 2160 @ 25 fps
4000 x 3000 @ 20 fps
MJPEG
800 x 600 to 320 x 240 @ 20 fps
1024 x 768 to 1920 x 1080 @ 15 fps
2048 x 1536 to 2592 x 1944 @ 10 fps
3840 x 2160 to 4000 x 3000 @ 5 fps | | Smart Codec | Area-based method | | Video Quality Adjustment | H.264: Target bit rate level control
MJPEG: Quality level control | | Bitrate Control Method | H.264: CBR or VBR
MJPEG: VBR | | Streaming Capability | Multiple streaming (Up to 3 profiles per each resolution mode) | | Audio In | Selectable (Mic in / Line in)
Max Output Level: 1 Vrms | | Audio Out | Line out (3.5 mm mono mini jack) | | Audio Compression Format | G.711 u-law/G.726 selectable, G.726 (ADPCM) 8 kHz, G.711 8 kHz
G.726: 16, 24, 32, 40 kb/sec | | Audio Communication | Bi-directional audio | | IP | IPv4, IPv6 | | Protocol | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour | | Security | HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, user access log, 802.1x authentication | | Streaming Method | Unicast / multicast | | Maximum User Access | 15 users (Maximum 5 users each profile) | | Edge Storage | microSD / SDHC / SDXC (128 GB) Motion images recorded in the SD / SDHC / SDXC memory card can be downloaded microSD card available separately | | Application Programming Interface | ONVIF profile S, SUNAPI (HTTP API) v2.0, SVNP 2.0 | | Webpage Language | English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Romanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish | | Web Viewer | Supported OS: Windows XP / Vista / 7 / 8, Mac OS X 10.7 Supported Browser: Microsoft Internet Explorer (Version 8 to 11), Mozilla Firefox (Version 9 to 19), Google Chrome (Version 15 to 25), Apple Safari (Version 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7), Mac OS X only | | Software | Central Management: SmartViewer, SSM | | | | Operating Temperature / Humidity | 14 to 131°F (-10 to 55°C) / <90% RH | | Storage Temperature / Humidity | -22 to 140°F (-30 to 60°C) / <95% RH | | | | Input | Voltage / Current: 24 VAC ±10%, 12 VDC ±10%, PoE (IEEE802.3af, class3) | | Power Consumption | 12.5 W (24 VAC, 50 to 60 Hz) maximum
12 W (12 VDC) maximum
12W (PoE, class 3) maximum | | | | Material | Aluminum | | Dimensions (W x H x D) | 3.08 x 2.65 x 5.13" (7.83 x 6.73 x 13.04 cm) | | Weight | 1.09 lb (0.49 kg) | | | | Package Weight | 1.55 lb | | Box Dimensions (LxWxH) | 8.3 x 4.8 x 4.2" |
