User Manual for Hanwha Techwin WiseNet X Series XNV-6011W 2MP Outdoor Network Dome Camera Click to enlarge the picture
Contents of the user manual for the Hanwha Techwin WiseNet X Series XNV-6011W
- Product category: Wired IP Cameras Hanwha Techwin
- Brand: Hanwha Techwin
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Hanwha Techwin Wired IP Cameras
|
User manual for the Hanwha Techwin WiseNet X Series XNV-6011W contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Hanwha Techwin product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Hanwha Techwin user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Hanwha Techwin product will considerably shorten its lifespan!
|
Product description Keep a watchful eye on your property with the white WiseNet X Series XNV-6011W 2MP Outdoor Network Dome Camera from Hanwha Techwin. Equipped with a 1/2.8" 2MP CMOS sensor and a 2.8mm fixed lens, the XNV-6011W captures video at resolutions up to 1920 x 1080 at 60 fps in a 112 x 62° field of view. The camera has an automatic digital IR cut filter and offers image enhancement features including wide dynamic range and automatic white balance for capturing images in varying lighting conditions. PoE enables you to run just one wire for both data and power while ONVIF compliance ensures compatibility with a wide range of surveillance devices. - Up to 2MP (1920 x 1080) resolution
- Built-in 2.8mm fixed lens
- Up to 60 fps at all supported resolutions (H.265/H.264)
- H.265, H.264, and MJPEG video compression for efficient storage and bandwidth use
- WiseStream II technology dynamically controls encoding, balancing quality and compression according to movement in the image
- 150 dB wide dynamic range
- Vido analytics including loitering detection, directional detection, fog detection, defocus detection, digital auto tracking, heatmaps, people counting, queue management, tamper detection, motion detection, and handover
- SD/SDHC/SDXC memory slot for edge storage supports up to 256GB (SD/SDHC/SDXC cards available separately)
- PoE technology for easy, clutter-free installation
- Hallway view for monitoring vertical areas such as corridors, hallways, tunnels, and aisles
- Integrated Lens Distortion Correction (LDC) technology
- IP66 and NEMA4X rated for outdoor use
- IK10-rated vandal resistance
In the Box Hanwha Techwin WiseNet X Series XNV-6011W 2MP Outdoor Network Dome Camera Software CD Cable for Testing Monitor Template 2 x Tapping Screws 2 x Machine Screws L Wrench Plastic Anchor RJ45 Waterproof Accessory Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Hanwha Techwin WiseNet X Series XNV-6011W 2MP Outdoor Network Dome Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHanwha Techwin XNV-6011W Specs | | | Sensor | 2 MP 1/2.8" CMOS | | Focal Length | 2.8mm | | Maximum Aperture | f/2 | | Zoom | Digital: 24x | | Lens Field of View | Horizontal: 112°
Vertical: 62° | | IR Cut Filter | Digital | | Day/Night | Yes | | Minimum Illumination | Color: 0.055 Lux
B&W: 0.055 Lux | | Shutter Speed | 1/12,000 to 2 Seconds | | Camera Angle Adjustment | Horizontal: 0 to 353°
Vertical: 0 to 59° | | | | Streaming Resolution | 1920 x 1080 at 60 fps | | Supported Video Compression | H.264, H.265, MJPEG | | Multi-View Streaming | Yes, 10 Streams | | | | Security | Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log | | Supported Protocols | ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, ONVIF Profile G, ONVIF Profile S, PIM, PPPoE, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP | | | | Application Programming Interface (API) | SUNAPI (HTTP API) | | Analytics | Tampering, Loitering, Directional Detection, Defocus Detection, Fog Detection, Virtual Line, Enter/Exit, (Dis)Appear, Face Detection, Motion Detection, Digital Auto Tracking, People Counting, Heatmap, Queue Management | | Event Trigger | Yes | | Event Action | Recording, Notification, Alarm | | | | Windows OS Support | Windows 7, 8.1, 10 | | Mac OS Support | macOS 10.12, OS X 10.11, OS X 10.10 | | | | Recording Media | SD (Up to 256 GB) | | Pan/Tilt | None | | I/O Connections | 1 x RJ45 | | Video Management Software | SmartViewer, SSM | | Supported Languages | Czech
Dutch
English
French
German
Greek
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Spanish
Swedish
Traditional Chinese
Turkish | | Internal Storage | None | | External Storage Options | Local PC, NAS | | Power Source | PoE 802.3af (15 W) | | Power Consumption | PoE: 6.5 W | | Material of Construction | Metal (Unspecified Type) | | Operating Temperature | -22 to 131°F / -30 to 55°C | | Storage Temperature | -22 to 140°F / -30 to 60°C | | Operating Humidity | 0 to 89% | | IP Rating | IP66 | | IK Rating | IK10 | | Dimensions |
