Product description The WiseNetIII 2MP Bullet Camera (No Lens) from Samsung has a 2MP 1/2.8" progressive-scan CMOS sensor to capture 1920 x 1080 resolution video at up to 60 fps with a lens attached (available separately). This WiseNetIII camera features 120dB Wide Dynamic Range for low-light performance. It compresses video using H.264 and MJPEG codecs to ensure high-quality recording and playback. A built-in microSD slot supports up to a 64GB microSD card (available separately) for edge storage. PoE technology helps eliminate the need for additional cable runs by running a connection to an NVR and power in one Ethernet cable. - 2MP 1/2.8" progressive-scan CMOS sensor captures 1920 x 1080 resolution video at up to 60 fps in all compressions
- C/CS lens mount for a wide range of compatible lenses (available separately)
- H.264 and MJPEG compression
- Audio, face, and motion detection
- microSD slot for microSD cards up to 64GB (available separately)
- ONVIF Profile S compliant
In the Box Hanwha Techwin WiseNetIII 2MP Bullet Camera (No Lens) Software CD Cable for Testing Monitor C-Mount Adapter Automatic Iris Lens Connector 6-Position Terminal Block Brochure PDF 1.8mb Table of Contents
|
Upload User Manual
Have you got an user manual for the Hanwha Techwin WiseNetIII 2MP Bullet Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHanwha Techwin SNB-6004 Specs | | | Imaging Device | 2 MP 1/2.8" progressive-scan CMOS sensor | | Total Pixels (H x V) | 1952 x 1116 | | Effective Pixels (H x V) | 1944 x 1104 | | Minimum Illumination | Color : 0.1 lux (f/1.2, 50 IRE), 0.001 lux (2 sec, 50 IRE), 0.03 lux (f/1.2, 30 IRE)
B/W : 0.01 lux (f/1.2, 50 IRE), 0.002 lux (f/1.2, 30 IRE) | | S / N Ratio | 50 dB | | Video Output | CVBS: 1.0 Vp-p, 75 Ohms composite, 720 x 480 for installation
DIP connector type | | | | Focus Control | Simple focus / manual
Remote control via network, button control (manual, simple focus, day / night) | | Lens Type | Manual / DC auto iris, P-iris | | Mount Type | C, CS | | | | Camera Title | Off / On (Displayed up to 45 characters) | | Day & Night | Auto (ICR) / color / B&W / external / schedule | | Backlight Compensation | Off / BLC | | Wide Dynamic Range | 120 dB | | Contrast Enhancement | SSDR (Samsung Super Dynamic Range) (Off / On) | | Digital Noise Reduction (DNR) | SSNRIII (2D + 3D noise filter) (Off / On) | | Digital Image Stabilizer | Off / On | | Defog | Off / auto / manual | | Motion Detection | Off / On (4ea 4 points polygonal zones) | | Privacy Masking | Off / On (32 zones with 4 points of polygonal) | | Gain Control | Off / low / middle / high | | White Balance | ATW / AWC / manual / indoor / outdoor | | Electronic Shutter Speed | Minimum / maximum / anti flicker (2 to 1/12,000 sec) | | Flip / Mirror | Off / On | | Intelligent Video Analytics | Tampering, virtual line, enter / exit, appear / disappear, audio detection, face detection | | Alarm I/O | 1 x input / 1 x output | | Remote Control Interfaces | RS-485 | | RS-485 Protocol | Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch | | Alarm Triggers | Motion detection, tampering, audio detection, face detection, video analytics, alarm input, network disconnection | | Alarm Events | File upload via FTP and email, notification via email, TCP and HTTP, local storage (SD / SDHC / SDXC) recording at Network disconnected and event (Alarm triggers), external output | | | | Ethernet | RJ45 (10/100Base-T) | | Video Compression Format | H.264 (MPEG-4 part 10 / AVC), MJPEG | | Resolution | 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 | | Frame Rate | H.264: Maximum 60 fps at all resolutions
MJPEG: 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 (Maximum 15 fps)
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 (Maximum 30 fps) | | Video Quality Adjustment | H.264: Compression level, target bitrate level control
MJPEG: Quality level control | | Bitrate Control Method | H.264: CBR or VBR, MJPEG: VBR | | Streaming Capability | Multiple streaming (up to 10 profiles) | | Audio In | Selectable (mic in / line in), built-in mic
Max Output Level: 1 Vrms
Supply Voltage: 2.5 VDC @ 4 mA
Input Impedance: Approximately 2 kOhms | | Audio Out | Line out (3.5 mm stereo mini jack) | | Audio Compression Format | G.711 u-law / G.726 selectable, G.726 (ADPCM) 8 kHz, G.711 8 kHz
G.726: 16, 24, 32, 40 kbps | | Audio Communication | Two-way audio | | IP | IPv4, IPv6 | | Protocol | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour | | Security | HTTPS (SSL) login authentication, Digest login authentication, IP address filtering, User access log, 802.1x authentication | | Streaming Method | Unicast / multicast | | Maximum User Access | 15 users at unicast mode | | Memory Slots | microSD card up to 64 GB (available separately) | | Application Programming Interface | ONVIF profile S and G, HTTP API (SUNAPI) 2.0, SVNP 1.2 | | Web Viewer | Supported OS: Windows XP, Vista, 7, 8, 8.1, Mac OS X 10.7
Supported Browsers: Microsoft Internet Explorer (Version 8 to 11), Mozilla Firefox (Version 9 to 19), Google Chrome (Version 15 to 25), Apple Safari (Version 6.0.2, 5.1.7) | | Central Management | SmartViewer, SSM | | | | Operating Temperature | 14 to 131°F (-10 to 55°C) | | Storage Temperature | -22 to 140°F (-30 to 60°C) | | Relative Humidity | < 90% | | | | Input Voltage/Current | 24 VAC ± 10%, 12 VDC ± 10%, PoE (IEEE802.3af, Class3) | | Power Consumption | 24 VAC @ 50/60 Hz: 11.44 W maximum
12 VDC: 10.1 W
PoE, Class3: 11.1 W maximum | | | | Material | Aluminium, plastic | | Dimensions (WxHxD) | 2.9 x 2.6 x 5.8" (73 x 66.6 x 147.8 mm) | | Weight | 0.87 lb (395 g) | | | | Package Weight | 1.38 lb | | Box Dimensions (LxWxH) | 8.55 x 4.7 x 4.1" |
