Product description The HDfury PCI-MX 44UHD is a 4x4 HDMI Matrix Switch for an HTPC or a streaming computer. It allows you to route four HD sources to four HD displays. It provides four HDMI inputs, which allows you to connect devices such as the PS4, XBox One, cable box, Blu-ray player, and/or the HDMI output of your Android/Apple smartphone. It allows 32 viewing combinations of four HD sources on four HDTVs. The matrix switch provides Instant Port Switching (IPS) without any flash on other screens. This feature might be altered by the capability of the connected display to handle pixel clock changes.The matrix switch supports up to 3840 x 2160 resolution 3D video, 36-bit deep color, x.v.Color, and high-definition multi-channel audio including Dolby TrueHD and DTS-HD Master Audio. The unit can be powered by one PCI-X slot available on any CPU motherboard. In addition, the matrix switch incorporates EDID management through a windows EDID application and a USB service port for matrix control. - 4 x 4 HDMI repeater with equalizer
- Supports 32 combinations of matrix switching
- Four HDMI inputs and four HDMI outputs
- SD, HD, Full HD, and UHD support
- Supports resolutions up to 3840 x 2160 at 30 Hz (4:4:4) or 3840 x 2160 at 60 Hz (4:2:0)
- EDID management, USB service port for customization needs
- REMIX/CUSTOM and FIXED EDID modes available
- Supports four HDMI input ports (Port 0/1/2/3) with on-chip EDID RAM for each port
- Support HDMI/MHL dual mode in RX0 port
- On-chip four HDCP receiver ciphers which support Instant Port Switching (IPS) without blinking (altered by the connected display's capability)
- Supports four HDMI output ports with on-chip HDCP transmitter cipher for each port
- Supports wide frequency range of 25 to 340 MHz TMDS clock
- Supports 12-bit deep color Full HD, Full 3D, and 3840 x 2160 video
- Supports standard audio, DSD audio, and HD (HBR) audio
- On-chip HDMI receiver and transmitter core which are compliant with HDMI 1.4 specification
- On-chip HDCP receiver and transmitter engines support repeater, and are compliant with HDCP 1.4 specification
- Source signal detection in low power mode
- On-chip power regulator which provides regulated 3 and 1.6V power
- Low stand-by current at power down mode
- Gold-plated connectors to ensure smooth, corrosion-free connections
UPC: 019962384745 In the Box HDfury PCI-MX 44UHD 4 x 4 PCI HDMI Matrix Switch Main Board Daughter Board 4 x Short HDMI Cables Internal USB Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the HDfury PCI-MX 44UHD 4 x 4 PCI HDMI Matrix Switch in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHDfury PCI-MX44UHD Specs | Form Factor | PCI card | | Inputs | 4 x HDMI | | Outputs | 4 x HDMI | | Standards | HDMI 1.4 and HDCP 1.4 | | Resolutions | Up to 3840 x 2160 at 30 Hz (4:4:4) or 3840 x 2160 at 60 Hz (4:2:0) | | TMDS Clock Frequency | 25 to 340 MHz | | Modes | REMIX/CUSTOM and FIXED EDID | | Power Regulator | Provides regulated 3 V and 1.6 V power | | Dimensions | Not specified by the manufacturer | | Weight | Not specified by the manufacturer |
