User Manual for HighPoint RocketStor 6324L Single Mini-SAS to Thunderbolt 2 Adapter Click to enlarge the picture
Contents of the user manual for the HighPoint RocketStor 6324L Single Mini-SAS to
- Product category: Thunderbolt Cables & Adapters HighPoint
- Brand: HighPoint
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for HighPoint Thunderbolt Cables & Adapters
 |
User manual for the HighPoint RocketStor 6324L Single Mini-SAS to contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any HighPoint product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official HighPoint user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a HighPoint product will considerably shorten its lifespan!
|
Product description The RocketStor 6324L Single Mini-SAS to Thunderbolt 2 Adapter from HighPoint allows you to connect Mini-SAS storage, such as the RocketStor 6414S, to your Thunderbolt-compatible system. As this adapter features one Mini-SAS port, HighPoint's separately sold EXT-MS-1MMS External Mini-SAS to External Mini-SAS cable can directly support up to four 6 Gb/s SAS or SATA devices. Additionally, using HighPoint's separately sold EXT-MS-1MEJ external Mini-SAS to eSATA cable, the one Mini-SAS port of this adapter can directly support up to four 6 Gb/s SATA drives.
Aside from the one Mini-SAS port, this adapter is also equipped with dual Thunderbolt 2 ports, each of which is capable of delivering bi-directional data transfer speeds of up to 20 Gb/s. While one Thunderbolt port is used for connecting this device to your system, the other may be used to daisy chain up to six Thunderbolt devices together, such as Thunderbolt displays, additional storage, and more.
Please note that the RocketStor 6324L only supports JBOD and software-based Mac OS X RAID configurations. It does not support hardware RAID configurations.
The RocketStor 6324L Single Mini-SAS to Thunderbolt 2 Adapter includes a power adapter and a power cord. It is compatible with Mac OS X 10.8.5 and later, as well as PC-only configurations of Windows 7 and later. It is protected by a limited 1-year parts and labor warranty, as well as phone and Skype support. UPC: 643653632411 In the Box HighPoint RocketStor 6324L Single Mini-SAS to Thunderbolt 2 Adapter Power Adapter Power Cord Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the HighPoint RocketStor 6324L Single Mini-SAS to Thunderbolt 2 Adapter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHighPoint ROCKETSTOR 6324L Specs | | | Thunderbolt Interface | Thunderbolt 2 | | Input | Mini DisplayPort Male | | Output | Mini DisplayPort Male
SFF-8088 Female | | | | Housing Material | Aluminum | | LED Indicator | Yes | | Dimensions (W x H x D) | 13.0 x 6.9 x 3.7" / 33.0 x 17.5 x 9.5 cm | | Weight | 2.7 lb / 1.2 kg | | | | Package Weight | 2.9 lb | | Box Dimensions (LxWxH) | 13.307 x 7.008 x 3.78" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 08 owners. Add your rating and experience with the product.
