User Manual for Hikvision 2MP Network Ball Camera with Turret Mount and 2.8mm Lens Click to enlarge the picture
Contents of the user manual for the Hikvision 2MP Network Ball Camera with
- Product category: Wired IP Cameras Hikvision
- Brand: Hikvision
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Hikvision Wired IP Cameras
|
User manual for the Hikvision 2MP Network Ball Camera with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Hikvision product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Hikvision user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Hikvision product will considerably shorten its lifespan!
|
Product description The 2MP Network Ball Camera from Hikvision utilizes a 1/2.7" progressive scan CMOS sensor and a 2.8mm fixed lens to capture images at a resolution up to 1920 x 1080 at 30 fps. It supports H.264 and MJPEG video compression formats. The camera offers WDR of up to 120 dB for capturing images under varied lighting conditions. It comes with a built-in microSD card slot (up to 128GB) for on-board storage. - Supports people counting, defining region of interest, electronic image stabilization, and defogging
- Supports true day/night and backlight compensation
UPC: 842571100372 In the Box Hikvision 2MP Network Ball Camera with Turret Mount and 2.8mm Lens Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Hikvision 2MP Network Ball Camera with Turret Mount and 2.8mm Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHikvision DS-2CD6424FWD-40/E1 Specs | Image Sensor | 1/2.7" progressive scan CMOS | | Minimum Illumination | Color: 0.028 lux @ f/2.0 (AGC On) | | Focal Length | Fixed 2.8mm @ f/2.0 | | Mount | Ball with turret mount | | Horizontal Angle of View | 109.4° | | Day/Night | True Day/Night | | Backlight Compensation | Supported | | Wide Dynamic Range | 120 dB | | Video Compression | H.264/MJPEG | | Maximum Image Resolution | 1920 x 1080 | | Frame Rate | 30 fps @ 1920 x 1080, 1280 x 960, 1280 x 720 | | Motion Detection | Supported | | Audio Input/Output | Input: 1 x Line/mic
Output: 1 x Line | | Alarm | 1 x Input
1 x Output | | Local Storage | microSD card slot, supports up to 128 GB | | System Compatibility | ONVIF (Profle S and G), PSIA, and CGI ASAP | | Ratings | UL/cUL listed | | Operating Temperature | -22 to 140°F / -30 to 60°C | | Power Supply | 12 VDC, PoE (802.3af) | | Power Consumption | 6.5 W | | Dimensions | Not specified by the manufacturer | | Weight | Not specified by the manufacturer | | | | Package Weight | 1.87 lb | | Box Dimensions (LxWxH) | 10.1 x 6.5 x 5.2" |
