User Manual for Hikvision DS-2DF5276-AE3 1.3MP PTZ Dome Indoor Network Camera with 4.3 to 129mm Varifocal Lens Click to enlarge the picture
Contents of the user manual for the Hikvision DS-2DF5276-AE3 1.3MP PTZ Dome Indoor
- Product category: Wired IP Cameras Hikvision
- Brand: Hikvision
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Hikvision Wired IP Cameras
|
User manual for the Hikvision DS-2DF5276-AE3 1.3MP PTZ Dome Indoor contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Hikvision product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Hikvision user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Hikvision product will considerably shorten its lifespan!
|
Product description The DS-2DF5276-AE3 1.3MP PTZ Dome Indoor Network Camera from Hikvision features a 1/3" progressive scan CMOS sensor and a 4.3 to 129mm varifocal lens. It supports endless 360° panning and -5° to 90° tilting (auto flip). The camera also supports 30x optical zoom and 16x digital zoom. DS-2DF5276-AE3 comes with a card slot that supports a microSD card of up to 32GB. - Features a 1/3" progressive scan CMOS sensor that allows the camera to capture images of up to 1280 x 960
- Supports 30x optical zoom and 16x digital zoom
- Supports true day/night, 3D DNR, digital WDR
- Supports 3D intelligent positioning
- Can be powered via 24 VAC or PoE+ power supply
UPC: 816783016134 In the Box Hikvision DS-2DF5276-AE3 1.3MP PTZ Dome Indoor Network Camera with 4.3 to 129mm Varifocal Lens Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Hikvision DS-2DF5276-AE3 1.3MP PTZ Dome Indoor Network Camera with 4.3 to 129mm Varifocal Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHikvision DS-2DF5276-AE3 Specs | | | Image Sensor | 1/3" progressive scan CMOS | | Effective Pixels (H x V) | 1280 x 960 | | Maximum Image Resolution | 1280 × 960 | | Frame Rate | 60 Hz: 30 fps @ 1280 × 960, 1280 × 720 | | Compression | H.264/ MPEG4 | | Minimum Illumination | Color: 0.05 lux @ f/1.6, AGC On
B/W: 0.005 lux @ f/1.6, AGC On | | White Balance | Auto / Manual / ATW / Indoor / Outdoor / Daylight lamp / Sodium lamp | | AGC | Auto / Manual | | S/N Ratio | ≥52 dB | | Digital Noise Reduction | 3D DNR | | Backlight Compensation | BLC | | Wide Dynamic Range | 128x digital WDR | | Shutter Speed | 1 to 1/10,000 sec | | Day & Night | IR cut filter | | Digital Zoom | 16x | | Focus Modes | Auto / Semiautomatic / Manual | | | | Focal Length | 4.3 to 129 mm, 30x | | Zoom Speed | Approximately 3 sec (optical wide-tele) | | Angle of View | Wide: 58.9°
Tele: 2.11° | | Minimum Working Distance | Wide: 0.4" (1.0 cm)
Tele: 59.1" (150.0 cm) | | Aperture Range | f/1.4 to 5.0 | | | | Range | Pan: 360° endless
Tilt: -5° to 90° (auto flip) | | Speed | Pan Manual Speed: 0.1° to 250°/sec, Pan Preset Speed: 300°/sec
Tilt Manual Speed: 0.1° to 150°/sec, Tilt Preset Speed: 200°/sec | | Zoom | Proportional: Rotation speed can be adjusted automatically according to zoom multiples | | Number of Presets | 256 | | Patrol | 8 Patrols, up to 32 presets per patrol | | Action Type | Park: Pattern / pan scan / tilt scan / random scan / frame scan / panorama scan | | | | Input | Optional audio input (Line input), 2 to 2.4 Vpp
Output Impedance: 1 kOhm ±10% | | Output | Line level
Impedance: 600 ohms | | Compression | G.711μ / G.711a / G.726 | | | | Ethernet | 10Base-T / 100Base-TX, RJ45 connector | | Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE | | Live View | Up to 6 views simultaneously | | Streams | Dual streams | | User/Host Level | Up to 32 users
3 Levels: Administrator, camera control, live view only | | Security | User authentication (ID and PW), host authentication (MAC address) | | RS-485 Protocol | HIKVISION, Pelco-P, Pelco-D, self-adaptive | | | | Application Programming Interface | Open-ended API, support Onvif, PSIA and CGI | | Web Browser | IE 7, IE 8, IE 9, Chrome 8+, Firefox 3.5+, Safari 5+ | | | | Memory Card Slot | microSD slot, up to 32 GB | | Power | Supply: 24 VAC/PoE+
Consumption: Maximum 20 W | | Working Temperature | 14 to 122°F (-10 to 50°C) | | Humidity | 90% or less | | Dimensions | 7.2 × 9.6" (18.3 × 24.3 cm) | | Weight | Approximately 11 lb (5 kg) |
