User Manual for Hikvision Smart Pro Series 2MP 36x Outdoor PTZ Network Camera with 5.7 to 205.2mm Lens and Night Vision Click to enlarge the picture
Contents of the user manual for the Hikvision Smart Pro Series 2MP 36x
- Product category: Wired IP Cameras Hikvision
- Brand: Hikvision
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Hikvision Wired IP Cameras
|
User manual for the Hikvision Smart Pro Series 2MP 36x contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Hikvision product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Hikvision user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Hikvision product will considerably shorten its lifespan!
|
Product description The Smart Pro Series 2MP 36x Outdoor PTZ Network Camera from Hikvision features a 1/1.9" progressive scan CMOS sensor and a 55.7 to 205.2mm varifocal lens to capture images at a maximum resolution of 1920 x 1080. It also features DarkFighter technology that provides clear images in any lighting condition. The lens offers a 36x optical zoom for capturing details over expansive areas. The system also features Defog, EIS (Electronic Image Stabilization), and True WDR (Wide Dynamic Range). The camera is enclosed in an IP66-rated housing, which ensures the system can be used for both indoor and outdoor applications. This system can be used for 24-hour surveillance thanks to built-in IR LEDs with a range of up to 3280'. - Maximum resolution of 1920 x 1080
- Line crossing detection, intrusion detection, region entrance, region exiting, sudden audio increase/decrease detection, audio loss detection, defog
- Complies with ONVIF (Profile S and G) and CGI ASAPI
In the Box Hikvision Smart Pro Series 2MP 36x Outdoor PTZ Network Camera with 5.7 to 205.2mm Lens and Night Vision Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Hikvision Smart Pro Series 2MP 36x Outdoor PTZ Network Camera with 5.7 to 205.2mm Lens and Night Vision in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHikvision Pro Series Specs | Image Sensor | 1/1.9" progressive scan CMOS | | Minimum Illumination | Color: 0.002 lux @ f/1.5 (AGC On)
B&W: 0.0002 lux @ f/1.5 (AGC On); 0 with IR | | Resolution | 30 fps @ 1920 x 1080, 1280 x 960, 1280 x 720 | | Lens | 5.7 to 205.2mm motorized zoom and autofocus | | Horizontal Angle of View | 58.7 to 2° | | Video Compression | H.264 / MJPEG / MPEG4 | | Optical Zoom | 36x | | Digital Zoom | 16x | | Pan Range | 360° endless | | Tilt Range | -40° to 90° | | Pan & Tilt Speed | Manual
Pan: 0.1° to 100°/sec
Tilt: 0.1° to 40°/sec
Preset
Pan: 540°/sec
Tilt: 400°/sec | | WDR / BLC | 120 dB / Yes | | IR Range | 3280' / 1000 m | | Presets | 300 | | Tours | 8 | | Pattern | 4 | | Local Storage | microSD, 128 GB maximum (card sold separately) | | Operating Temperature Range | -40 to 149°F / -40 to 65°C | | Power Requirements | 24 VAC, 60 W (maximum) | | Ratings | IP66 & UL/cUL listed | | Dimensions | Not specified by manufacturer | | Weight | Not specified by manufacturer |
