User Manual for HIVE LIGHTING Wasp 1000 Plasma PAR Light with Remote Ballast Kit Click to enlarge the picture
Contents of the user manual for the HIVE LIGHTING Wasp 1000 Plasma PAR
- Product category: HMI & Plasma Lights HIVE LIGHTING
- Brand: HIVE LIGHTING
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for HIVE LIGHTING HMI & Plasma Lights
|
User manual for the HIVE LIGHTING Wasp 1000 Plasma PAR contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any HIVE LIGHTING product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official HIVE LIGHTING user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a HIVE LIGHTING product will considerably shorten its lifespan!
|
Product description This 120V Wasp 1000 Plasma PAR Light with Remote Ballast Kit was put together by Hive Lighting for image-makers who require a great deal of light backed by a comprehensive collection of modifiers. This version of the Wasp removes the power supply from the head to create a lighter weight unit that is more easily supported when mounted at significant heights. The Wasp 1000 then connects to the remote ballast via its 32' header cable. The kit includes the Wasp head with a 1000W plasma bulb, a 12-Degree Spot Reflector, accessory ring, 4-way barndoors and a 5-piece scrim Set. Also provided are a 4-piece HDP Lens Set for varying the light's beam spread, a 32' Header Cable, and a 120V Remote Ballast. The Wasp 1000 Plasma Head is a single point light source with performance similar to an 1800 to 2500W HMI (or 5000W tungsten fixture), but unlike an HMI it has an extremely low power draw. While the HMI consumes 2.5K of current, the Wasp uses just 150W, which means you can run 2 of them on a 20A, 120 VAC circuit. And performance isn't limited to power. The daylight-balanced Wasp outputs full spectrum, 98 CRI dimmable light at 6500K that's flicker-free at any frame rate, making it ideal for high-speed work. Ideal for long throw work, at 50' the Wasp 1000 reads f16 at spot and f4/5.6 at flood with an ISO of 800. The light has a combination 5/8" receiver / 1-1/8" pin mount. In the Box HIVE LIGHTING Wasp 1000 Plasma PAR Light with Remote Ballast Kit (120V) Plasma Bulb for Bee and Wasp 1000 (1000W) rrbxxqdtdxbyuztrsedxecxacewz Wasp 1000 12° Spot Parabolic Reflector 5-Piece Scrim Set for Wasp 1000 4-Leaf Barndoors for Wasp 1000 (13.5") 4 HDP Lens Set with Bag for Wasp 1000 PAR and Maxi Systems Header Cable for Wasp and Bee 1000 (32') 120V Remote Ballast/Power Supply Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the HIVE LIGHTING Wasp 1000 Plasma PAR Light with Remote Ballast Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHIVE LIGHTING Wasp 1000 Specs | Light Source | 1000 W Plasma bulb | | Lamp Life | 50,000 Hours | | Equivalent Light Output | Approximate Equivalence: 1800-2500 W HMI / 5000 W tungsten | | Color Temperature | 6500K | | CRI | 98 | | Dimming | Yes | | Power Consumption | 150 W | | Photometrics | With 12° Reflector
7000 fc / 75,348 lux @ 10' / 3.0 m
1120 fc / 12,056 lux @ 20' / 6.1 m
280 fc / 3014 lux @ 30' / 9.1 m
70 fc / 753 lux @ 40' / 12.2 m | | Voltage | 120 VAC | | Mounting | 5/8" / 16 mm) Receiver / 1-1/8" / 28 mm pin combo | | Dimensions | 19 x 18 x 17" / 48.3 x 45.7 x 43.2 cm including reflector | | Weight | Not specified by manufacturer |
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 57 owners. Add your rating and experience with the product.
