User Manual for HP 14" EliteBook 1040 G3 Laptop Click to enlarge the picture
Contents of the user manual for the HP 14" EliteBook 1040 G3 Laptop
- Product category: Notebooks HP
- Brand: HP
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for HP Notebooks
 |
User manual for the HP 14" EliteBook 1040 G3 Laptop contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any HP product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official HP user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a HP product will considerably shorten its lifespan!
|
Product description Designed for mobile professionals who require rugged systems for enhanced business and graphics performance in a managed IT environment, as well as security and manageability features, the 14" EliteBook 1040 G3 Laptop from HP is powered by a 2.6 GHz Intel Core i7-6600U Dual-Core processor and 16GB of 2133 MHz DDR4 RAM, allowing you to run multiple programs simultaneously and quickly access frequently used files and programs. When running more demanding programs or tasks, the processor can be boosted to achieve a speed of 3.4 GHz using Intel's Turbo Boost technology.
The 14" SVA display features a Full HD 1920 x 1080 screen resolution, LED backlighting, a 16:9 aspect ratio, and an anti-glare finish. Visuals are handled by the integrated Intel HD 520 chipset, and you can output video to an external display using the built-in HDMI port or the VGA port on the included docking station. Using the optional UltraSlim Docking Station, up to three displays are supported with a color depth of up to 32-bits per pixel.
For storage of your files, this system comes with a 512GB M.2 TLC SATA III SSD. While this SSD may not have the larger capacity of a traditional spinning hard drive, it can operate with faster data transfer speeds because it contains no moving parts. Additionally, its lack of moving parts also helps it to be more resistant to damage from bumps and drops. SSDs also receive less wear and tear because the drive has no read and write heads that the disk media can come into contact with.
If you want to add external storage, optical drives, mice, keyboards, printers, memory card readers, and more, the EliteBook 1040 G3 offers two USB 3.0 Type-A ports and one USB 3.0 Type-C port, all of which double as charging ports. Dual integrated stereo speakers, a dual-microphone array, and a 720p webcam let you participate in video calls for work or with friends and family. Connect to the Internet via 802.11ac Wi-Fi or Gigabit Ethernet via an included docking station for a more stable and reliable connection. Furthermore, to free up USB ports and reduce wire clutter, you can connect additional peripherals and devices using Bluetooth 4.2. A built-in 3-in-1 media card reader supports SD, SDHC, and SDXC formats.
The EliteBook 1040 G3 Laptop operates using an included 3.2' power cord and a 45W AC adapter that runs at 90-265 VAC and 47-63 Hz, as well as a 6-cell / 45.6Wh Lithium-ion polymer battery that will last for up to 11.5 hours before recharging is required. While the installed operating system is Windows 7 Professional (64-bit), a Windows 10 Professional (64-bit) license is included at no additional cost. Also included is Windows 7 Professional (64-bit) recovery media and an HP Side Dock Adapter with RJ45 and VGA ports, as well as NFC capabilities. This system is protected by a limited 3-year parts and labor warranty. General Features - Dual-Core 6th-Gen Skylake Intel Core Performance
- The HP notebook houses a 6th generation Skylake 2.6 GHz Intel Core i7-6700U Dual-Core processor. With a dedicated 4MB cache and 16GB of 2133 MHz DDR4 SDRAM, you will be able to multi-task between applications quickly and efficiently.
- 14" Full HD Anti-Glare SVA Display
- The 14" widescreen display of this HP notebook features LED backlighting, a 16:9 aspect ratio, and a 1920 x 1080 resolution, which can play 1080p content without scaling. The anti-glare finish allows you to work in brightly lit environments.
- HDMI & VGA Video Outputs
- Using the HDMI and VGA outputs, users can connect an external display with a color depth of up to 32-bits per pixel.
- Stay Connected
- This HP notebook can connect to a home or public wireless network via 802.11ac (2x2) Wi-Fi. If you require a more reliable Internet connection, you can utilize Gigabit Ethernet connectivity via the included docking station that attaches to the 1040 G3's docking connector. You can also connect wirelessly to peripherals via Bluetooth 4.2.
- Multi-Format Secure Digital Card Reader
- The multi-format Secure Digital card reader supports SD, SDHC, and SDXC cards. microSD cards are also supported using an adapter.
- Security Management
- Security lock slot (lock must be purchased separately)
TPM 1.2/2.0 (Infineon, soldered down)
Integrated Smart Card reader (active)
Fingerprint reader
Pre-boot Authentication (password, Smart Card) - Windows 7 Pro + Windows 10 Pro License
- This system is pre-installed with Windows 7 Professional software and comes with a license and media for Windows 10 Pro software. You may use only one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.
In the Box HP 14" EliteBook 1040 G3 Laptop 45W Smart AC Adapter HP Side Dock Adapter 3.2' / 1.0m Power Cord 6-Cell / 45.6Wh Lithium-ion Polymer Battery Windows 7 Professional (64-bit) Recovery Media Windows 10 Professional (64-bit) License Limited 3-Year Parts & Labor Warranty Guides & Manuals rszbsuxayeyrv More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the HP 14" EliteBook 1040 G3 Laptop in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the HP 14" EliteBook 1040 G3 Laptop can be downloaded in PDF format at the link stated below.
Technical parametersHP 1040 G3 Specs | | | Processor | Intel Core i7-6600U Dual-Core | | Base Clock Speed | 2.6 GHz | | Maximum Boost Speed | 3.4 GHz | | Total Installed Memory | 16 GB | | Maximum Memory Capacity | 16 GB | | Memory Type | DDR4 SDRAM | | Memory Speed | 2133 MHz | | Available Memory Slots | 1 | | Memory Slot Type | 260-Pin SO-DIMM | | Graphics Type | Integrated | | GPU | Intel HD Graphics 520 | | | | Panel Type | LCD | | Size | 14" | | Aspect Ratio | 16:9 | | Native Resolution | 1920 x 1080 | | Touchscreen | None | | Finish | Matte | | Maximum Brightness | 300 cd/m2 | | | | Total Installed Capacity | 512 GB | | Solid State Storage | 1 x 512 GB M.2 SATA | | Optical Drive | None | | | | Ports | 2 x USB 3.1 Gen 1 Type-A
1 x USB 3.1 Gen 1 Type-C
1 x Docking Connector | | Display | 1 x HDMI 1.4
1 x VGA | | Audio | 2 x Integrated Speaker
2 x Integrated Microphone
1 x 1/8" (3.5 mm) Headphone/Microphone Combo Jack | | Expansion Slots | 1 x Smart Card | | Media Card Slots | SD/SDHC/SDXC | | | | Network | 1 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) via Included Cable | | Wi-Fi | Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz) | | Bluetooth | Bluetooth 4.2 | | NFC | Yes | | Webcam | User-Facing: 720p | | | | Battery Chemistry | Lithium-Ion Polymer (LiPo) | | Watt Hours / Type | 45 Wh | | Cells | 6 | | Maximum Runtime | 11.5 Hours | | Power Requirements | 90-265 VAC, 47-63 Hz | | Power Supply | x 45 W | | | | Operating System | Windows 7 Professional (64-Bit) | | Security | Power-On Password, Kensington Lock Slot, Accepts 3rd Party Security Lock Devices, Infineon TPM Software Professional Package, Fingerprint Reader | | Keyboard | Standard Notebook Keyboard (Backlight) | | Pointing Device | TouchPad | | Dimensions (W x H x D) | 13.3 x 0.6 x 9.2" / 33.8 x 1.5 x 23.4 cm | | Weight | 3.15 lb / 1.43 kg (Starting weight) | | | | Package Weight | 5.35 lb | | Box Dimensions (LxWxH) | 19.0 x 12.0 x 2.7" |
