Product description

General Features

Thunderbolt 3
• Thunderbolt 3 is a hardware interface that utilizes the reversible USB Type-C connector. Doubling the speed of its predecessor, Thunderbolt 3 features a maximum bi-directional throughput of 40 Gb/s when used with compatible devices. The connector also transmits data via USB 3.1 at up to 10 Gb/s, and dual-bandwidth DisplayPort 1.2 allows you to simultaneously connect two 4K displays or one 5K display. Additionally, you can daisy chain up to six devices from a single Thunderbolt 3 port.

USB 3.1 Gen 1 Type-A Ports
• This ZBook 15u G5 features two USB 3.1 Gen 1 Type-A ports that will allow you to connect external peripherals such as additional storage, optical drives, printers, memory card readers, and more. One of the USB 3.1 Gen 1 Type-A ports also doubles as an always-on charging port for compatible USB devices.

Gigabit Ethernet & 802.11ac Wi-Fi
• The system uses a Gigabit Ethernet controller for Internet access when connected to a router, modem, or network switch. It also features Intel Dual Band Wireless-AC 8265 which is compatible with 802.11a/b/g/n/ac Wi-Fi so that users may access network connectivity using wireless technology.

Bluetooth 4.2
• Additional compatible peripherals, such as mice, keyboards, headsets, and more may be paired using Bluetooth 4.2 technology.

15.6" 1920 x 1080 UWVA Anti-Glare IPS Display
• The 15.6" UWVA display features a Full HD 1920 x 1080 screen resolution that is equipped with IPS technology, 67% sRGB coverage, an anti-glare finish, LED-backlighting, a 16:9 aspect ratio, a contrast ratio of 600:1, a refresh rate of 60 Hz, a brightness of 220 cd/m², and viewing angles of 85/85/85/85°.

Up to 32GB Memory
• While this system natively includes 8GB of 2400 MHz DDR4 RAM in a 1 x 8GB configuration, it can be upgraded to a maximum of 32GB when 16GB memory modules are used in each of the system's 260-pin SO-DIMM slots.

720p IR Webcam
• The integrated webcam allows users to easily connect and collaborate with Skype and other conferencing tools. It also features a privacy slider, which allows for the camera to be blocked out when not in use.

DisplayPort with MST (Multi-stream Transport)
• Supports resolutions up to Ultra HD 3840 x 2160, 24- and 30-bit color depth at 60 Hz, and WUXGA (1920 x 1200) monitors, with 24- and 30-bit color depth up to 120 Hz.

HP Fast Charging
• Recharge the battery to 50% capacity in just 30 minutes when the system is off or in standby.

Multi-Stream Transport (MST)
• Multi-stream Transport is a DisplayPort 1.2 feature that allows daisy chaining of DisplayPort 1.2 monitors (requires monitor with DisplayPort 1.2 MST capability), or the use of DisplayPort 1.2 hubs with MST to achieve a maximum of three active displays, which includes the integrated 14" display.

Smart Card Reader
• The integrated smart card reader is compatible with ISO 7816 compliant smart cards with PC/SC interface support.

Near Field Communications (NFC)
• Near Field Communications (NFC) is a set of communication protocols that enable two electronic devices, one of which is usually a portable device such as a smartphone, to establish communication by bringing them within 1.6" of each other. NFC devices are used in contactless payment systems, similar to those used in credit cards and electronic ticket smartcards and allow mobile payment to replace/supplement these systems. This is sometimes referred to as NFC/CTLS (Contactless) or CTLS NFC. NFC is used for social networking, for sharing contacts, photos, videos, or files. NFC-enabled devices can act as electronic identity documents and keycards. NFC offers a low-speed connection with simple setup that can be used to bootstrap more capable wireless connections.

Windows 10

Start Menu
• After its hiatus in Windows 8, the Start Menu has returned. Utilizing a combination of the traditional menu system and Windows 8's Live Tiles, the improved Start Menu gives you more information at a glance, showing notification information alongside your applications and other pinned items.

Cortana
• Microsoft's digital personal assistant, Cortana can answer your questions with information gleaned from both your device and the internet at large. You can type or even talk with her, if your system has a microphone. Using her Notebook, Cortana keeps track of your needs and wants, and she learns over time to improve her information gathering skills.

Microsoft Edge
• After nearly 20 years, Microsoft has finally replaced its Internet Explorer web browser. With Microsoft Edge, users can write directly on web pages and share notes with friends and colleagues. It also improves the online reading experience by adding a distraction-free mode and read-it-later functionality. Edge also has built-in Cortana integration; you can have her help you find a restaurant, make a reservation, and pull up directions without leaving your browser.

Windows Store
• For Windows 10, Microsoft has unified the Windows Store. Now, apps for PCs, tablets, and phones will all be accessible from one place. And with support for Universal Apps, one version of an app can work across all your compatible devices automatically.

Windows Continuum
• Windows 10 was designed for a variety of screen sizes and input styles, and with its Continuum feature, it automatically adapts to fit your needs. A Windows 10 tablet on its own requires a touch-centric approach, but attaching a mouse and keyboard will shift everything to a more traditional interface. You can even attach an external monitor to your Windows 10 phone for a near-desktop experience. But it's not just the operating system; Windows Universal Apps take advantage of Continuum as well.

Xbox on Windows 10
• Gaming is a big focus of Windows 10. Xbox integration allows for PC players to match up against Xbox One players on supported games, and if you have an Xbox One, you can even stream compatible titles to your PC. Native support for recording with the new Game DVR feature makes it easy to capture and share your gameplay. The new DirectX12 takes better advantage of multi-core processors, giving games a performance boost, even on older hardware. Windows 10 also features native support for virtual reality headsets, such as the Oculus Rift.

Windows 10 Pro
• The Pro version of Windows 10 includes all of the features of Windows 10 Home plus many designed specifically for business users, including Hyper-V virtualization, BitLocker disk encryption, and remote desktop access. Devices will also be able to join domains and the Azure Active Directory, and they can even access a specialized version of the Windows Store featuring custom, company-specific applications.
