User Manual for HP EliteDisplay S240n 23.8" 16:9 Micro Edge IPS Monitor Click to enlarge the picture
Contents of the user manual for the HP EliteDisplay S240n 23.8" 16:9 Micro
- Product category: Computer Monitors HP
- Brand: HP
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for HP Computer Monitors
 |
User manual for the HP EliteDisplay S240n 23.8" 16:9 Micro contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any HP product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official HP user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a HP product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More The EliteDisplay S240n 23.8" 16:9 Micro Edge IPS Monitor from HP is a virtually borderless business display that features a 250 cd/m² brightness rating and a 1920 x 1080 native resolution. A contrast ratio of 1000:1 showcases the monitor's ability to handle light and dark on-screen images. The panel has a 7 ms (GtG) response time, with overdrive, to combat image blur and distortion on moving images. -
- Plug-and-play operation
- User programmable
- Language selection
- On-screen controls
- LED backlights
- In-plane switching technology
- Tile multiple micro-edge displays together
- USB Type-C cable connection that pulls video and data from and sends power to your computer, notebook, tablet, or phone
- Wide viewing angle of 178°/178°
- Connect your digital devices right to the display with DisplayPort 1.2 and HDMI
- ENERGY STAR certified and EPEAT® Gold registered
- Includes HP Display Assistant software
UPC: 889899667477 In the Box HP EliteDisplay S240n 23.8" 16:9 Micro Edge IPS Monitor AC Power Cord DP Cable HDMI Cable USB Type-C to USB Type-C Cable VESA Mount Adapter Driver CD Limited 1-Year Warranty Data Sheet PDF 3.4mb More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the HP EliteDisplay S240n 23.8" 16:9 Micro Edge IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHP S240n Specs | | | Size | 23.8" | | Screen Area | 20.75 x 11.67" / 52.70 x 29.65 cm | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 1920 x 1080 | | Aspect Ratio | 16:9 | | Pixels Per Inch (ppi) | 93 ppi | | Maximum Brightness | 250 cd/m2 | | Contrast Ratio | 1000:1 | | Dynamic Contrast Ratio | 10,000,000:1 | | Refresh Rate | 60 Hz | | Adaptive Sync Technology | None | | HDR Compatibility | None | | Response Time | 7 ms (Overdrive) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | | | Connectivity | 1 x HDMI
1 x DisplayPort 1.2
1 x USB Type-C | | HDCP Support | No | | Built-In Speakers | None | | | | Power Consumption | 150 W (Maximum)
40 W (Typical)
0.5 W (Standby) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | USB Power Delivery | 60 W | | | | Certifications | ENERGY STAR, EPEAT GOLD, as per Manufacturer | | | | Height Adjustment | None | | Rotation Adjustment | None | | Swivel Adjustment | None | | Tilt Adjustment | -5 to 25° | | Mounting-Hole Pattern | None | | Lock Slot | No | | Dimensions (W x H x D) | 21.3 x 15.3 x 5.7" / 54.1 x 38.9 x 14.5 cm (With Stand)
21.3 x 12.3 x 1.4" / 54.1 x 31.2 x 3.6 cm | | Weight | 8.16 lb / 3.70 kg (With Stand) | | | | Package Weight | 14.75 lb | | Box Dimensions (LxWxH) | 24.0 x 15.5 x 5.0" |
