Product description

10 Factors to Consider When Selecting A Monitor for Video Editing Read More With three micro-edge bezels, the EliteDisplay S270n 27" 16:9 Micro-Edge IPS Monitor from HP offers an enhanced viewing experience without the distractions. The reduced size bezels also make this monitor great for use in multi-monitor setups.

Whether used in a multi-monitor setup or by itself, this HP monitor can be used for a variety of tasks as it features a 3840 x 2160 UHD 4K resolution, a 1300:1 contrast ratio, a 5 ms response time, and support for up to 1.07 billion colors. The EliteDisplay S270n also covers up to 99% of the sRGB color gamut, allowing the monitor to be used for a variety of tasks such as graphic design, photo editing, and other jobs in which color accuracy is a must.

Setup is simple as the HP S270n comes equipped with dual HDMI inputs, a single DisplayPort input, and USB Type-C connectivity so you can connect nearly any computer to this monitor. The USB Type-C connector also supports DisplayPort 1.2 connectivity and is capable of delivering up to 60W of power to compatible devices. Once configured, the height of the display can be adjusted up to 3.94" and it can be tilted from-5 to 23 degrees to take full advantage of the 178° horizontal and vertical viewing angles.
    Don't Miss a Thing
  • Put all your creativity and content front and center on a large 27" diagonal screen with a 4K, 3840 x 2160 resolution that reveals nearly every detail and makes colors pop.
    Clear Your Clutter
  • Maintain a minimalist workspace by pulling video and data from and sending power to your computer, notebook, tablet or phone with just one USB-C cable connection.
    Wide Open Spaces
  • Prepare for maximum visual impact and optimal productivity with a 3-sided micro-edge bezel that tiles easily for a virtually seamless multi-display experience. You can even adjust the height of the display up to 3.94" for maximum viewing comfort.
    Simple Setup
  • Speed deployments with out-of-the-box readiness and quickly connect your video sources to the display with one DisplayPort 1.2, two HDMI ports, and a single USB Type-C port.
    Divide and Conquer
  • Design the screen for how you work with HP Display Assistant software, which enables screen partitioning and helps deter theft by dimming a display that's disconnected without approval.
In the Box HP EliteDisplay S270n 27" 16:9 Micro-Edge IPS Monitor
  • AC Power Cord
  • HDMI Cable
  • DisplayPort Cable
  • USB Type-C Cable
  • VESA Mount Adapter
  • Limited 1-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the HP EliteDisplay S270n 27" 16:9 Micro-Edge IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    HP EliteDisplay S270n Specs

    Size 27"
    Screen Area 23.49 x 13.21" / 59.67 x 33.56 cm
    Panel Type IPS-Type LCD
    Touchscreen No
    Resolution 3840 x 2160
    Aspect Ratio 16:9
    Pixels Per Inch (ppi) 163 ppi
    Finish Matte
    Maximum Brightness 350 cd/m2
    Contrast Ratio 1300:1
    Dynamic Contrast Ratio 10,000,000:1
    Refresh Rate 60 Hz
    Adaptive Sync Technology None
    Horizontal Frequency 27 to 135 kHz
    Vertical Frequency 24 to 60 Hz
    Pixel Clock Frequency 533 MHz
    Bit Depth / Color Support 8-Bit+FRC (1.07 Billion Colors)
    HDR Compatibility None
    Color Gamut 99% sRGB
    Response Time 5 ms (GtG)
    Viewing Angle Horizontal: 178°
    Vertical: 178°
    Dot Pitch 0.1554 x 0.1554 mm
    Backlight Lifespan 30,000 Hours
    Connectivity 1 x HDMI 2.0 Input
    1 x HDMI 1.4 Input
    1 x DisplayPort 1.2 Input
    1 x USB Type-C Input
    HDCP Support Yes
    Built-In Speakers None
    Supported Languages Dutch
    English
    French
    German
    Italian
    Japanese
    Portuguese
    Simplified Chinese
    Spanish
    Traditional Chinese
    Power Consumption 126 W (Maximum)
    0.5 W (Eco)
    55 W (Typical)
    AC Input Power 100 to 240 VAC, 50 / 60 Hz
    Power Adapter Type External
    USB Power Delivery 60 W
    Operating Temperature 41 to 95°F / 5 to 35°C
    Storage Temperature 29 to 140°F / -1 to 60°C
    Operating Humidity 20 to 80%
    Storage Humidity 5 to 95%
    Operating Altitude 0 to 16,400' / 0.00 to 4998 m
    Storage Altitude 0 to 40,000' / 0.00 to 12,192 m
    Certifications BSMI, CE, ENERGY STAR, EPEAT GOLD, RCM, TCO Certified, VCCI, WEEE, as per Manufacturer
    Height Adjustment 3.94" / 100 mm
    Rotation Adjustment None
    Swivel Adjustment None
    Tilt Adjustment -5 to 23°
    Mounting-Hole Pattern 100 x 100 mm
    Lock Slot Yes
    Dimensions (W x H x D) 24.2 x 19.6 x 7.5" / 61.4 x 49.9 x 19.0 cm (With Stand)
    24.2 x 14.3 x 1.6" / 61.4 x 36.3 x 4.0 cm (Without Stand)
    Weight 10.69 lb / 4.85 kg (Without Stand)
