User Manual for HP Intel VROC for NVMe Click to enlarge the picture
Contents of the user manual for the HP Intel VROC for NVMe
- Product category: Controller Cards HP
- Brand: HP
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for HP Controller Cards
|
User manual for the HP Intel VROC for NVMe contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any HP product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official HP user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a HP product will considerably shorten its lifespan!
|
Product description Designed for NVMe-based SSDs in HP's Z4, Z6, and Z8 G4 Workstations running Windows 7 or 10, and Xeon Skylake-W or Skylake-SP processors, this premium version of the Intel VROC for NVMe from HP is an enterprise RAID storage solution that supports RAID 0, 1, 5, and 10 and lets users manage RAID volumes with NVMe SSDs that are directly connected to CPU PCIe lanes, without using a host bus adapter (HBA). Short for Virtual RAID on CPU, the Intel VROC delivers faster performance without the complexity and power of a traditional Hardware RAID HBA. General Features - No need for battery backup / RAID maintenance free backup unit
- Protected write back cache - software and hardware that allows recovery from a double fault
- Isolated storage devices from OS for error handling
- Protected R5 data from OS crash
- Boot from RAID volumes based on NVMe SSDs within a single Intel VMD domain
- 3 VMD domains per CPU provide for boot from one domain and data RAID spanning across the other 2 domains
- RAID / storage management using representational state transfer (RESTful) application programming interfaces (APIs)
- Graphical user interface (GUI) for Linux
- 4K native NVMe SSD support
Key Feature List for Workstations - Boot RAID (0, 1, 5, and 10) on CPU-attached NVMe RAID volume
- Close the RAID Write Hole - Helps to recover writes that may not have been written during a power loss condition while the system is in a RAID 5 rebuild
- Spanning data RAID volumes across VMD domains
- For NVMe RAID, Intel VROC is architected to use Intel VMD to provide the following features that Intel RSTe legacy NVMe RAID does not have:
- Bootable RAID
- RAID 5 Double Fault Protection
- Support for HP-qualified SSDs, as well as Intel SSDs
NVMe RAID Features - CPU attached NVMe SSD - high perf
- Third party vendor SSD support
- Intel RSTe 5.0 RAID 0, 1, 5, and 10
- RAID write hole closed (BBU replacement)
- Hot plug / surprise removal (2.5" SSD form factor only; Add-in card form factor not supported)
UPC: 192018660656 Table of Contents
|
Upload User Manual
Have you got an user manual for the HP Intel VROC for NVMe in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHP 3FJ81AA Specs | Compatibility | HP Z4, Z6, and Z8 G4 Workstations | | Supported Operating Systems | Windows 10 and 7 SP2 (UEFI installations) | | Supported Platforms | Intel Xeon Skylake-W and Skylake-SP | | Requirements | Intel RSTe 5.2 PV Release package | | Dimensions | Not specified by manufacturer | | Weight | Not specified by manufacturer |
