User Manual for HP Z38c 37.5" 21:9 Curved IPS Monitor Click to enlarge the picture
Contents of the user manual for the HP Z38c 37.5" 21:9 Curved IPS
- Product category: Computer Monitors HP
- Brand: HP
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for HP Computer Monitors
 |
User manual for the HP Z38c 37.5" 21:9 Curved IPS contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any HP product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official HP user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a HP product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More Immerse yourself in the expansive Z38c 37.5" 21:9 Curved IPS Monitor from HP, where form meets function and delivers crisp, panoramic views so you can stay focused on your work. This anti-glare, BrightView panel features a native UWQHD+ resolution of 3840 x 1600 @ 60 Hz, In-Plane Switching (IPS) technology, a widescreen 21:9 aspect ratio, a radius value of 2300R, a static contrast ratio of 1000:1, a dynamic contrast ratio of 5,000,000:1, 300 cd/m2 brightness, 100.93 pixels per inch, and a 14 ms (on/off) response time that can be adjusted to 5 ms (GtG). Using the 178° horizontal and vertical viewing angles, it is possible to watch content from virtually any position. This display can accept input signals using its DisplayPort 1.2 and HDMI 2.0 inputs, plus an upstream/downstream USB 3.0 Type-C port, which not only supports DisplayPort 1.2, but also power delivery up to 65W. Other featured connections include three downstream USB 3.0 Type-A ports, one of which provides 5V/2A of power for charging compatible devices.
HP has engineered the Z38c with 10-bit color that supports up to 1.07 billion colors and 98% of the sRGB color gamut with factory calibration of a color temperature of D65. Aside from its native 3840 x 1600 @ 60 Hz resolution, it is also able to support resolutions of 3840 x 1600 @ 30 Hz, 2560 x 1600 @ 60 Hz, 2560 x 1080 @ 60 Hz, 1024 x 768 @ 60 Hz, 1280 x 720 @ 60 Hz, 1280 x 1024 @ 60 Hz, 1440 x 900 @ 60 Hz, 1600 x 900 @ 60 Hz, 1600 x 1200 @ 60 Hz, 1680 x 1050 @ 60 Hz, 1920 x 1080 @ 60 Hz, 1920 x 1200 @ 60 Hz, 1920 x 1600 @ 60 Hz, 720 x 480 @ 60 Hz, 800 x 600 @ 60 Hz, 720 x 400 @ 70 Hz, and 640 x 480 @ 60 Hz.
To further help improve viewing and accessibility, the Z38c features a vertical tilt of -5 to 20°, a left/right swivel of ±45°, and a height adjustment of 4.7". This display operates using 100 to 240 VAC @ 50/60 Hz and includes an AC power cable, a DisplayPort cable, an HDMI cable, and a USB 3.0 Type-C cable. General Features - Experience sweeping panoramic visuals with the wide viewing angles of the 37.5" diagonal screen and 21:9 aspect ratio
- View your entire project with the high peripheral readability of the 2300R radius curved screen
- See every nuance of your project in sharp detail with 3840 x 1600 @ 60 Hz resolution. With 100.93 pixels per inch, your text and fonts are just the right size
- Maximize screen area visibility with the three-sided micro-edge bezel
- See consistently accurate and bright images across the entire screen with up to 178° horizontal and vertical viewing angles
- Find your setup with a vertical tilt range of -5 to 20° vertical, a left/right swivel range of 45°, and a height adjustment range of 4.7"
- Less cables, less clutter. The USB 3.0 Type-C connection delivers video, data, and 65W of power, all with one cable
- DisplayPort 1.2 and HDMI 2.0 connections, plus and cables come standard so you can quickly set up and easily connect most compatible devices
- Count on factory-calibrated color from the very first time you power on for reliable color between displays and from project to project
- The Z38c has a standard VESA mounting adapter for mounting to monitor arms
- Your screen is guaranteed to have no bright sub-pixel defects, or HP will replace it
- Declutter your desktop by mounting your mini PC with the HP B500 PC Mounting Bracket
UPC: 191628272969 In the Box HP Z38c 37.5" 21:9 Curved IPS Monitor AC Power Cord HDMI Cable DisplayPort Cable USB Type-C Cable Zero Bright Dot Guarantee Limited 3-Year Warranty Quick Specs PDF 323.5kb More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the HP Z38c 37.5" 21:9 Curved IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersHP Z38c Specs | | | Size | 37.5" | | Screen Area | 34.64 x 14.43" / 87.99 x 36.65 cm | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 3840 x 1600 | | Aspect Ratio | 21:9 | | Pixels Per Inch (ppi) | 111 ppi | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 300 cd/m2 | | Contrast Ratio | 1000:1 | | Dynamic Contrast Ratio | 5,000,000:1 | | Refresh Rate | 60 Hz | | Adaptive Sync Technology | None | | Horizontal Frequency | 27 to 130 kHz | | Vertical Frequency | 24 to 76 Hz | | Pixel Clock Frequency | 600 MHz | | Bit Depth / Color Support | 8-Bit+FRC (1.07 Billion Colors) | | HDR Compatibility | None | | Color Gamut | 98% sRGB | | Response Time | 5 ms (GtG) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Dot Pitch | 0.22908 x 0.22908 mm | | Backlight Lifespan | 30,000 Hours | | | | Connectivity | 1 x DisplayPort 1.2
1 x HDMI 2.0
1 x USB Type-C
1 x 3.5 mm Output
3 x USB Type-A (USB 3.1 Gen 1) | | HDCP Support | Yes | | Built-In Speakers | None | | Supported Languages | Dutch
English
French
German
Italian
Japanese
Portuguese
Simplified Chinese
Spanish
Traditional Chinese | | | | Power Consumption | 80 W (Typical)
195 W (Maximum)
0.5 W (Eco) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | Power Adapter Type | Internal | | USB Power Delivery | 65 W | | | | Operating Temperature | 41 to 95°F / 5 to 35°C | | Storage Temperature | -4 to 140°F / -20 to 60°C | | Operating Humidity | 20 to 80% | | Storage Humidity | 5 to 95% | | Operating Altitude | 0 to 16,404' / 0.00 to 4999 m | | Storage Altitude | 0 to 40,000' / 0.00 to 12,192 m | | Certifications | BSMI, CE, ENERGY STAR, FCC, Microsoft WHQL, TUV, VCCI, WEEE, as per Manufacturer | | | | Height Adjustment | 4.72" / 120 mm | | Rotation Adjustment | None | | Swivel Adjustment | 90° (-45 to 45°) | | Tilt Adjustment | -5 to 20° | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | Yes | | Dimensions (W x H x D) | 35.3 x 22.0 x 9.8" / 89.7 x 55.9 x 24.9 cm (With Stand)
35.3 x 15.7 x 4.1" / 89.7 x 39.9 x 10.4 cm (Without Stand) | | Weight | 30.36 lb / 13.77 kg (With Stand)
21.56 lb / 9.78 kg (Without Stand) | | | | Package Weight | 46.3 lb | | Box Dimensions (LxWxH) | 42.0 x 21.5 x 18.0" |
