User Manual for IDX System Technology Endura HL9 V-Mount 2-Battery Kit for Blackmagic URSA

• Product category: On Camera Batteries IDX System Technology
• Brand: IDX System Technology
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for IDX System Technology On Camera Batteries

Product description

• 2 x IDX System Technology E-HL9 Lithium Ion V-Mount Battery The IDX E-HL9 is a lithium ion, V-Mount battery. It offers 88Wh for 14.4VDC equipment in a compact package.
  Capacity
  • With a continuous draw of up to 10 Amps, the E-HL9 has an impressive capacity using highly durable cell technology. High-load capacity results in 50% higher discharge rate for this series.
  Low Temperature Discharge
  • Advanced low temperature discharge characteristics prohibit a voltage drop off down to -4 degrees Fahrenheit in extreme environment conditions.
  Lifecycle
  • Longer overall lifecycle operators can expect about 10% longer battery viability when the 500-cycle level is reached.
  PowerLink
  • PowerLink technology allows two E-HL9 batteries to be docked together, doubling capacity up to 176Wh for longer run times and high power needs.
  Digi-View
  • Digi-View gives the camera operator an accurate display of the E-HL9's remaining capacity, shown via the camera's viewfinder.
  Power Indication
  • 5 Power Status LEDs are located on the side of the E-HL9 for a quick and accurate check of remaining capacity, shown in increments of 20%.
  BMS
  • BMS is a unique software package that enables users to monitor the history and condition of their batteries to increase their life span. BMS gathers battery data and provides PC access to a comprehensive database, invaluable when managing large fleets of ELITE, E-10 and E-HL9 batteries.
  Circuit Protection
  • Battery circuit protection ensures the E-HL9 is fully protected against common causes of battery misuse, guarding against over charge, over discharge, over current and exposure to high temperatures.
  UPC: 825781012208
• IDX System Technology VL-2000S Simultaneous Quick Charger with 100W DC Output (2-Channel) The VL-2000S Quick Charger from IDX is a simultaneous 2-channel Li-ion V-Mount battery charger with a 100W DC output (4-pin XLR). Supporting LIFE PLUS mode, the VL-2000S can extend battery life up to 20%. It features Power Base mode. This mode gives you the ability to utilize the mounted batteries for powering equipment via the 4-pin XLR output. Low voltage batteries are safely charged with the Recovery Charge mode. The charger also houses energy efficient circuitry that will automatically power down the charger when inactive. UPC: 825781012949
• IDX System Technology V-Mount Adapter Plate for Blackmagic URSA & URSA Mini This IDX V-Mount Adapter Plate attaches directly to the rear of a Blackmagic URSA or URSA Mini camera and allows you to power the camera with V-Mount batteries. It also features an unregulated D-Tap output for powering accessories. UPC: 825781012796

• 2 x E-HL9 Lithium Ion V-Mount Battery ttrrfweacfryqvbfscarwcyyv
• Battery
• Limited 1-Year Warranty

• VL-2000S Simultaneous Quick Charger with 100W DC Output (2-Channel)

• V-Mount Adapter Plate for Blackmagic URSA & URSA Mini

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• 2 x IDX System Technology E-HL9 Lithium Ion V-Mount Battery

  Mount / Series Type	V-Mount
  Chemistry	Lithium-Ion
  Capacity (Wh)	88 Wh
  Amp-Hours	6150 mAh
  Output Voltage	14.4 VDC
  Dimensions (W x H x D)	3.4 x 5.5 x 2.3" / 85.0 x 140.0 x 58.0 mm
  Weight	1.6 lb / 0.7 kg

  Box Dimensions (LxWxH)	6.7 x 4.1 x 2.9"

• IDX System Technology VL-2000S Simultaneous Quick Charger with 100W DC Output (2-Channel)

  Channels	2
  Interface	V-Mount
  Chemistry	Li-ion
  AC Input Voltage	100 to 240 VAC; 50/60 Hz
  DC Output	Via 4-pin XLR: 100 W @ 15 VDC/6.7 A
  Quick Charge Current	1 Battery: 4 A 2 Batteries: 3 A
  Dimensions	7.16 x 3.24 x 9.05" (18.19 x 8.23 x 22.98 cm)
  Weight	2.64 lb (1.19 kg)

  Box Dimensions (LxWxH)	11.1 x 9.9 x 3.95"

• IDX System Technology V-Mount Adapter Plate for Blackmagic URSA & URSA Mini

  Auxiliary Output	1x D-Tap, unregulated 12 - 17 VDC, 50 W max
  Dimensions	3.3 x 5.6 x 0.5" (8.3 x 14.2 x 1.2 cm)
  Weight	6 oz (170 g)

  Box Dimensions (LxWxH)	5.7 x 4.2 x 1.0"
