User Manual for Ikegami CopperHead G1 Camera Mountable ENG SNG Transceiver Click to enlarge the picture
Contents of the user manual for the Ikegami CopperHead G1 Camera Mountable ENG
- Product category: Studio Systems Ikegami
- Brand: Ikegami
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Ikegami Studio Systems
|
User manual for the Ikegami CopperHead G1 Camera Mountable ENG contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Ikegami product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Ikegami user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Ikegami product will considerably shorten its lifespan!
|
Product description The Ikegami CopperHead G1 Camera Mountable ENG/SNG Transceiver simultaneously transports both digital (SDI or HD/SDI) / analog program video, plus 2-way camera control, audio, video, data, tally/call, and intercom signals between the camera and the base station. Transmitting all signals optically and digitally, the transceiver removes interference, grounding problems or drifting due to temperature variations from the video signal, thereby offering high-quality video.
With an optical range of 30dB with DFB (distributed feedback) option, the G1 transceiver can transmit broadcast quality video and audio. The transceiver supports battery mount options for Anton/Bauer, PAG, and V-mount and consumes less power for reliable operation. In addition, the transceiver can employ tactical fiber cable for powering the camera locally or SMPTE Hybrid Fiber cable delivering 150W power to the camera.
The CopperHead G1 Camera Mountable ENG/SNG Transceiver offers all-round connectivity. It is suitable for use in applications such as electronic news gathering, satellite news gathering, multi-camera flypack electronic field production, electronic cinematography, sports production, teleconferencing, inter/intra campus cameras, CATV local origination, telemedicine, and government video. In addition, the transceiver features battery backup in the base station unit. - Simultaneously transports both digital (SDI or HD/SDI) / analog (NTSC or PAL) program video, plus 2-way camera control, audio, video, data, tally/call, and intercom signals between camera and the base station
- Transmits all signals optically and digitally
- Removes interference, grounding problems or drifting due to temperature variations from the video signal, thereby offering high quality video
- Optical range of 30dB with DFB (distributed feedback) option
- Can transmit broadcast quality video and audio
- Supports battery mount options for Anton/Bauer, PAG, and V-mount
- Consumes less power for reliable operation
- Can employ tactical fiber cable for powering the camera locally or SMPTE Hybrid Fiber cable delivering 150W power to the camera
- Features RS170, NTSC, and PAL interfaces
- Offers all-round connectivity
- Suitable for use in applications such as electronic news gathering, satellite news gathering, multi-camera flypack electronic field production, electronic cinematography, sports production, teleconferencing, inter/intra campus cameras, CATV local origination, telemedicine, and government video
- Features battery backup in the base station unit
- Supports return color viewfinder/monitor video, and return black burst/genlock video
- Supports camera program audio, and auxiliary program audio
- Supports 2-way headset intercom, and return IFB/audio channel
- Features tally/call closure circuit
- Supports bi-directional camera control data, and bi-directional time code or RS232 data
- Supports multi-kilometer distance capability
- Available in multi-mode or single mode versions
In the Box Ikegami CopperHead G1 Camera Mountable ENG/SNG Transceiver 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Ikegami CopperHead G1 Camera Mountable ENG SNG Transceiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersIkegami COPPERHEAD G1 Specs | Optical Range | 30 dB | | Mounts | Anton/Bauer & PAG / V-Mount | | Signals Supported | Digital (SDI or HD/SDI)
Analog (NTSC or PAL) |
