User Manual for Ikegami ICD-B11-2812 High Resolution 700 TVL Vandal-Resistant Color Box Camera Click to enlarge the picture
Contents of the user manual for the Ikegami ICD-B11-2812 High Resolution 700 TVL
- Product category: Wired Analog & HD Cameras Ikegami
- Brand: Ikegami
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Ikegami Wired Analog & HD Cameras
|
User manual for the Ikegami ICD-B11-2812 High Resolution 700 TVL contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Ikegami product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Ikegami user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Ikegami product will considerably shorten its lifespan!
|
Product description The Ikegami ICD-B11-2812 High Resolution 700 TVL Vandal-Resistant Color Box Camera (NTSC) features a 2.8 to 12mm lens and a 1/3" Sony 960H Super HAD CCD II image sensor for capturing high-quality images. In the Box Ikegami ICD-B11-2812 High Resolution 700 TVL Vandal-Resistant Color Box Camera (NTSC ) Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Ikegami ICD-B11-2812 High Resolution 700 TVL Vandal-Resistant Color Box Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersIkegami ICD-B11-2812 Specs | Total Pixels (H x V) | 1020 x 508 | | Effective Pixels (H x V) | 976 x 494 | | Sensor | 1/3" Sony 960H Super HAD CCD II | | Scanning System | 2:1 interlace | | Frequency | Horizontal: 15.734 kHz
Vertical: 59.94 Hz | | Resolution | Color: 700 TVL
B&W: 750 TVL | | Video Output | 1.0 Vpp composite signal (75 Ω) | | AGC (Automatic Gain Control) | Off / low / middle / high | | S/N (Y Signal) | 52 dB or more (AGC off) | | Minimum Illumination | 0 lux for infrared lighting conditions | | White Balance | ATW / AWB / AWC->SET / manual | | Electronic Shutter Speed | 1/60s to 1/100,000 sec | | 3D-DNR | Off / on selectable (0 to 200, Smart NR) | | Sens-up | Off / auto (x2 to x256) | | D&N Selection | Auto / color / B&W / EXT | | BLC | Off / low / middle / high | | D-WDR | On (0 to 63) / off selectable | | Masking Options | HLM: On / off selectable | | Defect Compensation | Built-in OSD | | IR Smart | On / off selectable (0 to 100) | | Motion Detection | Off / on (Areas 1 to 4) | | Privacy Masking | Off / on (Masks 1 to 4) | | Mirror | Rotate / v-flip / mirror / off | | Digital Zoom | D-ZOOM / SMART D-ZOOM / DIS | | Sharpness | On / Off (level adjustable from 1 to 31) | | Language Supported | English, Chinese, Spanish, Russian, German, Portuguese, French, Japanese | | IR LED | 36 | | Illumination Distance | Up to 90.0' (27.4 m) | | Power Supply | 12 VDC / 24 VAC, 110 mA
CDS On: 500 mA maximum | | Dimensions (W x H x D) | 2.70 x 2.90 x 5.60" (68.58 x 73.66 x 142.24 mm) | | | | Package Weight | 4.0 lb | | Box Dimensions (LxWxH) | 18.0 x 15.0 x 12.0" |
Rating90% users recommend this product to others. And what about you?
This product has already been rated by 73 owners. Add your rating and experience with the product.
