Product description The IK-DA14 Video Distribution Amplifier from Ikegami is designed to accept (1) composite video input and distribute it to (2) outputs. This unit offers AC or DC operation and can be powered by an AC camera's power transformer to save money. Its small size makes it well suited for mobile or studio work. - 1x4 Composite Video Signal Distribution
- Use this unit to distribute (1) composite video signal to (4) outputs.
- Power Options
- This unit will work with AC or DC power.
- Small Footprint
- Its small size makes it a versatile solution that works equally well in studio or mobile applications.
In the Box Ikegami IK-DA14 Video Distribution Amplifier Distribution Amplifier One-Year Warranty Against Defects in Material & Workmanship Table of Contents
|
Upload User Manual
Have you got an user manual for the Ikegami IK-DA14 Video Distribution Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersIkegami IK-DA14 Specs | Input | (1) composite video on BNC connector | | Output | (4) composite video on BNC connectors | | Input Impedance | 75 Ohms +/-5% | | Output Impedance | 75 Ohms +/-5% | | Frequency Response | 0 to 15mHz +/-0.5dB | | Gain | Unity +/-10% | | Differential Gain | <1% | | Differential Phase | <1° | | Tilt | Max H tilt: <1%
Max V tilt: <1% | | Power | DC operation: 12 to 18VDC isolated source
AC power: 18 to 28VAC, 60Hz
AC power draw: <1W
Power connector: 4-screw terminal block | | Dimensions (HxWxD) | 1.5 x 4.5 x 5.25" | | Weight | 1 lbs | | | | Package Weight | 1.55 lb | | Box Dimensions (LxWxH) | 12.7 x 6.4 x 2.3" |
