User Manual for Ikegami KIT-BX11-OD2 IP Network Camera with Day Night Aspheric Varifocal Lens and Outdoor Aluminum Camera Housing with Wall Bracket Kit Click to enlarge the picture
Contents of the user manual for the Ikegami KIT-BX11-OD2 IP Network Camera with
- Product category: Wired IP Cameras Ikegami
- Brand: Ikegami
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Ikegami Wired IP Cameras
|
User manual for the Ikegami KIT-BX11-OD2 IP Network Camera with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Ikegami product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Ikegami user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Ikegami product will considerably shorten its lifespan!
|
Product description The KIT-BX11-OD2 IP Network Camera with Day/Night Aspheric Varifocal Lens and an Outdoor Aluminum Camera Housing with Wall Bracket Kit from Ikegami includes an IPD-BX11 Hyper Wide Light Dynamic IP Network Camera, a 5 to 50mm F1.6 Lens, and a CAMH-400K 12" Outdoor Aluminum Camera Housing with Wall Bracket.
The IPD-BX11 Hyper Wide Light Dynamic IP Network Camera combines the benefits of an IP network camera with the Hyper Wide Dynamic technology. This sub-megapixel camera captures useful information from a given scene with great bandwidth requirements. This IP network camera produces lucid images and allows for low-voltage integration. Regardless of the lighting conditions, you can capture clear and natural images with this network camera. This sub-megapixel camera delivers a good balance of resolution and bandwidth usage for video surveillance.
The Day/Night Aspheric Varifocal Lens (5.5 to 50 mm) from Fujifilm is a high image quality monitoring lens with an optical performance supporting 1.3 Mp resolution. With a special optic glass, it is best suited for color, black and white, and Day/Night cameras. Broad range of the wide angle f5 to the telephoto 50 mm range supports various applications. The wide aperture of F1.6 optimizes its performance at low lighting intensity. This lens is designed with high-accuracy aspheric lens, low-dispersion glass, and high refractive-index glass to maximize optical performance. It has a built-in ND filter of T360 to allow support for high sensitivity cameras.
The MG Electronics CAMH-400K 12" Outdoor Aluminum Camera Housing can be used to house a CCTV box camera in an outdoor location. With its 12" exterior length, the inside of the housing is roomy enough to accommodate most camera and lens combinations. Included with the housing is an 8" wall mount bracket, also made of aluminum. This bracket features 360° rotation, so you can easily point the camera in the required direction. - IK-YV10X5HR4A-SA2L Day & Night HD Varifocal Lens (5.5 to 50mm) The Ikegami IK-YV10X5HR4A-SA2L Day & Night Aspheric Varifocal Lens (5.5 to 50mm) from Fujifilm is a high image quality monitoring lens with optical performance supporting 1.3 MP resolution. With a special optic glass, it is best suited for color, black and white and day and night cameras. Broad range of the wide angle f5 to the telephoto 50mm range supports various applications. The wide aperture of F1.6 optimizes its performance at low lighting intensity.
This lens is designed with high-accuracy aspheric lens, low-dispersion glass, and high refractive-index glass to maximize optical performance. It has a built-in ND filter of T360 to allow support for high sensitivity cameras. - CAMH-400K 12" Outdoor Aluminum Camera Housing with Wall Bracket The MG Electronics CAMH-400K is an inexpensive enclosure that can be used to house a CCTV box camera in an outdoor location. With its 11" exterior length, the inside of the housing is roomy enough to accommodate most camera and lens combinations. Included with the housing is an 8" wall mount bracket, also made of aluminum. This bracket features 360° rotation, so you can easily point the camera in the direction you need it to see.
- Universal mounting plate fits most brands of mounting brackets
- Bracket head rotates 360°
- Housing can be secured with an optional padlock
UPC: 759377300533 - IPD-BX11 Hyper Wide Light Dynamic IP Network Camera
In the Box Bundle Items IPD-BX11 Hyper Wide Light Dynamic IP Network Camera bzfraawssxsfduytswyx IK-YV10X5HR4A-SA2L Day & Night HD Varifocal Lens (5.5 to 50mm) CAMH-400K 12" Outdoor Aluminum Camera Housing with Wall Bracket - 8" (203mm) Indoor/Outdoor Aluminum Wall Bracket
Table of Contents
|
Upload User Manual
Have you got an user manual for the Ikegami KIT-BX11-OD2 IP Network Camera with Day Night Aspheric Varifocal Lens and Outdoor Aluminum Camera Housing with Wall Bracket Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - IK-YV10X5HR4A-SA2L Day & Night HD Varifocal Lens (5.5 to 50mm)
| Mount | CS | | Focal Length | 5.5 to 50 mm (10x) | | Focus | Manual | | Zoom | Manual | | Iris Range | F1.6 - T360 (equivalent to F360) | | Iris | Auto (DC Type) When power is turned off, iris will automatically close. | | Back Focal Distance | 7.50 mm (in air) | | Exit Pupil Position | From Image Plane: -43 mm | | Object Dimensions at M.O.D. | 1/3": Wide: 11.96 x 8.97" (304 × 228 mm)
Tele: 2.12 x 1.61" (54 × 41 mm)
1/4": Wide: 8.97 x 6.73" (228 × 171 mm)
Tele: 1.61 x 1.22" (41 × 31 mm) | | Angular Field of View | 1/3": Wide: 51.28° × 39.6°
Tele: 5.5° × 4.11°
1/4": Wide: 39.6° × 30.21°
Tele: 4.11° × 3.1° | | Cable Type | 9" (230 mm) | | Focusing Range | From Front of the Lens: ∞ - 0.3 m | | Coil Resistance | Drive Coil: 190 Ω
Damping Coil: 500 Ω | | Current Consumption | 23 mA (Max.) at DC 4V | | Weight | 3 oz (85 g) | | | | Box Dimensions (LxWxH) | 9.0 x 9.0 x 7.0" | - CAMH-400K 12" Outdoor Aluminum Camera Housing with Wall Bracket
| Indoor/Outdoor | Outdoor | | Mount Type | Wall (includes bracket) | | Compatible Cameras | CCTV box cameras | | Clear or Tinted | Clear | | Maximum Camera/Lens Size | Not specified | | Construction | Aluminum with beige finish | | Operating Temperature | Not specified | | Dimensions (L x W x D) | Outer: 5.50 x 4.25 x 11.00" (13.97 x 10.80 x 27.94 cm)
Interior: 4.25 x 4.25 x 8.25" (10.80 x 10.80 x 20.96 cm) | | Weight | Not specified | | | | Box Dimensions (LxWxH) | 13.1 x 10.0 x 5.1" | - IPD-BX11 Hyper Wide Light Dynamic IP Network Camera
