Product description You can capture brilliant images of coral reefs, whale sharks, and more at depths as great as 200', thanks to Ikelite's 200DLM/A Underwater Housing for the Olympus PEN E-PL8 Mirrorless Micro Four-Thirds Digital Camera. An Ikelite sync cord bulkhead and built-in TTL circuitry enable the connection of optional external strobes. Ikelite DS flash units can be used in TTL or manual exposure mode, while third-party strobes will work in manual mode.
Ergonomic mechanical controls, including push-buttons, knurled knobs, a dial, and a lever, afford access to virtually all camera functions. Built for durability, the enclosure is made in the USA from a corrosion-resistant polycarbonate and ABS plastic blend. It is white on the front, top, sides, and bottom, but clear in the back to allow you to monitor the O-ring seal and maintain your view of the camera's rear controls. An optional aluminum tray with a quick-release grip or two will afford improved balance and handling, while offering a way to attach optional lighting arms.
The housing ships without a required lens port, and accepts various, interchangeable dome and flat ports for a broad array of lenses. For full compatibility details, see the DLM Type A Port Chart. - Construction Details
-
- Depth rating: 200'
- Made by hand in USA from corrosion-resistant polycarbonate and ABS plastic blend
- White on front, top, sides, and bottom to reflect sunlight and keep camera cool when shooting on or above water's surface
- Clear in the back to allow you to monitor the O-ring seal and camera
- Two double-passivated, stainless steel locking latches are virtually unbreakable and make it easy to open and close the housing
- Rear O-ring seal design and placement prevent accidental twisting or stretching, and eliminate the need for a groove that can trap sand, dirt, or debris
- 1/2-20 threaded accessory port on the side of the housing allows for the easy installation of an optional Vacuum Kit (#47012), which will allow you to confirm the integrity of the watertight seal before diving
- Camera is installed and removed through the front of the housing
- Mounting plate allows for secure camera placement, and does not need to be removed for you to access the battery compartment or memory card slot
- Mounting plate has a 1/4"-20 threaded hole for connection to a tripod
- Controls and Handling
-
- Large, ergonomic, mechanical controls, including push-buttons, knurled knobs, a dial, and a lever, afford access to all camera functions except for the Fn and zoom buttons
- Shutter lever features Ikelite's updated design, which has made it more sensitive and ergonomic than the levers on many previous housings
- Optional Shutter Trigger Extension (#4077.93) can be added on to allow for easy shutter activation without removing your hand from a grip
- Redesigned push-buttons are even lighter in weight than the previously existing ones, and are also less prone to salt buildup
- Video recording button is bright red for quick, easy identification and anodized to resist corrosion
- Laser-engraved control symbols on the back of the housing won't come off or fade with time
- Controls are placed in the same configuration as they are on the camera, allowing for a smooth transition from shooting on land to diving, thanks to the muscle memory you've already developed
- Camera's large, bright LCD monitor is entirely visible through the back of the housing
- Two 1/4"-20 threaded mounts on the bottom of the housing allow for connection to an optional tray with grips, which improves balance and handling while adding attachment points for lighting arms
- Lens Port
-
- Ships without a required lens port
- Accepts various, interchangeable dome and flat ports for a broad array of lenses
- For complete compatibility details, see the port chart linked above
- Simply press the port on and tighten three thumb screws
- Strobe Connection and Operation
-
- An optional external strobe will be extremely helpful--and virtually essential--once you descend further than 15-20' underwater, except when shooting with color filters on very clear days with bright sunlight
- Strobe acts as a color-correction tool, restoring hues that get absorbed by water so that your images are vibrant and accurate
- Try to stay no more than 3-4' away from subject to preserve natural colors in images
- Ikelite bulkhead with hot shoe connection and integrated TTL circuitry enables reliable electrical triggering of external strobes via sync cords
- Circuit is fine-tuned to the PEN E-PL8 camera's flash exposure protocol, allowing for the most accurate exposure possible
- Circuit is powered by the strobe, so there are no batteries to change and there is no maintenance to be done
- Exposure compensation in TTL mode is supported using the camera's built-in control
- Ikelite DS strobes, such as DS50 (above serial number 70000), 51, 125 (above serial number 5000), 160, 161, and 200 (above serial number 7163), are operable in TTL or manual mode
- Third-party strobes, such as those from Sea & Sea, INON, and Nikonos, operable in manual mode only
- Cord attachment is as easy as screwing in a light bulb, and the threaded fit prevents accidental detachment during use
- Bulkhead connector has been moved to the top of the housing to keep cords out of your way and reduce strain on the cord ends
- Housing ships without required sync cord and accepts following ones: Ikelite-to-Ikelite TTL (#4103.51), Ikelite-to-Ikelite TTL Dual (#4103.52), Sea & Sea/INON-to-Ikelite Non-TTL (#4118.1), Sea & Sea/INON-to-Ikelite Non-TTL Dual (#4118.2), Nikonos SB-to-Ikelite Non-TTL (#4116.31), and Nikonos SB-to-Ikelite Non-TTL Dual (#4116.32)
UPC: 883711054551 In the Box Ikelite 200DLM/A Underwater Housing for Olympus PEN E-PL8 - 0110 O-Ring dtrtzdcvwdwbtawavxfrrfzwxazfb
- O-Ring for Select Strobes and Housings dtrtzdcvwdwbtawavxfrrfzwxazfb
- ICS Bulkhead Cap (Replacement)
- Control + Push Button Tip Assortment for Compact Digital Housings
- 1/8" Hex Head Allen Wrench for Control Knobs on Housings
- #0184.1 Tube of Silicone Lubricant
- Limited 2-Year Warranty
