Product description

• Ikelite Underwater Action Housing for Sony Cyber-shot RX100 or RX100 II Capture Full HD 1080 video and still images at depths as far down as 200' beneath the surface with Ikelite's compact, lightweight Underwater Action Housing for the Sony Cyber-shot RX100 or RX100 II Digital Camera. The enclosure is designed primarily for video recording, as there is no strobe connector and the camera's flash is not accessible. However, quality photos are still possible with an optional constant light source at any depth or with available sunlight down to about 60' underwater.

  The housing affords access to important camera functions via ergonomic, mechanical controls, including pushbuttons and a knurled dial with a small lever. Built for durability, the housing is made in the USA from a corrosion-resistant ABS and polycarbonate blend, which is light gray/white on the front, sides, top, and bottom but clear in the back to allow you to monitor the O-ring seal and rear camera controls.

  The housing features a built-in, flat, optical glass lens port with a 3.0" diameter. Optional, accessory wide-angle and macro conversion lenses as well as color-correction filters can be attached to the front of the port to enhance your images.
  Construction Details
  • • Features a depth rating of 200'
    • Constructed by hand in USA from corrosion-resistant ABS and polycarbonate blend, which is light gray/off-white on front, sides, top, and bottom, but clear in back to allow you to monitor O-ring seal and rear camera controls
    • Light gray/off-white color reflects sunlight to keep camera cool when shooting at or above water's surface, and also offers better contrast for improved viewing of camera, monitor, and O-ring seal
    • Controls made of acetyl plastic
    • Compact, lightweight design is well-suited to action video recording and also makes for easy storage and transport
  Optional Lighting
  • • Designed primarily for video recording, as there is no strobe connector and the camera's flash is not accessible
    • Quality photos still possible with an optional constant light source at any depth, or with available sunlight down to about 60' underwater
    • Many optional lights designed for video and photo capture can be mounted to optional lighting arms for use with housing
    • At depths greater than about 60', or when diving in dark conditions, an external light source is necessary to provide adequate illumination and restore colors that get absorbed by water and turned into muted blue and green shades
    • Choose a light with a high lumen output, a wide and even beam, and--ideally--a daylight-balanced color temperature for best results
    • To preserve natural colors of subjects and environments in images, try to stay within arm's reach of what you're shooting. The further away you go, the more light is absorbed by water--which acts like a big blue/green filter
  Controls and Handling
  • • Affords access to important camera functions via ergonomic, mechanical controls, including push-buttons and a knurled dial with a small lever
    • Shutter button, power on/off, zoom (wide/telephoto) lever, movie recording, Fn button, menu, up/down/left/right controls, FUNC/SET, playback, and delete button are all accessible
    • Control symbols engraved into back of housing won't peel off or fade with time
    • Central, bottom-mounted 1/4"-20 threaded hole provides attachment point for optional tray with handles, which improves balance while offering mounting points for lighting arms
    • Slightly positive buoyancy in fresh water
  Lens Port
  • • Built-in, flat, optical glass lens port with a scratch-resistant front element, 3.0" diameter, and 67mm filter thread
    • Provides full use of the camera's zoom range without vignetting
    • Optional, external, 67mm threaded wide-angle and macro accessory lenses from Ikelite, INON, Epoque, and other manufacturers can be attached directly to front of port
    • Wide-angle lenses provide greater angle of coverage to allow you to fit more in frame, while macro lenses magnify your image to enable close-ups with greater clarity and detail
    • Both types of conversion lenses get you closer to subjects, reducing amount of water in between you and therefore minimizing distortion
    • Wide-angle lenses often result in some vignetting, which can be reduced/eliminated by zooming in, using smaller aperture, or cropping in editing/post-production phase
    • Recommended WD-3 Wide Angle Dome provides mid-range angle of view with no vignetting
    • Optional, external color-correction filters, available for tropical blue and green water, can be attached via press-fit method to front of port to restore hues that get absorbed underwater
    • Since color filters reduce amount of light that enters lens, they are most effective in sunny conditions at depths of about 80' or less
    • Color filters not recommended for use in conjunction with external lighting, as combination can throw off color accuracy in images
    • Most wide-angle lenses require a filter with a 3.6" diameter
  UPC: 883711052007
• Sony Cyber-shot DSC-RX100 Digital Camera (Black) Housed in a sophisticated aluminum body, the Sony DSC-RX100 Digital Camera (Black) features a 20.2 megapixel Exmor CMOS image sensor that excels in ultra low-light situations. It's equipped with a brilliant f/1.8 Carl Zeiss Vario-Sonnar T Lens with a focal length of 10.4-37.1mm (35mm equivalent: 28-100mm). It also has an integrated pop up flash. You can record ultra high-definition still images in JPEG format, RAW format, or even both simultaneously. The camera also affords Full HD 1080p video capture at 60 frames per second (fps). Plus, it supports a full range of controls for video and still shooting that range from iAUTO to P/A/S/M (Program, Aperture Priority, Shutter Priority and Manual).The RX100 is loaded with shot-enhancing features and high-quality components. The Exmor CMOS image sensor and refined BIONZ image processor work together to facilitate fast DSLR-like focusing speeds even in low-light - and without sacrificing any detail. The lens supports 3.6x optical zoom and 7.2x clear image digital zoom. It also features a multi-layered T coating that dramatically reduces ghost and flare caused by light reflection. For added convenience, the RX100 is equipped with a 3" Xtra Fine LCD display so you'll be able to quickly scroll through menus and pictures. The display even features WhiteMagic technology for increased visibility under intense sunlight.Other features include a customizable function button that supports up to seven different functions and a memory recall (MR) that can memorize up to three groups of preferred settings. The camera also features Optical SteadyShot with Active Mode, which eliminates blurry images when you're walking with the camera. Sony's even bolstered the image stabilization with an electronic image stabilization that affords blur-free movie shooting and steady zooming in unsteady situations. You can use the Auto Portrait Framing function to capture an additional, beautifully framed and balanced full resolution portrait, when you're out shooting stills. The camera also supports four focus modes, auto HDR, multi-aspect ratio recording, a digital level gauge, multi-frame noise reduction and much more.Sony designed the DSC-RX100 for capable photographers looking for a high-end compact camera to take on the go. Anyone who spends a lot of time shooting family and friends will also appreciate the camera's Face Detection and Face Registration technology. The RX100 can detect and register up to eight faces. Plus, it will automatically adjust focus, exposure, white balance and flash to ensure you get a clear and crisp shot of those closest to you. You can even tell the camera to prioritize children or adults. With a laundry-list of features and excellent components, the RX100 offers amazing quality and creative freedom in a stylish, compact package.
  20.2 Megapixel Exmor 1" CMOS Image Sensor
  • The massive 20.2MP Exmor 1" CMOS sensor captures ultra-high definition images that take full advantage of the camera's sharp Carl Zeiss Vario-Sonnar T lens. The sensor enables advanced column A/D processing that reduces noise levels, resulting in astonishing low light images with incredible smooth and clear details
  Bright f/1.8 Carl Zeiss Vario-Sonnar T Lens with 3.6x Optical Zoom
  • This large-diameter F1.8 Carl Zeiss Vario-Sonnar T lens delivers refined background defocusing. It also features a premium multi-layered T coating that dramatically reduces ghost and flare caused by light reflection. Effective focal length is 10.4-37.1mm, while 35mm equivalent lengths are as follows: Still 16:9: 29-105mm; Still 4:3: 30-108mm; Still 3:2: 28-100mm; Still 1:1: 36-127mm; Movie 16:9: 29-105mm (Std), 33-120mm (Active); Movie 4:3: 36-128mm (Std), 41-146mm (Active)
  P/A/S/M Modes for Video & Stills
  • Enjoy a full range of controls for video and still shooting from iAUTO mode to P/A/S/M: Program, Aperture Priority, Shutter Priority and Manual. There are even on-screen prompts which help you refine your skills, build your confidence and exercise greater creative control
  Capture JPEG Files, RAW Files, or Both
  • The RX100 saves pictures as compact JPEG files and/or ultra-high quality RAW files. RAW files save images prior to de-mosaicing, white balance, sharpness and color enhancement. This retains maximum latitude for enhancing the image on your PC
  Full HD 1080/60p Video Capture
  • Record crystal clear movies in Full HD 1080p at 60 fps. This provides stunning, fast motion video with less distortion for playback on your HDTV. Plus, with dual recording for stills and movies, you can shoot both at the same time
  Low-Light ISO 6400 Sensitivity
  • Capture incredibly clear low-light pictures without sacrificing detail, thanks to the low-noise Exmor CMOS image sensor and refined BIONZ image processor
  High-Speed Auto Focus
  • To improve focusing speed and sensitivity, the Exmor CMOS sensor uses its rapid throughput to deliver high-quality image signals to the camera's BIONZ processor, which provides intelligent response data to a high-speed actuator motor in the lens. The result is fast, DSLR-like focusing speeds even in low light
  Up to 10 fps Burst Mode
  • Capture full 20.2 megapixel resolution images at up to 10 fps, helping to ensure that the decisive moment is captured such as the soccer ball flying into the goal. In addition, a mechanical shutter helps reduce distortion when continuously shooting moving subjects
  Large 3" Xtra Fine LCD Display
  • The 3" (1229k dots) Xtra Fine LCD Display makes it easy to scroll through menus and preview pictures. Plus, the large display delivers brilliant-quality still images and movies while enabling easy focusing operation. It also features WhiteMagic technology, which increases visibility in bright daylight
  Customizable Function Button
  • Assign up to seven different functions to the function button, to allow quick access to your most frequently used functions
  Optical SteadyShot with Active Mode
  • Optical SteadyShot with Active Mode enables blur-free movies even while walking. Plus, the camera-shake compensation using Optical SteadyShot/Active Mode has been improved with the addition of electronic image stabilization, which makes it easier to obtain sharp, blur-free movies even when zooming in unsteady situations, such as shooting with one hand while walking
  Memory Recall
  • MR (memory recall) mode can memorize up to three groups of the user's preferred settings. The settings include zoom magnification, white balance, exposure compensation, date and grid lines. This enables quick switching of settings at the right moment
  Sophisticated Design with Pop Up Flash
  • The sophisticated aluminum body is lightweight, slim and strong. There's even an integrated pop up flash, which affords the convenience of flash photography everywhere you go
  Auto Portrait Framing
  • Simply photograph a person and Auto Portrait Framing will save an additional, optimally framed image in portrait or landscape orientation. This mode combines Face Detection and By Pixel Super Resolution technologies with rule of thirds to provide beautifully composed and appealingly balanced full resolution portraits
  Auto HDR Mode
  • Using auto HDR mode allows you to capture more scene dynamic range than a single exposure can handle - and more range than photo film. It combines the best highlight detail from one shot, the best mid-tones from a second shot and the best shadow detail from a third shot for one incredible image (up to 6 EV stops). Plus, it works in a split second (recommended for still subjects)
  Face Detection / Face Registration
  • The camera can automatically detect and register up to eight individual faces and adjust focus, exposure, white balance and flash to help deliver crisp, properly lit images of family and friends. You can even prioritize children or adults
  Multi-Aspect Ratio Recording for Still Images
  • Capture still images in any of four aspect ratios - 1:1, 2:3, 4:3, or 16:9 (vertical to horizontal). This provided the freedom to choose a ratio that matches the scene or the specific shooting purpose
  3.6x Optical Zoom & 7.2 Digital Zoom
  • Most digital zooms use electronic cropping to get closer to the subject, resulting in decreased image sharpness. With Clear Image Zoom the powerful processor compares patterns found in adjacent pixels and creates new pixels to match selected patterns, resulting in more realistic, higher-quality images. Clear Image Zoom digitally doubles optical zoom for closer photos
  Four Focusing Modes
  • This camera has two Autofocus modes: Single-shot AF (AF-S) or Continuous AF (AF-C), which tracks moving objects. It also has Manual Focus for manual focusing freedom, and Direct Manual Focus (DMF), that first uses autofocusing to focus on the subject, and then allows fast and easy switching to manual focusing for even more precise adjustment
  MF Assist & Peaking
  • Manual focus becomes much easier because peaking highlights the edges that are in focus in your choice of three colors (white, red, or yellow). This is especially helpful during macro or portrait photography where your focus setting can make or break your shot
  Multi-Frame Noise Reduction
  • In this mode, the camera automatically shoots multiple images and layers them to produce a single noise-free image. This method provides noise reduction equivalent to a 2-stop lower shutter speed while maintaining the same aperture setting. Since the Multi Frame NR mode can be used in combination with P/A/S/M modes, it expands the user's shooting flexibility
  Photo Creativity
  • The Photo Creativity interface enables you to easily enjoy the creative expression of SLR-quality digital imaging without complex jargon. Changes can be combined, removed and viewed in real time on the LCD display, which makes it a breeze to make adjustments. Choose from several different Photo Creativity functions using the convenient control wheel and center button including: Picture Effect, Background Defocus, Color, Brightness and Vividness
  Picture Effect Mode
  • Picture Effect is a fun and simple way to convert ordinary landscapes and portraits by heightening mood and emphasizing certain attributes. Effects include: Soft Focus, Posterization, Retro Photo, High Contrast Monochrome, Rich-Tone Monochrome, Miniature, Soft High-key, Toy Camera, Pop Color, Partial Color, Watercolor Painting, HDR Painting and Illustration
  Creative Style Settings
  • Control how the camera processes your images with six finishing styles: Standard, Vivid, B&W, Sunset, Portrait and Landscape. You can even fine-tune contrast, saturation and sharpness to your personal taste
  Sweep Panorama Mode
  • Capture expansive landscapes automatically. Press the shutter and sweep vertically or horizontally. The camera does the rest by continuously shooting images and stitching them together
  Superior Auto Mode
  • In order to get cleaner, more dynamic pictures and fewer missed shots, the camera automatically recognizes the correct scene mode, then quickly shoots and combines up to six shots to produce images with greater clarity, optimum dynamic range using Backlight Correction HDR technology, and lower image noise using six shot layering technology. Superior Auto can intelligently detect 33 scenes for still images and movies, making it easy to get the best shot
  Intelligent Scene Recognition Mode
  • Intelligent Scene Recognition (iSCN) automatically detects 33 different types of scenes for photos and 44 scenes for movies, and then selects the appropriate camera settings. In Auto Mode, the camera takes a single shot using the optimal settings. In Advanced Mode, the camera takes a photo with the optimal settings and, if in difficult lighting (low light or back light) immediately takes a second photo with another optimized setting so you can choose which to keep
  Digital Level Gauge
  • The digital level gauge allows for easier leveling of the camera
  UPC: 027242856110

• Underwater Action Housing for Sony Cyber-shot RX100 or RX100 II xxdwvbexvsedrfex
• 1cc Tube of Silicone Lubricant
• Port Cover
• Lanyard
• Limited 2-Year Warranty

• Sony - Cyber-shot DSC-RX100 Digital Camera (Black) xxdwvbexvsedrfex

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Ikelite Underwater Action Housing for Sony Cyber-shot RX100 or RX100 II

  Depth Rating	200' / 61 m
  Control Type	Mechanical pushbuttons and knurled dial with a small lever
  Controls	Afford access to important camera functions: Shutter button, power on/off, Zoom (wide/telephoto) lever, movie recording, manual white balance, Fn button, menu, up/down/left/right controls, FUNC./SET, playback, and delete button
  Material of Construction	Housing: ABS and polycarbonate blend Controls: Acetyl plastic
  Lens Port	Built-in, flat, optical glass lens port Scratch-resistant front element 3.0" / 76 mm diameter Accepts optional, external 67mm threaded wide-angle and macro accessory lenses from Ikelite, INON, Epoque, and other manufacturers Accepts optional, external color-correction filters via press-fit method
  Buoyancy	Slightly positive in fresh water
  Lighting	Optional constant light source with high lumen output and a wide, even beam highly recommended No strobe connector on housing Camera's flash not usable
  Mounting	Central, bottom-mounted 1/4"-20 threaded hole provides attachment point for optional tray with handles Tray improves balance while offering mounting points for lighting arms
  Dimensions	6.0 x 4.6 x 5.7" / 15.2 x 11.7 x 14.4 cm
  Weight	1.1 lb / 0.5 kg

  Box Dimensions (LxWxH)	6.8 x 5.5 x 5.4"

• Sony Cyber-shot DSC-RX100 Digital Camera (Black)

  Pixels	Actual: 20.9 Megapixel Effective: 20.2 Megapixel
  Sensor	1.0" (13.2 x 8.8 mm) CMOS
  File Formats	Still Images: JPEG, RAW Movies: AVCHD
  Max Resolution	20 MP: 5472 x 3648
  Aspect Ratio	1:1, 3:2, 4:3, 16:9
  Image Stabilization	Optical & Digital

  Lens	7 Elements in 6 Groups Effective Focal Length: 10.4 to 37.1mm (35 mm Equivalent: 28 to 100mm) Aperture: f/1.8 (W) to f/4.9 (T)
  Zoom	Optical: 3.6x Digital: 7.2x
  Focus Range	Wide: 1.97" to Infinity / 5 cm to Infinity Telephoto: 21.65" to Infinity / 54.99 cm to Infinity

  ISO Sensitivity	Auto, 125 to 6400 (Extended Mode:Auto, 125 to 25600)
  Shutter	Type: Mechanical Speed: 1 to 1/2000 Second in Program Mode Type: Mechanical Speed: 4 to 1/2000 Second in Auto Mode Type: Mechanical Speed: 8 to 1/2000 Second in Aperture Priority Mode Type: Mechanical Speed: 30 to 1/2000 Second in Manual Mode
  Exposure Metering	Center-Weighted, Multi, Spot
  Exposure Modes	Modes: Aperture Priority, Auto, Manual, Programmed Auto, Shutter Priority Compensation: -3 EV to +3 EV (in 1/3 EV Steps)
  White Balance	Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent, Fluorescent (Day White), Fluorescent (Natural White), Fluorescent (White), Incandescent, Shade
  Continuous Shooting	Up to 10 fps at 20.2 MP for up to Exposures
  Self-Timer	2, 10 Sec
  Interval Recording	No

  Flash Modes	Auto Fill-In Off Rear Sync Slow Sync
  Built-In Flash	Yes
  Effective Flash Range	Wide:1.0 to 56.10' / 0.3 to 17.1 m Telephoto:1.80 to 20.7' / 0.55 to 6.3 m

  Memory Card Type	SD SDHC SDXC Memory Stick Duo Memory Stick Pro Duo Memory Stick PRO HG-Duo

  Video Recording	Yes, NTSC
  Resolution	1920 x 1080p: 60 fps 1920 x 1080i: 60 fps 1440 x 1080p: 30 fps 640 x 480p: 30 fps

  Video Clip Length	Up to 29 Minutes
  Audio Recording	With Video

  Screen	3.0" LCD Rear Screen (1,229,000 Pixels)

  Connectivity	1 x HDMI D (Micro), USB 2.0

  Battery	1 x NP-BX1 Rechargeable Lithium-Ion Battery Pack
  AC Power Adapter	AC-UD10/11 (Included)

  Dimensions (W x H x D)	4.0 x 2.3 x 1.4" / 101.6 x 58.2 x 35.9 mm
  Weight	8.47 oz / 240 g with Battery & Memory Stick Duo

  Box Dimensions (LxWxH)	6.1 x 5.7 x 3.9"
