Product description The Impact Soft n' Natural 3-Light LED Kit with Case was put together by to offer image-makers a 3-point, multi-use setup that's suitable for fashion, portraiture, products, ecommerce and small productions. The kit includes three 4-socket fixtures, each with four 60W daylight-balanced LED bulbs, a 20 x 27.5" softbox and a 6' light stand. A sturdy kit case with a shoulder strap and a 35 lb load capacity is included for storage and transport. - 3 x Impact 4 Socket Fluorescent Fixture The 4 Socket Fluorescent Fixture from Impact is a lightweight fixture in a polycarbonate housing that accepts Edison-base compact fluorescent lamps up to 50W, for a four-socket total of 200W. The fixture's bracket tilts and locks into position and features a standard 5/8" receiver that mounts on any 5/8" stud or accessory, and also accepts standard photo umbrellas. UPC: 847628563599
- 3 x Impact 50 x 70 cm Softbox for Fluorescent Fixtures The 50 x 70 cm Softbox for Fluorescent Fixtures by Impact is a light modifier that softens the output from Impact FF-S1 and FF-S4 single- and four-socket fluorescent fixtures, as well as Impact's SF-ABRL160 Slave Flash. Installation is easy - no speed ring is needed; each of these heads has four receptacles located around the face of the fixture. The softbox can be used with up to four 50W fluorescent lamps for a total of 200W. UPC: 847628563629
- 3 x Impact Light Stand, Black (6') This 6' Impact Black Light Stand is one of the most economical light stands available. It has a 5/8" stud top with a 1/4"-20 thread.
- For small light fixtures or boom arms.
UPC: 847628011953 - 12 x Raya 60W LED Daylight Studio Bulb Create a photo quality continuous light source anywhere with a standard E26 Edison socket with this 60W LED Daylight Studio Bulb from Raya. Able to produce daylight-balanced 5400K light, this bulb can find uses in a variety of applications, especially being multi-voltage and switching from 100-240 VAC for worldwide use. Equivalent to a 250W incandescent bulb, it delivers a brightness of 4200 lumens at 3.3'. Also, it has a CRI of 84 for creating accurate colors. LED technology allows the light to run cool, and this is further assisted by a built-in fan. Additionally, it has a frosted finish for a soft output, as well as a rated average lifetime of 30,000 hours. UPC: 847628599475
- Impact Light Kit Bag #3 - Holds 2 Monolights with Light Stands and Accessories The Impact Light Kit Bag #3 (Black) is a soft padded case designed to transport and protect a 2 monolight lighting kit. It has space to hold 2 monolights with reflectors, cables, umbrellas and light stands. It is carried by 2 overlapping carrying handles or the included shoulder strap.
- Bag Basics
-
- Fits 2 monolight lighting system
- Soft padded lighting bag
- Holds up to 35 lbs
- Carrying Options
-
- Two overlapping handles
- Removable, adjustable shoulder strap
UPC: 847628011885 In the Box - 3 x 4 Socket Fluorescent Fixture xywsbvrstxxbvttzeaxr
- Limited 1-Year Warranty
- 3 x 50 x 70 cm Softbox for Fluorescent Fixtures
- 3 x Light Stand, Black (6')
- 12 x Raya - 60W LED Daylight Studio Bulb
- Light Kit Bag #3 - Holds 2 Monolights with Light Stands and Accessories
Table of Contents
|
Upload User Manual
Have you got an user manual for the Impact Soft n' Natural 3-Light LED Kit with Case in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - 3 x Impact 4 Socket Fluorescent Fixture
| Input Voltage | 120 VAC | | Lamps | 4 CFL (compact fluorescent lamps) | | Ballast | In lamps | | Mounting | 5/8" / 16 mm | | Dimensions (LxWxH) | 6.5 x 6.25 x 7.25" / 16.5 x 15.8 x 18.4 cm | | Weight | 1.3 lb / 590 g | | | | Box Dimensions (LxWxH) | 8.45 x 7.65 x 6.15" | - 3 x Impact 50 x 70 cm Softbox for Fluorescent Fixtures
| Shape | Rectangular | | Interior | Silver | | Requires Speed Ring | No | | Accepts Grids | No | | Maximum Wattage | 250 W | | Removable Front Face | Yes | | Removable Interior Baffle | No | | Rectangular Dimensions | W: 20.0 x H: 27.5" / W: 50.0 x H: 70.0 cm | | | | Box Dimensions (LxWxH) | 19.85 x 8.4 x 1.5" | - 3 x Impact Light Stand, Black (6')
| Load Capacity | 4 lb / 1.8 kg | | Mounting Options | 1/4"-20 Male Thread
5/8" Stud | | Maximum Working Height | 6' / 1.8 m | | Minimum Working Height | 26.3" / 66.8 cm | | Collapsed Height | 26.3" / 66.8 cm | | Footprint Diameter | 30" / 76.20 cm | | Leg Shape | Round | | Accepts Wheels | Yes | | Air Cushioned | No | | Detachable Base | No | | Leveling Leg | No | | Reverse Legs | No | | Finish | Black | | Weight | 1.8 lb / 0.8 kg | | | | Box Dimensions (LxWxH) | 26.4 x 3.5 x 3.5" | - 12 x Raya 60W LED Daylight Studio Bulb
| Type | LED | | Wattage | 60 W | | CRI | 84 | | Base | E26 Edison | | Color Temperature | 5400K | | Brightness | 4200 lumens at 3.3' / 1 m | | Dimming | No | | Finish | Frosted | | Cooling | Fan | | Average Life Hours | 30,000 hours | | Power Requirements | 100-250 VAC, 50/60 Hz | | Dimensions (Diam. x L) | 3.7 x 5.9" / 9.4 x 14.6 cm | | Weight | 8.4 oz / 238 g | | | | Box Dimensions (LxWxH) | 11.8 x 6.25 x 3.8" | - Impact Light Kit Bag #3 - Holds 2 Monolights with Light Stands and Accessories
| Material | Nylon | | Type of Closure | Zipper | | Exterior Dimensions | 36 x 9 x 9" (91.4 x 22.6 x 22.6 cm) (LxWxH) | | Interior Dimensions | 35 x 8 x 8" (88.9 x 20.3 x 20.3 cm) (LxWxH) | | Accommodates | 2 monolights with reflectors, cables, umbrellas and light stands | | Carrying/Transport Options | Carrying handles
Shoulder strap | | Load Capacity | 35 lbs (15.88 kg) | | Weight | 4.05 lbs (1.837 kg) | | | | Box Dimensions (LxWxH) | 52.0 x 8.0 x 8.0" |
