User Manual for Intel Compute Stick Click to enlarge the picture
Contents of the user manual for the Intel Compute Stick
- Product category: PC Sticks Intel
- Brand: Intel
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Intel PC Sticks
 |
User manual for the Intel Compute Stick contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Intel product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Intel user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Intel product will considerably shorten its lifespan!
|
Product description Transform your display into a fully functional computer with the Compute Stick from Intel. This over-sized thumb drive PC offers performance similar to a desktop computer and allows you to stream online videos, play games, work on projects, and more. On the inside, it sports a quad-core Intel Atom processor along with 2GB of RAM so you can simultaneously run multiple software programs. It connects to any HDMI-equipped monitor or TV and delivers high-resolution images utilizing integrated Intel HD Graphics. Additionally, it supports multi-channel audio through the same HDMI connection. For long-term storage, it is outfitted with a 32GB flash storage drive that provides instant access to your programs and data. You can expand its storage capacity by inserting an optional micro-SD card into the memory card slot, which can accept a 128GB micro-SDXC card.
This Compute Stick PC delivers full plug-and-play connectivity by offering USB 2.0 and USB 3.0 ports for connecting with a printer, storage drive, or other USB devices. With built-in 802.11ac Wi-Fi, it lets you wirelessly access the Internet to check emails and browse websites as well as a network for sharing files and videos. Another included wireless feature is Bluetooth 4.0 that lets you control the Stick PC with your Bluetooth keyboard and mouse from the couch in a living room or on the other side of a conference room. Bundled along with the Intel Compute Stick to ensure you stay productive are an HDMI extender cable and a 5V, 3A micro USB adapter for providing it with power. Please note that this version of the Intel Compute Stick does not come with an installed operating system. You will need to install your own operating system. - Quad-Core Intel Atom Z3735F Performance
- This Stick PC features a quad-core 1.44 GHz Intel Atom x5-Z8300 processor, with 2MB of L2 cache. With Intel Burst Performance technology, the maximum clock rate this processor can achieve is 1.84 GHz. Having four cores also allows the system to run multiple programs at the same time without slowing down the computer.
- Computer When, Where, and How You Want
- The Intel Compute Stick is a computer-on-a-stick device that's ready to go right out of the box. It offers a complete PC experience on an ultra-small, power-efficient device that is just 4" long, yet packs the power of a quad-core processor, on-board flash storage, Wi-Fi connectivity, and a micro SD card slot for additional storage. It's everything you prefer about your desktop computer in a device that fits in the palm of your hand.
- Personal PC
- The Compute Stick connects to your HDMI-enabled TV or monitor to provide you with the storage and performance needed for light productivity and gaming as well as social networking, web browsing, and streaming online media.
- Business Ready
- For small- to medium-sized businesses, the Compute Stick can be utilized as a thin-client solution for delivering ultra portability and reliable plug-and-play simplicity with access for on-the-fly support.
- PC-like Embedded
- You can use the Intel Compute Stick to create digital signage kiosks with no-effort installation and deliver streaming or static HD content on displays located anywhere.
UPC: 735858308168 In the Box Intel Compute Stick 5V, 3A Power Connector with Micro-USB Cable HDMI Extender Cable Limited 1-Year Warranty Specification PDF 1.3mb Table of Contents
|
Upload User Manual
Have you got an user manual for the Intel Compute Stick in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersIntel BLKSTK1A32SC Specs | | | CPU | 1.44 GHz Intel Atom x5-Z8300 Quad-Core | | Maximum Boost Speed | 1.84 GHz | | L3 Cache | 2 MB | | Memory Type | DDR3L | | Total Installed Memory | 2 GB | | Memory Configuration | 2 GB (Onboard) | | Available Memory Slots | None | | Buffered Memory | No | | ECC Memory | No | | Graphics Type | Integrated | | GPU | Intel HD Graphics | | | | Total Installed Capacity | 32 GB | | Solid State Storage | 1 x 32 GB Integrated eMMC | | Optical Drive | None | | | | Ports | 1 x USB Type-A (USB 2.0)
1 x USB Type-A (USB 3.1 Gen 1) | | Display | 1 x HDMI Output | | Audio | None | | Built-In Speakers | None | | Built-In Microphones | None | | Media Card Slots | 1 x microSDXC | | | | Ethernet | None | | Wi-Fi | Wi-Fi 5 (802.11ac) | | Bluetooth | 4.0 | | | | Dimensions | 4.4 x 1.5 x 0.5" / 11.18 x 3.81 x 1.27 cm | | | | Package Weight | 0.9 lb | | Box Dimensions (LxWxH) | 6.3 x 5.3 x 2.7" |
