User Manual for IOGEAR MiniView Extreme Multimedia KVMP Switch with USB Cables - 2-Port KVM, Peripherals and Audio with Optional PS 2 Click to enlarge the picture
Contents of the user manual for the IOGEAR MiniView Extreme Multimedia KVMP Switch
- Product category: KVM Switches IOGEAR
- Brand: IOGEAR
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for IOGEAR KVM Switches
 |
User manual for the IOGEAR MiniView Extreme Multimedia KVMP Switch contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any IOGEAR product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official IOGEAR user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a IOGEAR product will considerably shorten its lifespan!
|
Product description Multi-Monitors: Maximizing Multitasking Read More euxxbsbdcwzsyvxvazuybfrrv This KVM & Peripherals Switch is the best in multimedia technology. Now, prosumers can use one computer, mouse and keyboard as controllers via IOGEAR's ultra-fast MiniView Extreme Multimedia 2-Port KVMP Switch with USB cables. This KVMP switch allows up to two direct and 127 daisy-chained USB or PS/2 computer connections, two compatible peripherals, and audio/microphone support to be operated from one console. Easily control all attached peripherals with a single keyboard, monitor and mouse; your time and money are precious. Considering all the power in the MiniView Extreme, it is hard to believe that it is contained in a neat 5.2 x 1.7" encasement. It fits anywhere your ideas will go. The MiniView Extreme features premium configuration with multi-platform support for Windows, Macintosh and Sun Systems using either USB or PS/2 (additional cables needed for PS/2, IOGEAR part No. G2l5302P). It also allows asynchronous switching between consoles and peripheral devices by using Hot Keys or On Screen Display (OSD). With its easy installation, LED status monitors, 2048 x 1536 high-resolution support and three-year warranty, no compact KVM switch could be closer to perfection. - Maximize Control While Minimizing Clutter
- This Ultimate KVMP Switch allows up to two USB PS/2 computers, two compatible peripherals, and audio/microphone support to be operated from one console. KVMP Switch also carries daisy-chain capabilities that allows connection of up to 127 different USB devices. Easily control all attached peripherals with a single keyboard, monitor and mouse; your time and money are precious.
- Expanded Platform Support
- The MiniView Extreme features premium configuration with multi-platform support for Windows, Macintosh and Sun Systems using either USB or PS/2 (additional cables needed for PS/2, IOGEAR part No. G2l5302P).
- Streamlined Size to Fit Every Work Environment
- Unbelievable power is contained in this extra small console. Its surprising dimensions, 5.2 x 1.7 x 3.5", seem impossible considering its exceptional features. Made out of a durable metal and plastic encasement, the MiniView Extreme never ceases to surprise prosumers in need of perfection and convenience.
- High-Resolution Precision
- MiniView Extreme supports up to 2048 x 1536 resolution, giving users superior image quality for heavy editing, detailed graphics and more.
- Peripheral Choice Convenience
- The MiniView Extreme wants the user to work with outstanding ease. That is why it allows asynchronous switching between consoles or peripheral devices by using Hot Keys or On Screen Display (OSD).
- Multi-Computer Precision
- Utilize IOGEAR's status-monitoring LEDs, On Screen Display (OSD), and its user-friendly interface for all of your extended computer environments.
- IOGEAR's Three-Year Warranty
- Your prosumer tool is protected by IOGEAR's guaranteed three-year warranty.
UPC: 881317000453 In the Box IOGEAR MiniView Extreme Multimedia KVMP Switch with USB Cables - 2-Port KVM, Peripherals and Audio with Optional PS/2 MiniView Extreme Multimedia KVMP Switch 2 x USB KVM Bonded Cable Quick Start Guide Power Adapter User Manual Firmware Upgrade Cable Warranty Card Table of Contents
|
Upload User Manual
Have you got an user manual for the IOGEAR MiniView Extreme Multimedia KVMP Switch with USB Cables - 2-Port KVM, Peripherals and Audio with Optional PS 2 in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersIOGEAR GCS1732 Specs | Max Computer Connections | 2 Direct connections; up to 127 Daisy-chained USB devices | | PC Connectors | Keyboard, Mouse, and Monitor-SPDB15: x2
Audio: x2
Stereo speakers: x2
Microphones: x2
Peripherals-USB Type A: x2 | | Console Connectors | Monitor-HDB-15 Female: x1
Mouse-USB Type A: x1
Keyboard-USB Type A: x1
Audio: x1
Stereo speaker: x1
Microphone: x1
Flash ROM Upgrade-RJ11 socket: x1 | | Video Resolution | 2048 x 1536 | | Scan Interval | 5 seconds | | Port Selection | Push Button and Hot Keys | | Enclosure | Plastic/Metal | | System Requirements | Computers with USB or PS/2 connections (additional cables needed for PS/2 computers, USB peripheral ports will not function when using PS/2 cables.)Windows 98, 98SE, ME, 2000, XP
Mac OS 8.6 or greater
Sun Solaris work station
Linux, UNIX and other USB supported systems
Additional drivers and support may be needed
Audio: Only support 2-piece, powered speakers systems. | | Power Requirements | 5V DC | | Dimensions (WxHxD) | 5.2 x 1.7 x 3.5" (13.2 x 4.3 x 8.9 cm) | | Weight | 0.75 lbs (0.34 kg) | | Warranty | 3-Year Warranty | | | | Package Weight | 3.25 lb | | Box Dimensions (LxWxH) | 10.6 x 8.8 x 3.9" |
