Product description iOptron built on the success of their first camera tracking system with the redesigned and re-engineered SkyTracker Pro Camera Mount. The mount is specifically made to capture long-exposure images of the Moon and Sun, or wide-field photos of the night sky or skyscapes. Improvements include a smoother and quieter right ascension motor for clear imaging and precise tracking, the addition of an internal rechargeable battery with a runtime of up to 24 continuous hours, and multiple mounting options for both the camera and the mount itself.The single-axis servo motor features four tracking speeds: Solar, lunar, 1x celestial (for tracking wide-field star patterns), and 1/2x celestial (for combination skyscape framing). Its tracking rates can be used in both the Northern and Southern hemispheres for world-wide use. The included AccuAlign dark-field illuminated polar scope makes precise polar alignment fast and easy - especially when used in conjunction with iOptron's alignment app for Android and iOS devices.The SkyTracker comes in two parts, the Alt-Az base and the tracker module. The base attaches to 3/8"-16 photo/video/field tripod posts via its socket, or 1/4"-20 posts with the included adapter plug. The tracking module can be attached to the base with a simple Vixen-style dovetail plate and saddle or directly to a tripod via a 3/8"-16 socket. The camera mounts onto the tracking module's motorized plate using an optional ball head - for camera rigs up to 2.6 pounds, or with an optional counterweight kit - for rigs from 2.6 to 6.6 pounds, including the lens. - Mount
-
- Single-axis equatorial
- Payload capacity: 6.6lb
- Camera mounts on optional ball head or counterweight kit, available separately
- SkyTracker attaches to base with a Vixen-style dovetail plate and saddle
- Mount SkyTracker directly to photo/video ball heads and tripod via 3/8"-16 or 1/4"-20 socket
- 3/8"-16 or 1/4"-20 tripod mount on base
- Aluminum alloy construction with ABS polycarbonate covers
- Mount and base weighs 2.5 lb, total
- Mount and base only. A tripod is required for proper use
- Motors and Gears
-
- Single right-ascension DC servo motor: Quiet and virtually vibration-free for steadier imaging
- Tracking speeds: 1x Celestial, 1/2x Celestial, solar, lunar
- 180x forward and reverse fast slew speed for fast polar alignment or to find objects
- Selectable Northern or Southern hemisphere
- Right-Ascension shaft: 25mm diameter, steel
- Worm wheel: 74mm diameter, 144-teeth, aluminum alloy
- Worm gear: 11mm diameter, brass
- Four-piece bearing
- Use and Handling
-
- 3/8"-16 and 1/4"-20 attachment post for optional ball head or counterweight kit
- Internal Li-Poly 2000mAh battery with up to 24 hours of runtime
- Micro-USB charging, reaches 80% charge in 5 hours
- Wide 14 to 104° operating temperature
- AccuAlign Polar Scope
-
- Etched reticle for longevity
- Illuminated with 8 intensity levels
- 6° field of view
- 8° field of view Polar sight hole allows for fast alignment without Polar scope
In the Box iOptron SkyTracker Pro Camera Mount with Polar Scope (Mount Only) Padded Carrying Case Micro-USB Charging Cable AccuAligning Polar Scope Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the iOptron SkyTracker Pro Camera Mount with Polar Scope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersiOptron 3322 Specs | Construction | Die-cast aluminum with ABS cover | | Payload Capacity | 6.6 lb / 3.0 kg | | Mount Type | Equatorial | | Motor Drive | Single-axis DC servo | | Adjustment Range | Latitude: -30 to 65º, with alt-az base
AZ: ±5° | | Mounting | Base to tripod: 3/8"-16, or 1/4"-20 with included adapter
Base to SkyTracker: Vixen-style dovetail
SkyTracker to camera: 1/4"-20 | | Battery | Internal lithium-poly, 3.7 V, 2000 mAh | | Runtime | 24 h max, continuous operation at 68°F / 20°C | | Charging | Micro-USB port, 5 VDC
Charges to 80% in 5 h | | Operating Temperature | 14 to 104°F / -10 to 40°C | | Dimensions | 4.5 x 4.5 x 3.7" / 11.5 x 11.5 x 9.5 cm
Base diameter: 3.1" / 8.0 cm | | Weight | 2.5 lb / 1.2 kg, with battery | | | | Package Weight | 3.5 lb | | Box Dimensions (LxWxH) | 8.7 x 5.9 x 4.8" |
