Product description

This D-213ASE-MATX 2U Compact Aluminum microATX Rackmount Chassis from iStarUSA comes with a 700W PS2 ATX high-efficiency switching power supply.
  • D-213ASE-MATX 2U Compact Aluminum Rackmount microATX Chassis The iStarUSA D-213ASE-MATX Compact Aluminum Rackmount microATX Chassis is a reliable and stable 2U-high and 15" deep industrial computer chassis. The full size I/O supports all microATX motherboards with dual-core or quad-Core processors and the backplate supports 4 low-profile add-on cards (sold separately). This chassis is constructed from aluminum material. In addition, the chassis supports a standard ATX PS2 power supply (sold separately) to help meet regular server system applications.
    • Industrial chassis with 15" depth
    • Two front access USB 2.0 ports
    • Power and HDD LED
    • Power and reset switch
    • Supports ATX PS2 power supply (sold separately)
    • Supports 4 low-profile add-on cards (sold separately)
    • Compact aluminum body
    • RoHS compliant
  • TC-700PD8B 700W PS2 ATX High-Efficiency Switching Power Supply The iStarUSA TC-700PD8B 700W PS2 ATX High-Efficiency Switching Power Supply has a front load ball-bearing cooling fan for optimal airflow to keep the system fully operating. 80 Plus high-efficiency saves energy and reduces cooling requirements. The TC-700PD8B is designed to be the ideal power supply for servers and high-end gaming workstations.
    • Complies with ATX/EPS 12V standards
    • High reliability: MTBF > 100,000 hours
    • Protection: over current, over voltage, and short-circuit
    • Active PFC circuit
    • Full range input
    • High-efficiency 80% above
    • Front load 80 mm fan
    UPC: 846813034814
In the Box Bundle Items D-213ASE-MATX 2U Compact Aluminum Rackmount microATX Chassis wsxwqxtcxye
  • Screws
  • 2 x Key
  • Limited 1-Year Warranty
TC-700PD8B 700W PS2 ATX High-Efficiency Switching Power Supply
  • Limited 1-Year Warranty
Table of Contents




Upload User Manual

Have you got an user manual for the iStarUSA D-213ASE-MATX 2 RU Compact Aluminum microATX Rackmount Chassis with 700W Power Supply in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Upload PDF user manual Upload DOC user manual
Please enter here the link to the user manual of this product:





OR

Enter here the file with the user manual of this product from your computer/phone:
(60MB max; Permitted formats: PDF)

0%


Technical parameters

  • D-213ASE-MATX 2U Compact Aluminum Rackmount microATX Chassis
    Standard Drive Bays 3.5" Drive: 1
    3.5" Drives (internal): 2
    5.25" Drive: 1
    Compatibility TC-250PD3 250W PS3 Size ATX12V Switching Power Supply
    TC-500PD3 500W PS3 Size ATX12V Switching Power Supply
    TC-750PD1 750W PS2 ATX Switching Power Supply
    TC-850PD1 850W PS2 ATX Switching Power Supply
    TC-350PD3 350W PS3 Size ATX12V Switching Power Supply
    Indicators Power, HDD
    Switches Power, reset
    Expansion Slots 4 (low profile)
    Security Front bezel
    Material Front Bezel, Handle, & Main Chassis: Aluminum
    Front Connector 1 x USB 2.0
    Air Filter Removable & washable
    Motherboard Size microATX: 9.6 x 9.6" (243.8 x 243.8 mm)
    Fan 2 x 2.3" (60.0 mm) The cooling fan is sold separately.
    Dimensions (W x H x D) 19.00 x 3.50 x 15.40" (482.60 x 88.90 x 391.1 mm)
    Weight 11.0 lb (4.9 kg)
    Box Dimensions (LxWxH) 21.5 x 21.0 x 8.0"
  • TC-700PD8B 700W PS2 ATX High-Efficiency Switching Power Supply
    Wattage 700
    Fan Size Front load 3.1" (8.0 cm)
    Certification ATX/EPS 12V
    Connectors 1 x main connector - 20 + 4 pin
    1 x 4 + 4 pin 12V
    1 x 8 pin EPS 12V
    2 x 6 + 2 Pin PCIE
    5 x Molex
    4 x SATA
    1 x Floppy
    MTBF > 100,000 hours
    Protection Over current
    Over voltage
    Short-circuit
    Environment Requirements Operating temperature: 32 - 122°F (0 - 50°C)
    Operating humidity: 10 - 90% RH, non-condensing
    Operating altitude: 0 - 5000' (1524 m) above sea level

    Storage temperature: -4 to 176°F (-20 - 80°C)
    Storage humidity: 95% RH, non-condensing
    storage altitude: 0 - 50,000' (15,240 m) above sea level
    Dimensions 5.9 x 3.4 x 5.5" (150.1 x 86.1 x 140.0 mm)
    Weight 7.0 lb (3.2 kg)
    Box Dimensions (LxWxH) 10.0 x 6.0 x 6.0"
