User manual
Istorage 256GB diskAshur PRO2 USB 3.1

User Manual for Istorage 256GB diskAshur PRO2 USB 3.1 Encrypted Portable SSD

• Product category: External Drives Istorage
• Brand: Istorage
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Istorage External Drives

Product description

• FIPS 140-2 Level 3 (USA), NCSC CPA (UK), NLNCSA BSPA (NL), and NATO restricted level certified

• Water and dust resistant, IP56 rated

• No speed degradation—as fast as non-encrypted USB 3.1 HDDs

• Desk lock slot

• No software or drivers required—100% hardware encryption

• Read-only (write protect) and read/write modes

• PIN authenticated; supports independent Admin and User 7-15 digit PINs

• Super-speed USB 3.1 interface with integrated cable

• No admin rights needed

• OS and platform independent—works on any device with a USB port

• Layer of super-tough epoxy resin over all components

EDGE (Enhanced Dual Generating Encryption) Technology
• The diskAshur PRO2 SSD offers advanced portable data security via a built-in FIPS PUB 197 validated AES-XTS 256-bit hardware encryption engine. The data encryption key is randomly generated by a Common Criteria EAL4+ ready random number generator and protected by FIPS validated wrapping algorithms. A dedicated onboard Common Criteria EAL4+ ready microprocessor enhances security through true random number generation and built-in cryptography. Active-shield technology and physical mechanisms protect the drive from external tamper, bypass laser attacks, and fault injections.

  The diskAshur PRO2 SSD's microprocessor reacts to all forms of automated hacking attempts by entering the deadlock frozen state where the device can only restart through a power-on reset procedure. The security lock feature protects the device against any unauthorized firmware modifications from the host side (fully protected against BadUSB). The microprocessor uses algorithms to encrypt both the data and the encryption key, giving you the peace of mind of knowing that your data is protected at any given time.

FIPS PUB 197 Validated Encryption Algorithm
• Employing AES-XTS 256-bit hardware encryption, the diskAshur PRO2 SSD seamlessly encrypts all data on the drive in real time, keeping your data safe even if the drive is removed from its enclosure.

USB 3.1 Fast Transfer
• With USB 3.1 data transfer speeds of 294 MB/s (read) and 319 MB/s (write), the drive gives you fast access to your files. The diskAshur PRO2 SSD is also backward compatible with USB 2.0 and 1.1 ports.

Brute Force Hack Defense Mechanism
• The diskAshur PRO2 SSD is intelligently programmed to protect against all forms of brute force attacks. After five consecutive incorrect PIN entries the drive freezes, requiring the drive to be disconnected and reconnected to the USB port to get five further PIN entry attempts. If five further consecutive incorrect PIN attempts are entered, the diskAshur PRO2 SSD freezes again. To get five final PIN attempts (15 in total), the "shift" button must be pressed whilst inserting the USB cable into the USB port and then a preset PIN needs to be entered. On the fifteenth consecutive incorrect PIN entry, the diskAshur PRO2 SSD assumes it is being attacked. At this point the drive deletes the encryption key and locks itself, rendering all data previously stored on it lost forever. In such an event the drive can be reset to factory default settings and redeployed.

Self-Destruct Feature
• You can pre-program the diskAshur PRO2 SSD with your own unique Self Destruct PIN which, once implemented, instantly deletes the encryption key, all PINs, and data, after which a new encryption key is created.

Unattended Auto-Lock Feature
• The diskAshur PRO2 SSD can be set to automatically lock after a predetermined length of idle time.

Drive Reset Feature
• The diskAshur PRO2 SSD also employs a drive reset feature, which can be implemented with a unique command. This clears all PINs and data, and creates a new randomly generated encryption key, enabling the drive to be reset and redeployed as many times as needed.

Tamper-Proof & Tamper-Evident Design
• In addition to incorporating a secure microprocessor and encrypting the data and the encryption key, the diskAshur PRO2 SSD adds another barrier between your data and a hacker. All the components of the diskAshur PRO2 SSD are completely covered by a layer of super-tough epoxy resin, which is virtually impossible to remove without causing permanent damage to the components. This barrier prevents potential hackers from accessing the drive's critical components. Furthermore, the diskAshur PRO2 SSD provides visible evidence in the event of tampering.

Data-at-Rest Protection
• All data and encryption keys are always encrypted while at rest.

Wear-Resistant Epoxy-Coated Keypad
• The diskAshur PRO2 SSD's wear-resistant epoxy-coated keypad hides key usage to avoid tipping off would-be hackers to commonly used keys.

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

Istorage Pro2 Specs
