Product description The ASB6125-WRX High-Power Dual-15" Subwoofer from JBL is designed to house two of the company's 2265H-1 Differential-Drive dual-coil dual-gap 15" woofers. It is front-loaded, vented, and is constructed with a neodymium magnet transducer and a durable cone for maximum reliability and a long lifespan. The ASB6125-WRX features an exterior fiberglass finish, corners wrapped in fiberglass cloth for maximum structural reinforcement, and an interior gelcoat seal for use in extreme environments and when directly exposed to the outdoors. - 2 x 2265H-1 15" Differential-Drive dual-voice coil dual-gap, neodymium magnet transducers
- 1600 W continuous pink noise and 6400 W peak power-handling capacity
- Parallel/discrete switchable-input mode
- Large vent area for high output with low distortion
- For ground-stacked or suspended applications in stand-alone arrays or in combination with other AE Series products
In the Box JBL ASB6125-WRX High-Power Dual 15" Subwoofer Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the JBL ASB6125-WRX High-Power Dual 15" Subwoofer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersJBL ASB6125 Specs | Frequency Range | At -10 dB: 32 Hz to 1 kHz | | Frequency Response ± 3dB | 38 Hz to 1 kHz | | Transducer Power Rating | 1600 W (6400 W peak), 2 hr | | Input Modes | Drivers parallel, drivers discrete | | Long-Term System Power Rating | 1530 W (5400 W peak), 100 hr | | Maximum SPL | 32 to 400 Hz: 132 dB-SPL cont avg (138 dB peak) | | System Sensitivity | 35 to 400 Hz: 100 dP-SPL, 1 W (2.0 V) @ 1 3.3' / 1.0 m | | Nominal Impedance | 4 ohms in parallel-drive mode
2 x 8 ohms in discrete-drive mode | | Low Frequency Driver | 2 x 2265H-1, 15.0" / 380.0 mm diameter, 3.0" / 75.0 mm Dual-Coil Dual-Gap neodymium Differential-Drive drivers | | Enclosure | Rectangular cabinet, 0.6" / 16.0 mm exterior grade 11-ply birch plywood | | Suspension Attachment | 16 points (4 top, 4 bottom, 4 each side), M10 threaded hardware | | Input Connector | NL4 Neutrik Speakon and CE-compliant covered barrier-strip terminals. Barrier terminals accept up to 0.2 in² / 5.2 mm² (10 AWG) wire or max width 0.4" / 9.0 mm spade lugs. Speakon in parallel with barrier strip for loop-through. | | Approvals and Compliance | IP56 per IEC 529
Mil-Std 810; IP-x3 per IEC529 | | Finish | Exterior: 0.1" / 1.5 mm fiberglass, corners wrapped in fiberglass cloth for maximum structural reinforcement
Interior: gelcoat-sealed | | Grille | Powder-coated 14-gauge perforated steel, with acoustically transparent black-foam backing | | Dimensions | 38.0 x 16.5 x 23.5" / 96.5 x 41.9 x 59.7 cm | | Weight | 80.9 lb / 36.7 kg |
