Product description The JBL Control 322CT is a passive 12" coaxial ceiling speaker with a multi-tap transformer designed for voice amplification and foreground music reproduction in waiting rooms, offices, retail stores, and restaurants. With a low-saturation transformer for compatibility with a 70V/100V power amplifier (available separately), this 2-way speaker provides a long-term power capacity of 400W (1600W peak). The Control 322CT is equipped with a durable 12" Kevlar-reinforced cone and a medium-format compression driver, yielding an extended frequency response of 48 Hz to 19 kHz. The cone, which also serves as a waveguide, results in reliable 90° broadband coverage while the built-in crossover network ensures proper frequency distribution to the speaker components. A removable locking connector with screw-down terminals ensures easy wiring at the desired power tap setting. - Coaxial ceiling speaker with pre-attached ported baffle
- Low-saturation 68W multi-tap transformer enables use with 70V/100V constant-voltage systems
- Long-term power handling of 400W (1600W peak)
- Durable 12" Kevlar-reinforced cone serves as a waveguide for high frequencies
- Metal throat transitions smoothly to the horn to eliminate high-frequency beaming
- High-temperature 3" voice coil
- Medium-format compression driver features a radial slot phase plug for a smooth, extended high-frequency response, along with a neodymium magnet for low installation weight
- Consistent 90° coverage on a broadband basis
- Built-in crossover network with 18 dB/octave high-pass filter and 12 dB/octave low-pass filter
- Integrated EZRail temporarily holds one side of the speaker baffle in place until the installer can affix the baffle to the backcan with screws
- Removable multi-pin locking connector with secure screw-down terminals allows pre-wiring of inputs for easy clip-on convenience during installation
- Compatible with MTC-300SG12 grille, and MTC-300BB12 backbox (both available separately)
In the Box JBL Control 322CT 12" 2-Way 400W Coaxial 70V/100V Ceiling Speaker Limited 5-Year Warranty on Loudspeaker Table of Contents
|
Upload User Manual
Have you got an user manual for the JBL Control 322CT 12" 2-Way 400W Coaxial 70V 100V Ceiling Speaker in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersJBL Control 322CT Specs | Active or Passive | Passive | | LF Driver | 12" / 30 cm Woofer with Kevlar-Reinforced Cone and 3" / 7.5 cm Voice Coil | | HF Driver | JBL 2407H Medium-Format Compression Driver with Neodymium Magnet and 1.5" / 3.7 cm Voice Coil | | Frequency Range | 32 Hz to 20 kHz (-10 dB) | | Frequency Response | 48 Hz to 19 kHz (
