User Manual for JBL Go Mobile Rechargeable Portable PA Kit with EON One Pro, Wireless Mic, and Accessories Click to enlarge the picture
Contents of the user manual for the JBL Go Mobile Rechargeable Portable PA
- Product category: Portable PA Systems JBL
- Brand: JBL
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for JBL Portable PA Systems
|
User manual for the JBL Go Mobile Rechargeable Portable PA contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any JBL product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official JBL user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a JBL product will considerably shorten its lifespan!
|
Product description Be Heard with JBL Compact and Portable Linear-Array PA Systems Read More This B&H Kit combines the JBL EON ONE PRO All-In-One Rechargeable Linear Array PA System with a handheld wireless microphone, a wireless microphone carrying case, a mic stand, a premium XLR to 1/4" cable, and a foam windscreen to create a portable PA system well suited for on-the-go performances. - JBL EON ONE PRO All-In-One Rechargeable Linear Array PA System
- Elle Varner A Wanderer - JBL EON ONE PRO
Building upon the success of the EON ONE, the JBL EON ONE PRO is an all-in-one battery-powered, compact PA system that delivers professional quality audio for live performances, meetings, conferences and more. The base unit houses the battery, power amplifier, 8" subwoofer, and the 7-channel mixer. The built-in lithium-ion battery can power the system for up to 6 hours. The high-frequency element features patent pending Directivity Control Geometry, which optimizes the spacing and angles of the six high-frequency drivers to create a remarkable front-to-back coverage.
Channels 1 to 4 on the mixer offer XLR-1/4" connectors with dedicated treble, bass, and reverb controls, as well as phantom power for condenser microphones or active DIs. Channels 3 & 4 can be switched to Hi-Z instrument inputs to accommodate guitars and bass, while channels 5 & 6 offer stereo RCA inputs, and a stereo 1/8" input for connecting portable music players. Additionally, channels 5 & 6 offer Bluetooth audio streaming. The mixer also features a stereo RCA output monitor for connecting to additional speakers, recording devices, or other outboard gear and an XLR pass-thru for connecting additional speakers.
The EON ONE includes two spacers allowing for three position configurations and further expanding the systems flexibility. The HF element and two spacers conveniently pack away into the base unit, which can be carried by one hand. An optional EON ONE bag is available, which includes wheels to aid in transporting the unit and provides protection from bumps and scratches. Additionally, an accessory mount located at the top of the line-array speakers allows you to attach a camera, such as a GoPro or a light for creating a vibe. The EON ONE PRO ships with the two spacers and a power cord. -
- 6 hours of battery playtime with high-capacity Li-ion rechargeable battery
- Max SPL: 118 dB (peak)
- Bass: 8” LF bass unit
- Driver: 6 x 2” HF drivers
- 80° x 60° clean coverage using patent-pending "Directivity Control Geometry"
- Seven-channel mixer with Bluetooth streaming audio
- 4 x XLR-1/4"
- 1 x 3.5 mm
- 1 x stereo RCA
- +48V phantom power
- Hi-Z inputs
- Pass-thru XLR connector
- Carry the compact and ultra-light EON ONE PRO with just one hand; it’s only 37.5 lbs
- Wireless Bluetooth streaming of break music or backing tracks
- Keep your mobile device handy and powered up with a built-in stand and USB charging port
- Capture the moment or add lighting effects with the built-in accessory mount for a camera or lighting element
UPC: 691991006715 - AKG WMS40 Mini Single Vocal Set Wireless Microphone System (Band: D)
- Elle Varner A Wanderer - JBL EON ONE PRO
The band D WMS40 Mini Single Vocal Set Wireless Microphone System from AKG features a single-channel SR40 Mini receiver and an HT40 Mini handheld transmitter, and is a true plug and play wireless solution. It provides clear audio sound and can be used to capture audio in several environments for applications such as live stage, rehearsals, conferences, and more. The included HT40 handheld transmitter features a dynamic cardioid capsule for maximum gain before feedback. The SR40 receiver has a balanced 1/4" output connector, which connects to your mixer or amplifier. The WMS40 is a fixed frequency system and has an extremely long battery life of 30 hours on a single AA battery, and saves money in day-to-day operation. A universal power supply is also included. UPC: 885038039006 - Gator Cases GM-1W Wireless Mobile Pack
- Elle Varner A Wanderer - JBL EON ONE PRO
The Gator Cases GM-1W Wireless Mobile Pack (Black) is a 600 denier nylon case with interior padding. It is designed to carry and protect an entire single wireless system. The zippered case reveals sufficient space for lavalier microphones, cables and accessories. The foam padded interior protects the gear from shock while remaining lightweight and rugged. The receiver is functional while still in the bag. The front and back unzip for easy access. The bag is carried by a removable, adjustable shoulder strap and padded carrying handles. - Construction
-
- 600 denier nylon
- Foam padded interior
- Zipper closure
- Access for antenna to be extended while in the case
- Space for lavalieres, cables and wireless mic with transporter
- Mounted front and rear access unzips for easy set up in the field
- Carrying options
-
- Removable, adjustable shoulder strap
- Padded carrying handles
- Compatible with most single microphone wireless systems
UPC: 716408503424 - Auray MS-5230T Tripod Microphone Stand with Telescoping Boom
- Elle Varner A Wanderer - JBL EON ONE PRO
The Auray MS-5230T Tripod Microphone Stand with Telescoping Boom features durable, steel construction. The telescoping boom arm is adjustable from 19.3 to 33.9" in length, allowing you to angle and extend the mic placement however you need it. An ergonomic twist-action clutch helps adjust the height of the stand, while the reinforced tripod base and non-slip feet keep it firmly and sturdily in place. The Auray MS-5230T mic stand collapses for easy transport. UPC: 847628015593 - Pearstone PM Series 1/4" TRS M to XLR M Professional Interconnect Cable - 6' (1.8 m)
- Elle Varner A Wanderer - JBL EON ONE PRO
The Pearstone PM Series 1/4" TRS M to XLR M Professional Interconnect Cable (6') is ideal for audio applications in which a device with an XLR input needs to be connected to a device with a balanced 1/4" output. Typical scenarios include connecting the output of a mixing board or audio interface to a powered speaker, or using an aux send to route signal to an outboard effects processor.
The cable is equipped with 24-gauge oxygen-free copper conductors and spiral shielding to protect against EMI and RFI noise. The professional-grade cast-zinc Rean XLR connector is field serviceable and features silver-plated contacts, while the Rean 1/4" TRS connector features a molded design for maximum strain relief. The twin conductive PVC shield reduces electrostatic noise, and distinguishes the PM series as the best value in its class. - Professional quality, field-serviceable, cast-zinc Rean connectors with silver-plated contacts
- Twin conductive PVC shield reduces electrostatic noise
- 24-gauge oxygen-free copper conductors
- Spiral shielding to protect against EMI and RFI noise
UPC: 847628574793 - Auray WHF-158 Foam Windscreen for 1-5/8" Diameter Microphones (Black)
- Elle Varner A Wanderer - JBL EON ONE PRO
The black Auray WHF Series Foam Windscreens are designed to reduce unwanted broadband wind noise and vocal pops with minimal high frequency loss. This WHF-158 Foam Windscreen is designed for use with many common handheld microphones with a 1-5/8" diameter head. The density of the specialty acoustic foam is optimized to help protect the microphone element from air bursts without muffling the sound. When used on a handheld microphone, this windscreen is effective in minimizing wind noise and plosive sounds. It is most effective in calm to light breeze conditions (0-7mph), and can be used indoors for protection against drafts caused by air-conditioners. Users can generally expect a 4dB to 8dB reduction in wind noise, with very slight dampening of high frequencies. For most applications, the very slight high frequency dampening is a worthwhile exchange for the notable wind noise reduction. The WHF-158's foam is hypoallergenic and washable and helps prevent moisture and dirt from damaging your microphone. The windscreen is designed to fit microphones from Shure, Electro-Voice, AKG, Audio-Technica, Audix, Beyerdynamic, Sennheiser, Neumann and others. The WHF-158 Foam Windscreen for 1-5/8" Diameter Microphones is an effective solution for basic wind protection. - Fits these and other similar-sized microphones:
-
- Shure SM58, Beta 58, Beta 87A, Beta 87C, PG58, PG48, SM48, SM96, VP88, SM87, SM53, SM54, PE85, PE86, BG3.0, PE15, PE75, 12a, 14A, 587, 587SB
- Electro-Voice RE50/B, BBK1, Co5, Co7, Co9, DS35, MC100, 150, 300, MT200, N/D200, N/D247, 257, 267, N/D357, 367, 457, 757, N/D767, PL50, PL60, PL70, PL77, PL80, RE11, RE16, RE18
- Sennheiser e825S, e865, MD21, 200, MD400, 425, 427, 429, MD511, 512, 515, 516, 735, MD736, ME65, MKE44, SKM3072, SKM5000, SKM100, SKM300, SKM500, SKP30
- Audio-Technica AE3300, 4100, 5400, 6100, ATM23, 25, 29, 31, 41, 61, ATM91, AT801, AT802, AT813, AT814, ATW7375, ATW-T602, MB1000, Pro-1a, Pro-2ax, Pro-3, Pro-4, Pro-5, Pro-10
- Audix OM-2, OM-3, OM-5, OM-6, OM-7, VX-10
- AKG C900, D40, D50, D60, D80, D90, D95, D125, D130, D190, D200, D310, D321, D330, D590, D770, D880, C535, CK4, D3700, D3800, D5900
- Beyerdynamic BM85, EM85, M01, M59, M69, M260, M300, M400, M500, MCE81, TGX-20, TGX-40, TGX-58, TGX-60, TGX-80
- Neumann KMS105, KMS140, KMS150
- Nady SP-1, SP-3, SP-4, SP-5, SP-9, SP10, WHT14, WHT15, UH10
- Peavey Celebrity, PAA250, PVM835, PVM880, PV, PVi
- Telex HT700, SH100, FMR150, FMR450, EN6100, H12E, VR12E
UPC: 847628562868 In the Box - EON ONE PRO All-In-One Rechargeable Linear Array PA System eyewqwut
- EON ONE Pro Base
- Column Speaker Array
- 2 x Listening Height Spacers
- Power Cable
- Limited 5-Year Warranty on Speaker
- Limited 3-Year Warranty on Amplifier
- Limited 2-Year Warranty on Cabinet
- AKG - WMS40 Mini Single Vocal Set Wireless Microphone System (Band: D)
- Gator Cases - GM-1W Wireless Mobile Pack
- Auray - MS-5230T Tripod Microphone Stand with Telescoping Boom
- Pearstone - PM Series 1/4" TRS M to XLR M Professional Interconnect Cable - 6' (1.8 m)
- Auray - WHF-158 Foam Windscreen for 1-5/8" Diameter Microphones (Black)
7 All-In-One Portable Speaker Systems for Special Events and Parties Phillip Nichols-Wright 11/29/2018 Table of Contents
|
Upload User Manual
Have you got an user manual for the JBL Go Mobile Rechargeable Portable PA Kit with EON One Pro, Wireless Mic, and Accessories in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - JBL EON ONE PRO All-In-One Rechargeable Linear Array PA System
| | | System Type | Battery-operated portable line array with powered mixer | | Maximum SPL | 118 dB peak system output (pink noise) | | | | Type | Extended-life lithium-ion | | Charge Time | 5 hours | | Run Time | Up to 6 hours | | | | Design | Class-D | | System Power | System Power Rating: 250 W LF/HF | | | | Input Connectors | 6 inputs (4 x mono mic/line, 1 x stereo) | | Channels | 1-4: XLR-1/4" / 6.35 mm combo connectors (XLR = mic-level input, 1/4" = line-level input)
(Enabling the CH3+CH4 HI-Z button switches 1/4" inputs on channels 3-4 to accept high-impedance signals from instruments)
5-6: 3.5 mm stereo jack or stereo RCA connectors | | Input Impedance | Ch 1-4 combo XLR: 40 KOhms balanced
Ch 1-2 Combo TRS: 40 KOhms balanced
Ch 3-4 Combo TRS (CH3+CH4 HI-Z button disabled): 40 kOhms balanced
Ch 3-4 Combo TRS (CH3+CH4 HI-Z button enabled): 40 kOhms unbalanced
Ch 5-6 RCA: 5 kOhms unbalanced
Ch 5-6 3.5 mm: 10 kOhms unbalanced | | Phantom Power | 48 V (CH 1-4 XLR inputs) | | Bluetooth | 2-channel Bluetooth audio input streaming (stereo signal is fed to the Monitor Out jacks while mono-summed signal is fed to the line array speakers) | | Output Connectors | 3 outputs (1 x stereo RCA monitor output
1 x mono pass thru output) | | Output Impedance | RCA Monitor Outputs: 100 Ohms unbalanced
XLR Pass Thru Output: 37 Ohms balanced | | Signal Indicator | Limit: Yellow LED indicates limiter active condition | | EQ Section | Individual channel Bass and Treble controls, center detent, ±12 dB cut and boost | | Limiter | System Limiter: On-board DSP limiting and tuning | | | | LF Driver | LF: 1 x 8.0" / 203.2 mm woofer | | HF Driver | HF: 6 x 2.0" / 50.8 mm drivers | | Coverage Pattern | 80º x 60º (H x V) | | Enclosure | Polypropylene | | Grille | Powder-coated perforated steel | | | | Dimensions (H x W x D) | 15.8 x 10.5 x 23.4" / 401.3 x 266.7 x 594.4 mm | | Weight | 37.5 lb / 17.0 kg | | | | Box Dimensions (LxWxH) | 26.5 x 21.0 x 16.5" | - AKG WMS40 Mini Single Vocal Set Wireless Microphone System (Band: D)
| | | Frequency Bandwidth | Band D | | Audio Frequency Response | 40 to 20 kHz | | Signal to Noise | 110 dBA | | Total Harmonic Distortion (THD) | 0.8 % @ 1 kHz | | Operating Temperature Range | 14 to 131°F (-10 to 55°C) | | Peak Deviation | 45 kHz | | Nominal Deviation | 15 kHz | | Radio Output Power | 10 mW | | Transmitter Synchronization | Manual | | Interchangeable Mic Heads | No | | Channels | 3 | | Number of Selectable Frequencies | 1 fixed frequency | | Range | 66' (20 m) | | Modulation | FM | | Pilot Tone | No | | Encryption | No | | Battery | 1 x LR6 AA alkaline | | Operating Time | 30 hours | | Material of Construction | Plastic | | Dimensions (H x W) | 9.1 x 2.0" (230 x 51 mm) | | Weight | 6.9 oz (195 g) | | | | Frequency Bandwidth | Band D | | Audio Frequency Response | 40 to 20 kHz | | Signal to Noise | 110 dBA | | Total Harmonic Distortion | 0.8% @ 1 kHz | | Operating Temperature Range | 14 to 131°F (-10 to 55°C) | | Radio Sensitivity | -100 dBm | | Channels | 3 | | Number of Selectable Frequencies | 1 fixed frequency | | Frequency Selection | Fixed | | Range | 66' (20 m) | | Modulation | FM | | Encryption | No | | Pilot Tone | No | | Transmitter Synchronization | Not necessary | | HiQnet Compatible | No | | Rack Compatibility | 1/3 rack size (19")
Rack height: 1 RU | | Antenna | 1 x fixed external antenna | | Audio Output | 1 x balanced TRS 1/4" (6.3 mm) female jack
Balanced audio output adjustable from mic to line level
Output level at rated deviation: 500 mV rms | | Internal Power Supply | No
Type: DC socket
Voltage: 12 V | | Material of Construction | Metal | | Dimensions (L x H x W) | 5.2 x 1.7 x 5.2" (132 x 43 x 133 mm) | | | | Box Dimensions (LxWxH) | 11.6 x 9.4 x 2.6" | - Gator Cases GM-1W Wireless Mobile Pack
| Material | Exterior: 600 denier nylon
Interior: Foam padded | | Type of Closure | Zippers | | Exterior Dimensions | 15.35 x 5.0 x 11.42" (38.99 x 12.7 x 29cm) (LxDxH) | | Interior Dimensions | 8.5 x 2.0 x 8.5" (21.59 x 5.08 x 21.59cm) (LxDxH)
Mic Drops: 8.25" (20.96cm) | | Carrying/Transport Options | Shoulder strap
Padded carrying handles | | Weight | 4.4 lbs (2.0kg) | | | | Box Dimensions (LxWxH) | 14.724 x 10.315 x 4.882" | - Auray MS-5230T Tripod Microphone Stand with Telescoping Boom
| | | Height | 36.2 to 63" / 91.9 to 160 cm | | Base Type | Tripod | | Base Dimensions | 25.6 x 25.6" / 65 x 65 cm | | | | Length | 19.3 to 33.9" / 49 to 86 cm | | | | Material | Steel | | Weight | 4.6 lb / 2.1 kg | | | | Box Dimensions (LxWxH) | 33.5 x 4.0 x 4.0" | - Pearstone PM Series 1/4" TRS M to XLR M Professional Interconnect Cable - 6' (1.8 m)
| Cable Type | 3-Pin XLR balanced to 1/4" TRS interconnect cable | | Length | 6' (1.8 m) | | Shielding | Copper spiral shield | | Gauge | 24 AWG | | Contacts | Silver plated | | Connector 1 | XLR Male | | Connector 2 | 1/4" TRS Male | | | | Box Dimensions (LxWxH) | 5.9 x 5.9 x 1.3" | - Auray WHF-158 Foam Windscreen for 1-5/8" Diameter Microphones (Black)
| Compatible Mic Diameter | 1.62" / 4.13 cm | | Material | Foam | | | | Box Dimensions (LxWxH) | 2.6 x 2.6 x 1.8" |
