User Manual for JBL PD595-WRC 15" Horn-Loaded Full-Range Loudspeaker System with WRC Weather Protection Click to enlarge the picture
Contents of the user manual for the JBL PD595-WRC 15" Horn-Loaded Full-Range Loudspeaker
- Product category: Installed Speakers JBL
- Brand: JBL
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for JBL Installed Speakers
 |
User manual for the JBL PD595-WRC 15" Horn-Loaded Full-Range Loudspeaker contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any JBL product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official JBL user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a JBL product will considerably shorten its lifespan!
|
Product description Provided by third party: PD595 is a Precision Directivity loudspeaker designed for applications requiring high output capability with excellent pattern control. PD595 can be utilized in music or speech systems where frequency extension to 80Hz is adequate or combined with subwoofers to create extended bandwidth full-range systems.
The 2031H 380mm low-frequency transducer features high sensitivity and low power compression for high and continuous SPL capability. It is horn-loaded for additional sensitivity and improved pattern control. The 2432H 38mm exit, 75mm voice coil high frequency compression driver utilizes a neodymium magnet and aluminum diaphragm to deliver clear and intelligible high frequency projection, extended frequency response, and low distortion at even the highest drive levels.
The system is equipped with a large format rotatable PT waveguide allowing the PD595 to be used in either vertical or horizontal orientation. The loudspeaker can be operated in either biamplified or in full passive mode. Input connectivity is achieved via CE-compliant covered barrier strips. The cabinet is fitted with twenty-two M10 threaded suspension points, supporting a wide variety of installation approaches.
- Key Features
-
- 380 mm horn-loaded low-frequency driver
- Large PT Progressive Transition waveguides provide broad band 90
|
Upload User Manual
Have you got an user manual for the JBL PD595-WRC 15" Horn-Loaded Full-Range Loudspeaker System with WRC Weather Protection in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersJBL PD595-WRC Specs | | | Product Type | Speaker - for stage | | Protection | Weatherproof | | Enclosure Color | Black | | Enclosure Material | Birch plywood | | Design Features | DuraFlex finish, trapezoidal design | | | | Speaker Type | 2-way - passive | | Nominal Output Power | 300 Watt | | Max (RMS) Output Power | 500 Watt | | Frequency Response | 50 - 20000 Hz | | -3dB Frequency Response | 90 - 16000 Hz | | Nominal Impedance | 8 Ohm | | Output Level (SPL) | 139 dB | | Sensitivity | 104 dB | | Crossover Frequency | 1300Hz | | Coverage | 90
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 02 owners. Add your rating and experience with the product.
