User Manual for JVC DT-V24G2Z 24" 10-Bit Studio LCD Monitor Click to enlarge the picture
Contents of the user manual for the JVC DT-V24G2Z 24" 10-Bit Studio LCD
- Product category: Production Monitors JVC
- Brand: JVC
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for JVC Production Monitors
 |
User manual for the JVC DT-V24G2Z 24" 10-Bit Studio LCD contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any JVC product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official JVC user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a JVC product will considerably shorten its lifespan!
|
Product description The JVC DT-V24G2Z 24" 10-Bit Studio LCD Monitor features a 10-bit panel and wide gamma range, making it suitable for critical image evaluation. The monitor is fully capable of displaying 1920 x 1200 signals, and offers a contrast ratio of 1500:1. It also offers wide viewing angles of 178°/178° and a brightness rating of 400 cd/m2.The studio monitor supports EIA/CEA-708 and EIA/CEA-608 SDI closed captioning standards. It comes with a built-in stereo speaker and a tiltable stand with two-way installation capability. - 10-bit IPS panel with 1.073 billion color reproduction
- WUXGA resolution: 1920 x 1200 pixels
- Built-in histogram, waveform, vectorscope, and zebra pattern
- Built-in audio level meter, up to 16 channels
- Wide array of markers and indicators
- Two 3G-SDI and dual-link inputs
- EBU 100% equivalent color spectrum
- Color temperature settings: 9300K, 6500K, 5600K, or User mode
- IP modes: Normal, Field, and Cinema (24p)
- Pixel-by-pixel (1:1) display
UPC: 046838074790 In the Box JVC DT-V24G2Z 24" 10-Bit Studio LCD Monitor Tilting Desk Stand AC Power Cord Power Cord Holder Core Filter 2 x Screw Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the JVC DT-V24G2Z 24" 10-Bit Studio LCD Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersJVC DT-V24G2Z Specs | Monitor Type | Multi-format LCD monitor | | Screen Size | 24" (61 cm) measured diagonally | | Resolution | 1920 x 1200 | | Display Colors | 1.073 billion | | Viewing Angle | 178° / 178° (H / V) | | Brightness | 400 cd/m2 | | Contrast Ratio | 1500:1 | | Signal System | Not specified by the manufacturer | | Response Time | Not specified by the manufacturer | | Aspect Ratio | 16:10 | | LCD Panel | 24" (61 cm) diagonal, active matrix TFT | | Effective Screen Size | W x H: 20.4 x 12.8" (51.8 x 32.4 cm) | | Standards | 3G-SDI (Ready): SMPTE 424M / SMPTE 425M; dual-link
HD-SDI (Ready): SMPTE 372M
HD-SDI: BTA S-004C, SMPTE 292M
SD-SDI: ITU-R BT.656 (525 / 625), SMPTE 259M (525)
Embedded Audio: SMPTE 299M, SMPTE 272M | | Audio Output | Internal: 1 W + 1 W (L/R) | | Energy Efficiency Class | C | | Rated Current | North America: 0.72 A (120 VAC)
Europe: 0.42 A (220 to 240 VAC) | | Video I/O | In 1:
3G/HD/SD-SDI
In 2:
3G/HD/SD-SDI (compatible with embedded audio/dual-link signals; auto detection)
2 x Lines
2 x BNC connector
1 x HDMI In (compatible with HDCP)
1 x Component In:
Y: 1 Vpp, 75 Ohms (with sync)
PB/B-Y, PR/R-Y: 0.7 Vpp, 75 Ohms
1 x Composite Input/Output
2 x BNC, 1 Vpp, 75 Ohms
((In and Out are connected with a bridge connection; auto termination)
Out 1:
3G/HD/SD-SDI (compatible with embedded audio signals)
1 x Line, BNC connector
Out 2:
3G/HD/SD-SDI (switched out; compatible with embedded audio signals)
1 x Line, switched out
1 x BNC connector | | Audio I/O | In 1:
2 x Analog signal lines
2 x RCA connectors
1 x 3.5 mm stereo mini jack
In 2:
500 mV (rms), high impedance
Output:
Audio assign (monitor out)
1 x Analog signal line
2 x RCA, 500 mV (rms) | | External Control | Make/Trigger: RJ-45
RS-485: RJ-45
RS-232C: D-Sub (9-pin) | | Operating Temperature | 41 to 95°F (5 to 35°C) | | Storage Temperature | -4 to 140°F (-20 to 60°C) | | Operating Humidity | 20 to 80%, non-condensing | | Power Requirements | 120/220 to 240 VAC, 50/60 Hz | | Power Consumption | On: 38.9 W
Standby: 0.29 W
Annual Energy Consumption: 57 kWh/year | | Dimensions (W x H x D) | With Stand: 22.3 x 17.7 x 9.6 " (56.4 x 44.9 x 24.3 cm)
Without Stand: 22.3 x 16.1 x 3.9" (56.4 x 40.8 x 9.9 cm) | | Weight | With Stand: 23.4 lb (10.6 kg)
Without Stand: 17.0 lb (7.7 kg) | | | | Package Weight | 29.0 lb | | Box Dimensions (LxWxH) | 26.0 x 22.3 x 13.0" |
Rating90% users recommend this product to others. And what about you?
