Product description The SMPTE 311M Fiber Optic System from JVC includes the Camera Unit, the G4 Base Station, an SMPTE hybrid power cable, OpticalCON connectors, an IDX Power Wafer, and a universal intercom. The system is for use with the GY-HM890 ProHD camcorder. It provides you with all the signals used in television broadcast production from digital video transmission to intercom interface. In the Box JVC Fiber Optic System with IDX Power Wafer and OpticalCON Connector Camera Unit G4 Base Station OpticalCON Connector IDX Power Wafer Universal Intercom Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the JVC Fiber Optic System with IDX Power Wafer and OpticalCON Connector in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersJVC FS-790PNVG Specs | | | Data Rate | 270 Mb/s or 1.5 Gb/s (digital bidirectional) | | Input Level | 800 mV (peak to peak) (digital bidirectional) | | Impedance | Input/Output: 75 Ohms (digital bidirectional) | | Output Impedance | 75 Ohms (digital bidirectional) | | Bit Error Rate | 10-12 (@ -22 dBm) (digital bidirectional) | | Jitter | < 0.2 UI (pathological data) (digital bidirectional) | | Time | Rise/Fall: < 270 ps (digital bidirectional) | | Interface | RS170, NTSC, PAL (analog bidirectional) | | Frequency Response | 30 Hz to 4.2 MHz:
