Product description Making News: JVC GY-HM620 and GY-HM660 ProHD Mobile News Cameras Read More The JVC GY-HM660 ProHD Mobile News Streaming Camera features a lightweight-user-friendly design providing capacity for fast, efficient mobile newsgathering. The GY-HM660 offers built-in GPS, Wi-Fi connectivity allowing FTP file uploads, and remote control and remote viewing Apps for both iOS and Android. Also, a dual codec recording capacity allows for simultaneous HD + SD or HD + ¼ HD capture for web delivery. The built-in streaming functionality enables you to record internally, while simultaneously streaming. Please note that streaming from the camera requires that you source a Wi-Fi adapter, 4G LTE modem, or a LAN connector that connects to the camera's USB port.
The camera's imaging system consists of three 1/3" 12-bit CMOS sensors with 1920 x 1080 resolution. The camera records NTSC broadcast compatible frame rates up to 59.94p in AVCHD and integrates a 23x Fujinon autofocus zoom lens with manual focus and zoom capability with a built-in 3-position ND filter. Connections include HD-SDI and HDMI. Comprehensive recording options consist of MPEG-2, AVCHD 2.0, and SD and Proxy H.264. Two SDXC/SDHC slots are available for simultaneous dual codec recording or relay recording. A viewfinder, LCD display and built-in microphone provide additional flexibility in on-the-go shooting. - Image
-
- Three 1/3" 12-bit CMOS sensors (1920 x 1080 each)
- 23x Fujinon autofocus wide angle zoom lens with manual functions F1.6-3.0, 23x, f=4.1-94.3mm (35mm equivalent: 29 to 667mm)
- Optical image stabilizer
- 3 position ND filter (1/4, 1/16, 1/64)
- Inputs / Outputs
-
- HD/SD-SDI and HDMI outputs
- 2-ch balanced audio mic/line switchable inputs with phantom power supply
- Frame Rate
- The camera records at NTSC compatible frame rates of up to 59.94 i/p
- Multiple Encoding Formats
-
- HD MPEG2 (35/25/19Mbps)
- AVCHD 1920 x 1080 59.94p/60i
- SD H.264
- 960x540 H.264 mode
- 480x270 H.264 (web)
- Wide Media Format Compatibility
-
- AVCHD
- .MP4 (XDCAM EX)
- .MOV
- Pre Record
- In this mode, the camera continually records up to 15 seconds in cache memory. When the trigger is pressed, the live signal is appended to the cached recording. This feature is useful for situations when you don't know when the action will start, and allows you to press record after the event has happened, and still capture it, without worrying about wasting recording time or overwriting your media cards.
- Additional Features
-
- The Interruptable Foldback (IFB) Audio channel allows the control room to communicate with on-air talent or the camera operator via an ear piece. Communication is one way, with the control able to send messages but not receive them. IFB Audio is scheduled to be available around June 2016
- SDXC/SDHC memory card recording (2 slots for dual-backup, continuous recording)
- Built-in GPS
- Professional switch layout and comprehensive video settings
- Time lapse recording
- Built-in stereo microphone
- Wi-Fi connectivity with Apps for iOS/Android for remote control, remote viewing, and metadata upload (requires optional Wi-Fi adapter)
- FTP file upload via Wi-Fi (requires optional Wi-Fi adapter)
- Dual codec recording for simultaneous HD + SD or HD + 1/4 HD capture (for web delivery)
- 0.45-inch 1.22M pixel color viewfinder
- 3.5-inch 920K pixel LCD display with focus assist
- High performance 2D DNR
- Wired remote control connector
UPC: 046838074172 In the Box JVC GY-HM660 ProHD Mobile News Streaming Camera AC Adapter Battery Pack AV Cable Limited 3-Year Warranty User Manual PDF 10.8mbsavytrawaysqzcwsuyuraazydx Table of Contents
|
Upload User Manual
Have you got an user manual for the JVC GY-HM660 ProHD Mobile News Streaming Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersJVC GY-HM660 Specs | | | Image Sensor | 3-Chip 1/3" CMOS Sensor | | Sensor Resolution | 2.2 MP | | Gain | -6 to 18 dB | | | | Focal Length | 4.1 to 94.3mm | | 35mm Equivalent Focal Length | 29 to 667mm | | Optical Zoom Ratio | 23x | | Maximum Aperture | f/1.6 to 3 | | Filter Size | 72 mm | | Image Stabilization | Optical | | | | Shutter Speed | 1/6 to 1/10,000 sec | | Built-In ND Filter | Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters | | Recording Media | 2 x SDXC Card Slots (U1 / Class 10 or faster cards recommended) | | | | Broadcast System Compatibility | NTSC | | Recording Modes | MPEG2 4:2:0:
1920 x 1080 at 23.98/25/29.97 fps
1440 x 1080i at 50/59.94 fps
1280 x 720p at 23.98/29.97/59.94 fps
AVCHD 4:2:0:
1920 x 1080p at 23.98/25/29.97/50/59.94 fps | | Audio Recording | 2-Channel 16-Bit 48 kHz | | | | Video Connectors | 1 x 1/8" (3.5 mm) TRRS A/V Output
1 x BNC (HD-SDI) Output
1 x HDMI Output
1 x 1/8" (3.5 mm) TRRS A/V (Composite) Output | | Audio Connectors | 1 x 1/8" (3.5 mm) Stereo Headphone Output
2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" (3.5 mm) Stereo Input | | Other I/O | 1 x 2.5 mm LANC Control
1 x RCA Timecode Input/Output | | | | Display Type | LCD | | Screen Size | 3.5" | | Screen Resolution | 920,000 Dots | | | | EVF Display Type | LCOS | | Screen Size | .45" | | EVF Resolution | 1,220,000 Dots | | | | Power Connectors | 1 x Barrel (12 VDC) Input | | Power Consumption | 12 W | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Storage Temperature | 14 to 122°F / -20 to 50°C | | Operating Humidity | 35 to 80% | | Storage Humidity | 85% | | | | Dimensions | 7 x 7.8 x 16.3" / 17.8 x 19.8 x 41.6 cm | | Weight | 5.3 lb / 2.4 kg | | | | Package Weight | 9.15 lb | | Box Dimensions (LxWxH) | 19.7 x 11.4 x 10.7" |
