Product description The JVC Pan / Tilt Control Unit (Rack-mountable) remotely controls video surveillance cameras through a simple RS-422 interface; it is best suited for the JVC DPT-130 range of pan / tilt heads and JVC KY-F560U cameras. The unit supports up to 4 cameras and features 8 presets along with variable focus and zoom functions. Some of the controller's applications include teleconferencing, distance learning, tele-medicine, and theater instrumentation. Pan-and-tilt control is provided by a proportional deflection joystick; the speed can be controlled by the force with which the control is pressed. - Suitable with DPT-130 pan / tilt heads and JVC KY-F560U cameras
- 8 presets for up to 4 cameras
In the Box JVC Pan / Tilt Control Unit (Rack-mountable) Wall Mount Power Supply 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the JVC Pan Tilt Control Unit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersJVC MODEL-180R Specs | Control | Power: Slide Switch, with LED indicator
Pan/tilt: Joystick, proportional deflection
Focus: Seesaw control, proportional deflection
Zoom: Seesaw control, proportional deflection
Presets: 16 per cameral station
Number of stations: 4
Max. distance between controller & p/t head: 2000' (610 m) | | Output Connector | 4 conductor RJ-11 style (other connectors available for special requirements) | | Power Requirements | 9 to 28 VDC (includes power supply) | | Current | 0.3 Amperes | | Operating Temperature | (for indoor use)
40 - 104°F (0 - 40°C) | | Mounting | Table top, rack mount or special | | Dimensions (WxD) | Rack Mount: 19 x 3.5" (483 x 89mm) | | Weight | 4 lbs (1.8kg) |
