Product description The HDSC31D-4K 3-Input DisplayPort, HDMI, & VGA Switcher Scaler over HDBaseT from KanexPro is designed for sending video and control signals up to 230' over a shielded Catx cable to an HDBaseT receiver. It supports resolutions up to 4K @ 30 Hz. The sender or receiver can be powered from either side, requiring only one power supply supporting POE (Power over Ethernet) and allowing you to switch between the sources while upscaling or downscaling to the desired resolution.DisplayPort, HDMI, and VGA inputs are built into the transmitter (sender) with one HDBaseT output and serial control. This Collaboration Switcher supports video signal resolutions up to 4K, including 1920 x 1200 and 1080p60 Deep Color. The HDSC31D-4K offers reliable switching and transmission of DisplayPort, HDMI, and analog video signals with HDCP 2.2 compliancy. Additionally, RS-232 and IR remote control facilitate integration. - Reliable switching with selectable output resolutions up to 4K @ 30Hz
- 3D, 1080p @ 60 Hz, 36-bit; 4K2K @ 30 Hz, 24-bit
- VGA supports scaling resolutions up to 720p, 1080p, and 1600 x 1200 @ 60 Hz
- Bidirectional POE support (Tx to Rx/Rx to Tx)
- Bidirectional IR control, front-panel, and RS-232 pass-through
- Supports CEC and HDCP 2.2 compliant
- Compact and slim design for flexible installation
- International power supply
- Low profile design and remote power (POE) capability enable discreet placement in lecterns and beneath tables in conference rooms, board rooms, or smart classrooms
UPC: 813982020566 In the Box KanexPro HDSC31D-4K 3-Input DisplayPort, HDMI, & VGA Switcher Scaler over HDBaseT HDBaseT Transmitter HDBaseT Receiver Wideband IR Tx Wideband IR Rx Power Supply Mounting Ear Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the KanexPro HDSC31D-4K 3-Input DisplayPort, HDMI, & VGA Switcher Scaler over HDBaseT in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersKanexPro HDSC31D-4K Specs | | | Video | 1 x HDMI
1 x VGA
1 x HDBaseT | | Signal | DP/HDMI/VGA | | IR | 1 x 1 IR In (3.5 mm mini jack) | | | | Video | 1 x HDMI
1 x HDBaseT | | Signal | HDMI Video | | IR | 1 x 1 IR Out (3.5 mm mini jack) | | | | Resolution | HDMI: Up to 4K/30 Hz
DisplayPort: 4K/30 Hz, 1920 x 1200, and 2560 x 1600
VGA: 1024 x 768, 1280 x 720, 1280 x 800, 1600 x 1200, and 1920 x 1080 | | Maximum Pixel Clock | 165 MHz | | Gain | 0 dB | | Standards | HDMI, DisplayPort, HDCP:
Compliant with DVI & HDMI 1.4 standards, HDCP 2.2
Compliant to the VESA DisplayPort standard, version 1.1a, for both 1.62 Gbps & 2.7 Gbps
Supports resolutions up to 4K @ 30 Hz | | Bandwidth | HDMI: 10.2 Gbps | | Output | 75 Ohms | | Level | Input/Output: 0.5 to 2 Vpp | | | | Input | HDMI/DP audio via HDMI, DP connectors | | Input Impedance | >10 kOhms | | Output | Via HDMI | | Output Impedance | 50 kOhms | | Frequency Response | 20 Hz to 20 kHz | | CMRR | >90 dB @ 20 Hz to 20 kHz
Audio Format: HDMI
Embedded Audio: PCM, Dolby DTS | | Stereo Channel Separation | >80 dB @ 1 kHz | | | | Control | IR remote, buttons, and RS232; Phoenix connectors | | Pin Configuration | 2=TX, 3=RX, 5=GND | | Power Supply | 24 VDC, 1 A | | Power Consumption | Approximately 10 W | | Temperature | 32 to 113°F (0 to 45°C) | | Humidity | 10 to 90% | | Dimensions | Tx: 2.9 x 7.6 x 0.7" (7.5 x 19.3 x 1.8 cm)
Rx: 2.9 x 5.7 x 0.7" (7.5 x 14.5 x 1.8 cm) | | Weight | Tx: 13.4 oz (380 g)
Rx: 10.2 oz (290 g) | | | | Package Weight | 2.395 lb | | Box Dimensions (LxWxH) | 11.25 x 5.65 x 2.85" |
